Rsrteng IPC-H12 Series User Manual

Security camera tester

Quick Links

Download this manual

SECURITY CAMERA TESTER

IPC-H12 Series

User Manual

IPC-H12

IPC-H12-ADHS

IPC-H12-MADHSEF

IPC-H12-MOVTADHSEF

（V01.00）

Table of Contents

Need help?

Do you have a question about the IPC-H12 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Rsrteng IPC-H12 Series

Page 1 SECURITY CAMERA TESTER IPC-H12 Series User Manual IPC-H12 IPC-H12-ADHS IPC-H12-MADHSEF IPC-H12-MOVTADHSEF （V01.00）...
Page 2 Preface • Thank you for purchasing the Rsrteng IP camera tester. Please read the manual before using the IP camera tester and use properly. We have built this user manual in the tester, you can also view it on your tester.
Page 3: Table Of Contents
IP Camera Tester User Manual Content 1. Safety information ..........................1 2. IP Camera Tester Introduction ......................2 2.1 General ............................. 2 2.2 Packing list ..........................4 2.3 Function interface ........................5 3. Operation ............................8 3.1 Installing the Battery ......................... 8 3.2 Instrument connection .......................
Page 4 IP Camera Tester User Manual 3.3.13 Auto HD ( *Optional )....................44 3.3.14 HD Coaxial & Analog level test (* Optional ) .............44 3.3.15 SDI Camera Test (* Optional ) ..................46 3.3.16 CVI camera test (* Optional ) ..................46 3.3.17 TVI camera test (* Optional ) ..................53 3.3.18 AHD camera test (* Optional ) ..................55 3.3.19 NET TOOL PRO ......................56 (1) IP address scan.......................56...
Page 5 IP Camera Tester User Manual 3.3.35 Data monitor .......................99 3.3.36 Audio player ......................100 3.3.37 Media Player ......................100 3.3.38 RTSP Player ......................101 3.3.39 Hik test tool .......................103 3.3.40 Dahua test tool......................107 3.3.41 Update ........................112 3.3.42 Office ........................112 3.3.43 LED Flashlight ......................113 3.3.44 Browser ........................113 3.3.45 Notepad ........................114 3.3.46 Professional WIFI Analyzer ..................115...
Page 6: Safety Information
1. Safety information ◆ The Rsrteng tester is intended to use in compliance with the local rules of the electrical usage and avoid to apply at the places which are inapplicable for the use of electrics such as hospital, gas station etc.
Page 7: Ip Camera Tester Introduction
2. IP Camera Tester Introduction 2.1 General The Rsrteng 8 inch touch screen IP camera monitor is designed for maintenance and installation of IP cameras, analog cameras, 8MP TVI, 8MP CVI, 8MP AHD, 8MP EX-SDI cameras, as well as testing 8K H.265 /4K H.264 IP camera via mainstream, The high resolution enables it to display network HD...
Page 8 IP Camera Tester User Manual Model feature comparison The IPC-H12 series has multiple models, this manual list all the functions of the tester, but does not mean that your tester has all the functions in the user manual. Except for IPC-H12-MOVTADHSEF, other models will not support some of these functions.
Page 9: Packing List
8). Multi-meter test leads one pair of red and black (only for H12-MADHSEF, H12-MOVTADHSEF) 9). Output Power cable 10). Audio cable 11). TDR alligator clamp (only for H12-MOVTADHSEF) 12). 8GB TF card 13). Safety cord 14). Tool bag 15). Manual (English) Page.4. www.rsrteng.com...
Page 10: Function Interface
Press more than 3 seconds, turn on or off the device, short press to turn on or off the menu display Menu key Confirm key Return/Close: Return or cancel while setting parameters of the menu Multimeter interface (Optional) Page.5. www.rsrteng.com...
Page 11 IP Camera Tester User Manual Top interface Bottom interface DC12V 3A power output, for provisional DC power supply. PSE power supply input interface/Lan test interface PoE++ power supply output/Lan test interface HDMI IN. Camera Laser distance meter Optical power meter interface (Optional) Page.6. www.rsrteng.com...
Page 12 TDR3.0 cable test interface -RJ45 (Optional). VGA input HDMI output interface. Audio input/Audio output and earphone interface. Audio output and earphone interface TF card slot, include 8GB TF card, support TF card up to 32GB. TDR 3.0 cable test interface-Alligator Clips (Optional). Microphone Page.7. www.rsrteng.com...
Page 13: Operation
Multi-meter: the red and black multi-meter pen must insert the corresponding port. Warnings: Instrument communication port is not permitted access circuit voltage over 6V, otherwise damage the tester. Warnings: Not allow insert multi-meter pen in the current terminal to measure voltage. Page.8. www.rsrteng.com...
Page 14: Instrument Connection
PoE switch can receive the data via the tester. Warning: PoE switch or PSE power sourcing equipment only can be connected to tester "PSE IN" port, otherwise will damage the tester. Page.9. www.rsrteng.com...
Page 15: Analog Camera Connection
1) Connect the SDI camera's video output to the IP tester's "SDI IN" interface, the image will display on the tester. The tester only come with SDI input interface. There is no SDI output interface. 2) Connect the SDI camera or the speed dome RS485 controller cable to the tester RS485 interface. Page.10. www.rsrteng.com...
Page 16: Hdmi In
IP Camera Tester User Manual 3.2.4 HDMI IN DVR, NVR or other device's HDMI out port connect to tester's HDMI in port, the meter will display input image. Page.11. www.rsrteng.com...
Page 17: Hdmi Output
Auto HD: Automatically recognize type of HD input signal HDMI IN: Click HDMI IN to enter, In HDMI IN mode, It can converter test from analog to digital with dual test window IP &HDMI IN or Analog & HDMI in. Page.12. www.rsrteng.com...
Page 18: Short-Cut Menu
You can long press any app in the all applications list, it will auto move to shortcut menu. If delete any app in the shortcut menu, please select an APP and press several seconds, it will be deleted. Page.13. www.rsrteng.com...
Page 19: Screen Capture
Tap icon "Link Monitoring" at left corner on the screen to enter. It can detect instrument port rate 10/100/1000M, signal quality detection, upload and download speed, etc. in real time. It can be used to detect whether the network video access bandwidth of devices such as NVR is normal. Page.14. www.rsrteng.com...
Page 20 IP Camera Tester User Manual When using a four-core cable to connect to a Gigabit device, would prompt "the link limited". Advanced link monitor It is for monitoring CVBS loop, Ethernet statistics, error frame statistics, frame length etc. Page.15. www.rsrteng.com...
Page 21: Testerplay
At this time, the mobile phone will display the real-time screen projection of the Tester, and you can touch the screen to control the Tester. (If the screen is not displayed, please quickly slide the left menu of the Tester interface system settings or switch the Tester interface) Page.16. www.rsrteng.com...
Page 22: Ip Discovery
Tester. (The phone can also install VLC player for screen projection viewing) IP discovery 3.3.6 Press IP discovery , tester auto-scan the whole network segment IP, as well as auto-modify the tester's IP to the same network segment with the scanned camera's IP. Page.17. www.rsrteng.com...
Page 23: Ipc Test Pro
IP, and auto-modify tester's IP address, greatly improved engineering efficiency . IPC Test pro 3.3.7 Camera test often need to open multiple apps, "IPC Test pro" app, using new technology and combine multiple functions to one APP, it can increase efficiency. Page.18. www.rsrteng.com...
Page 24: Rapid Onvif
It lists cameras name and IP address on the Left of screen. Tester can auto login camera and display camera image. Factory default use admin password to auto login, if you modified the password, then default use the modified password to login. Page.19. www.rsrteng.com...
Page 25 Click the button “Refresh”, tester will scan the ONVIF camera again. Click the newly displayed ONVIF camera on the “Device List”. The tester will show the IP camera’s relative information and settings. Pop-up settings menu when click the icon of the upper left corner Page.20. www.rsrteng.com...
Page 26 Compatible IP PTZ cameras will rotate accordingly. PTZ rotation direction is displayed on top left corner of the image. Page.21. www.rsrteng.com...
Page 27 IP Camera Tester User Manual IP camera video settings: Click “Video Set” to enter the IP camera’s encoder and resolution settings. Make the desired changes and click “OK” to save. Page.22. www.rsrteng.com...
Page 28 IP Camera Tester User Manual Image setting: Click “Imaging Set” to adjust image brightness, saturation, contrast, sharpness and backlight compensation mode. Profiles: Click “profiles", can view video streaming current configuration files, as well as switch between Major stream and minor stream. Page.23. www.rsrteng.com...
Page 29 Preview pictures: Quickly preview and zoom in or out pictures, automatically and manual refresh Identification: click “Identification” to view information of the camera Time set: click “Time set”, Select “Manual set” to set up the time of camera Page.24. www.rsrteng.com...
Page 30 IP Camera Tester User Manual Maintenance: For camera software reset or restore to factory settings. Network setting: Click “Network Set” to change the IP address. Some cameras cannot support change IP address, so there is no change after saving. Page.25. www.rsrteng.com...
Page 31 When the image is enlarged, if not operate on touch screen, it can operate by the keyboard, press the key “ZOOM+” to zoon in, press the key “ZOOM-” to zoom out, press upward and downward key to move image. Page.26. www.rsrteng.com...
Page 32 Click on the “Stop” icon to stop recording and save the video file to the TF card. Playback: Click the “Playback” icon to view saved videos. Double click the video you want to play. Click to return to the last menu Page.27. www.rsrteng.com...
Page 33 To rename or delete a photo, click and hold on the file until this screen appears: Video files can play in the Video player on the main menu. Modify channel name: clicking "OSD" will pop up OSD settings, including time, channel name and other optional items. Page.28. www.rsrteng.com...
Page 34 Set preset position: Move the camera to preset position, enter the preset number on the Bottom right corner to complete position preset. Call the preset position: Select the preset number on the left, click "Call" to call preset Page.29. www.rsrteng.com...
Page 35 IP Camera Tester User Manual PTZ Speed set: Horizontal and Vertical Speed set RTSP: Get RTSP address of the current camera Doc: Auto generate test reports document of camera, click "generate document”. Click Preview to view the report document Page.30. www.rsrteng.com...
Page 36 IP Camera Tester User Manual Enter the camera test information, click "Create Document" to complete the report. Click doc menu again, you can preview the report document. Icons description: the description of function icons on the bottom toolbar Page.31. www.rsrteng.com...
Page 37: Non Onvif
"Manual": Click IP camera type, list Honeywell, Kodak, Tiandy, ACTi IP camera etc. If the brand has offered official original protocols, pls select camera type, input IP camera address, user name and password, click "official" to enter the camera image display interface (Currently, only support DAHUA official protocols). Page.32. www.rsrteng.com...
Page 38 IP address. It is better to directly connect the IP camera to the tester so the search results will only display the camera's IP address. If the tester is connected to a PoE switch, it will find and display several IP address. Page.33. www.rsrteng.com...
Page 39: Hdmi In
When tester receives HDMI in image, the top tool bar shows the resolution of this image. You can select "resolution" to set resolution in the setting menu. Tap screen by twice, full image display. Support resolution up to 4K_3840*2160/2K_2560*1440P/1920×1080p /1920×1080i /720×480p /720×576p /1280×720p/1024×768p/1280×1024p /1280×900p /1440×900p Page.34. www.rsrteng.com...
Page 40 When you click the "Record" icon, video starts recording. A red recording icon appears on the screen and begins to flash and a timer appears indicating the time elapsed for the video. Click on the "Record" icon again to stop recording and save the video file to the SD card. Page.35. www.rsrteng.com...
Page 41 Double-tap the image you want to view to make it full screen. Double-click again the photo to return. To rename or delete an image, click and hold on the file until this screen below appears Click to close and return to PTZ controller. Page.36. www.rsrteng.com...
Page 42: Analog Camera Test
"Record", "Playback", "PTZ", "Set". Click , or press to quit. Click the screen twice quickly, can be full zoom in on the touch screen. 1) PTZ controller parameter setting Select and click icon "PTZ", to enter PTZ setting: Page.37. www.rsrteng.com...
Page 43 To control PTZ by screen touch: Tap left, right, upward and downward on the touch screen to control the PTZ rotation direction. By two fingers move outward and inward on the touch screen to zoom in and out the PTZ. Page.38. www.rsrteng.com...
Page 44 PTZ direction of rotation Press the key , switch on or turn off the aperture. Press the key , adjust the focus manually Press the key , manually adjust the zoom 2) Video and storage setting Page.39. www.rsrteng.com...
Page 45 If the unit is set to the manual mode an "Input Name" pop up box will appear and you can enter a title for the snapshot. If the unit is set up to automatically set file names, this box will not pop up. Page.40. www.rsrteng.com...
Page 46 (by Chinese character, English letter, or digit) to store in SD card, tester will hereby store the files in SD card after recording. if select "Auto-storage", tester will auto store the files in SD card after recording. Page.41. www.rsrteng.com...
Page 47 Click the "Playback" icon to view your recorded videos. Tap on the video file image you want to watch. To rename or delete a video, click and hold on the file until this screen appears: Video files also can play in the main menu "Video Player". Page.42. www.rsrteng.com...
Page 48: Color-Bar Generator (Tv Out)
If the monitor receive the color bar, it means the video transmit channel works normally. Meanwhile on the basis of the received color bar, the monitoring center can judge if transmission has loss or interference. Page.43. www.rsrteng.com...
Page 49: Auto Hd (*Optional)
It is used for level measurement of HD coaxial cameras, judge whether the working image of the camera and the image after attenuation by BNC cable transmission are normal, quickly detect and eliminate faults. Page.44. www.rsrteng.com...
Page 50 Threshold: Critical value at this resolution. Lower this value, will appear image noise on the screen, click "value" to modify. Reset: Click "Reset" to reset the reference value and threshold. Create documents: The testing report can save customer information, level meter test information, camera information and Instrument information. Page.45. www.rsrteng.com...
Page 51: Sdi Camera Test (*Optional)
HD CVI camera, CVI dome camera test and PTZ control, click icon to enter When HD CVI signal input, the tester will display the image resolution on the top bar. Double-taps on the screen to make the image displayed full screen. Page.46. www.rsrteng.com...
Page 52 1920x1080P 30FPS/2560x1440P 25FPS/2560x1440P 30FPS/ 2592x1944P 20FPS / 2960x1920P 20FPS / 3840 x 2160P 12.5/15 FPS (1) PTZ control 1.1 Coaxial PTZ control Click the icon "PTZ" on the right toolbar to do the corresponding setting. "Port": select coaxial control Page.47. www.rsrteng.com...
Page 53 Tap left, right, upward and downward on the touch screen to control the PTZ rotation direction, PTZ cameras will rotate accordingly. By two fingers move outward and inward on the touch screen to zoom in and out the PTZ. Page.48. www.rsrteng.com...
Page 54 Press the key , manually adjust the zoom Set preset position Setup preset position, move the PTZ camera to the preset position, the Tap it and input preset position number. Tap "Set position" to complete set preset position. Page.49. www.rsrteng.com...
Page 55 Call preset position Tap the preset position: Tap the preset position area, input preset position number. Tap "call position" to complete call preset position. 1.2 RS485 control Operation instructions, please refer to "3.3.1 PTZ (1) PTZ control parameters setting". Page.50. www.rsrteng.com...
Page 56 Tap icon "UTC", select "menu setting" to enter the dome camera menu. Input calling dome camera menu address code, after finishing the parameter settings, you can press the or click the icon to call the dome camera menu. Page.51. www.rsrteng.com...
Page 57 (3) Snapshot, record, photo viewer and video play back, please refer to "3.3.1 PTZ (1) Video monitor test". Tap "close menu" or press the key " " to close camera menu. (4) Save setting Click icon "Set" on the right toolbar to enter storage setting. Support auto-storage and manual storage. Page.52. www.rsrteng.com...
Page 58: Tvi Camera Test (*Optional)
The tester supports resolution as follows: 1280x720P 25FPS / 1280x720P30FPS / 1280x720P 50FPS / 1280x720P 60FPS 1920x1080P 25FPS / 1920x1080P 30FPS / 1920x1080P 50FPS / 1920x1080P 60FPS //2048x1536P 18FPS/2048x1536P 25FPS/2048x1536P 30FPS /2560x1440P 15FPS/2560x1440P 25 FPS/2560x1440P 30FPS/2688x1520P 15FPS/2592x1944P 12.5FPS/2592x1944P 20FPS/3840 x 2160P 12.5/15 FPS Page.53. www.rsrteng.com...
Page 59 Input calling dome camera menu address code, after finishing the parameter settings, you can press the or click the icon to call the dome camera menu. More operation instructions (such as PTZ control, coaxial camera menu setting, snapshot, recording and playback etc.), please refer to "3.3.6 CVI camera test". Page.54. www.rsrteng.com...
Page 60: Ahd Camera Test (*Optional)
UTC control: select "PTZ control or PTZ control-2"(AHD camera has two different order, if select "PTZ" cannot control, please go "PTZ-2" ) If to coaxial PTZ control the AHD camera, no parameters setting is needed. More operation instructions please refer to "3.3.6 CVI camera test" Page.55. www.rsrteng.com...
Page 61: Net Tool Pro
Connect the cable to the LAN port. Set your IP address search range by changing the Start and End IP addresses. Click the "Start" button to scan the IP address range. You can also input an IP address in the Port Number Scan to scan for open ports. Page.56. www.rsrteng.com...
Page 62: Ping Test
Application: PING testing is the most conventional network debugging tools. It is used for testing if the connected IP camera or other network equipment's Ethernet port is working normally and the IP address is correct. It's normal that the first data packet will be lost when test start. Page.57. www.rsrteng.com...
Page 63: Network Test (Ethernet Bandwidth Test)
The two testers must be in the same network segment. a). Start the server: Click "Start Server" button to use the tester as a Server. It will display its IP address at the top of the screen. Page.58. www.rsrteng.com...
Page 64 Network bandwidth testing can also be tested with a computer using compatible network bandwidth testing software. Install network bandwidth testing software on a computer, as a test Client or Server, to do the mutual testing with the tester. If use computer as the server, the computer IP address is :192.168.0.39 Page.59. www.rsrteng.com...
Page 65 IP address. Input Server's IP address 192.168.0.39 in the tester and click "Start" to test network bandwidth. Or use tester as a Server, computer as test Client（select Client, input tester's IP address to test） When use tester as Server, shows results: Page.60. www.rsrteng.com...
Page 66: Port Flashing
Click on the DHCP icon to open the DHCP server app. Select the "Start" check box at the top and make any desired changes to the network settings. Click "Save" to start assigning dynamic IP addresses for IP cameras and other networked devices. Click the "Refresh" button to check your client list. Page.61. www.rsrteng.com...
Page 67: Trace Route
Note: Trace route testing results only for reference, for accurate test route tracking, please use professional Ethernet tester. Click to enter trace route Input tracking IP address or domain name in the Remote Host IP. Set maximum hop count, normally default is 30 Click "start" to trace the goal address Page.62. www.rsrteng.com...
Page 68: Link Monitor
Add an IP camera or other network device to the current network group, the new IP address must not be occupied, otherwise it will cause IP conflicts and stop the equipment normal working. Link monitor can check if the new setting IP address is occupied. Page.63. www.rsrteng.com...
Page 69: Poe++ Power / Dc12V 3A And Dc 5V 2A Usb Power Output
5. Make sure you plug in your IP camera to the LAN port prior to turning on PoE power 6. Make sure the tester is full charged or more than 80% charged, otherwise the tester will shows "low power", "not able to supply power". Page.64. www.rsrteng.com...
Page 70: Dc 24V 2A Power Output
Disconnect all the connections of the tester and then connect the tester with power adaptor to resume the tester. d. Make sure the tester is full charged or more than 80% charged, otherwise the tester will shows "low power", "not able to supply power" Page.65. www.rsrteng.com...
Page 71: Cable Test
If need several different number other types cable testers, should pay the additional cost. Cable test Tap "cable test sketch map", pop up Straight-through cable and crossover cable sketch, it is for line sequence reference, when the crystal on the first pressure in the twisted-pair. Page.66. www.rsrteng.com...
Page 72: Rj45 Cable Tdr Test
"online", the testing result would be not accurate. Cable quality test: Green is good quality cable, Yellow is Poor quality cable, Red is water poured cable, the attenuation value will be displayed when cable over 10 meters. Page.67. www.rsrteng.com...
Page 73 Skew: After 1000M link up, when skew value is 0ns, it is the best quality communication, if over 50ns, will cause a Bit Error Rate in the transmission. Cable sequence diagram: A straight- through and cross-over cable diagram, the cable sequence display for reference. Click "Help" to check the instruction of all parameters. Page.68. www.rsrteng.com...
Page 74: Cable Tracer
Press the "MUTE" button of cable tracer for 2 seconds. After the "Di" sound, the silent mode is turned on. In the silent mode, can judge cable type according to the indicator light. Press the "MUTE" button again to exit the silent mode. Page.69. www.rsrteng.com...
Page 75: Tdr Cable Test (*Optional)
Connect Alligator clip cable to the TDR port, and the cable must connect well before testing, otherwise it will influence the accuracy. Built-in BNC cable, network cable, RVV control cable, Telephone line and TVVB cable etc. can test. 11 groups user-defined cable can be set. Page.70. www.rsrteng.com...
Page 76 The Calibration function can be used at this time. Click "Cable" "Type" to select cable and start testing. One tap on "Start", do one testing. If select built Page.71. www.rsrteng.com...
Page 77 2. Click "Cable", "Type" to select cable, and corresponding type, for example, if testing BNC cable, select "BNC", if testing communication cable 75-2, select SYV 75-2. 3. Click "+" or "-" to adjust wave speed, while display length is the same with the actual Length, click Page.72. www.rsrteng.com...
Page 78 It is more convenient and efficient to repair the faulty cable. Note: The TDR reflect signal could be affected by the cable quality cable's not well connected etc. to cause the different TDR measurement. The TDR measurement is for reference only. Page.73. www.rsrteng.com...
Page 79: Bnc Attenuation Test (*Optional)
2. After calibration, the red clip clips the copper core of the BNC cable, and the black clip clips the outer envelope of the BNC cable. attenuation value will be displayed after connection, as below: 3. Click "Reset", the application will restore factory defaults. Page.74. www.rsrteng.com...
Page 80: Poe++ Detection
LAN port, tester not only can transmit voltage to supply power for camera, but also transmit data at the same time, as well as the computer connect to the PoE/PSE, it can log in connected tester's PoE camera. Page.75. www.rsrteng.com...
Page 81: Power Input Test
Warning: Not allow connect device with input power over 17V to tester "1V IN" port, otherwise it will damage the machine. 3.3.29 Digital Multi-meter (* Optional ) Click icon to enter. Page.76. www.rsrteng.com...
Page 82 DC Voltage Measuring WARNING! You can't input the voltage which more than 660V DC, it's possible to show higher voltage, but it's may destroy the inner circuit. Pay attention not to get an electric shock when measuring high voltage. Page.77. www.rsrteng.com...
Page 83 The tester default Auto range status, by click "AC auto range" d. Manual range can be select, press the key "NEAR" to restore Auto range e．Manual range: 0.000V → 6.600V range 00.00V → 66.00V range 000.0V → 660.0V range 000.0mV → 60.0mV rang 000.0mV → 660.0mV range Page.78. www.rsrteng.com...
Page 84 ◆ The maximum current of 10A socket is 10A, over-current will destroy the meter, and will damage the operator. D. AC Current Measuring (Only Manual range) WARNING! Shut down the power of the tested circuit, and then connect the meter with the circuit for measurement. Page.79. www.rsrteng.com...
Page 85 Connect the black test lead to the "COM " jack and the red test lead to the "V/ " jack. Ω b. Select Ω, enter the measurement he tester default Auto range status, Press the key manually select range, press "NEAR" to restore "Auto range" Page.80. www.rsrteng.com...
Page 86 Connect test red lead across to the anode, the black lead to the cathode of the diode under testing. d. Connect test red lead across to the cathode, the black lead to the anode of the diode under testing. Page.81. www.rsrteng.com...
Page 87 → 660.0μF range 000.0uF → 0.000mF 6.600mF range → 00.00mF 66.00mF range d. Before connect test leads across two sides of the capacitor under measurement, be sure that the capacitor has been discharged fully. I. frequency of testing Page.82. www.rsrteng.com...
Page 88 While testing the capacitance of a capacitor to 660uF, the Max time will be 6.6 seconds, if the cap acitor is leaked or damaged, the data can't be read. The tester will be normal after disconnecting the capacitor. AUTO Intelligent mode: In AUTO mode, the DC/AC voltage is automatically switched. Resistance, Continuity Page.83. www.rsrteng.com...
Page 89 When the current gear and the connected pen do not match, the buzzer and red text on the page alarm Added: connection diagram Manual range and Auto range When testing, click "Range select" to change the value, click "Auto range" to enter Auto measurement. Page.84. www.rsrteng.com...
Page 90 Please use the same model when change the fuse, Pls opens the battery cover to change. Note: 10A socket without fuse protection, if over the current range Wrong using the 10A socket to measure the voltage, will damage the meter. Page.85. www.rsrteng.com...
Page 91: Optical Power Meter (* Optional)
Note: Please keep the fiber connector and the dust cap be clean, and clean the detector with the special alcohol. Data hold While testing, click "Hold" to data hold, the data will not change. It's convenient to read. Press again to quit. Page.86. www.rsrteng.com...
Page 92 Input another optical fiber to be measured, the displayed new measurement and relative value is red color. Press it again to quit. Data hold and Relative measuring use together, the data is yellow while the function is effect. Page.87. www.rsrteng.com...
Page 93: Visual Fault Locator (* Optional)
60 mins and 120 mins). Click "Steady mode", red laser source emits steady, click again to quit. Click icons "Evasive 1Hz"or "Evasive 2Hz" to enter pulse mode, the red laser source is emitted by a certain frequency, press it again to quit Page.88. www.rsrteng.com...
Page 94: Infrared Measurement
The number of sides to be measured will vary depending on the measurement mode. When the measurement is over, the "measurement" key changes back to the "start" key, and the red measurement laser of the device goes out. Page.89. www.rsrteng.com...
Page 95: Measurement Mode
Secondary Pythagorean (data subtraction): Measure the three sides of the object separately. Secondary Pythagorean (data addition): Measure the three sides of the object separately. Front and rear reference instruction: Page.90. www.rsrteng.com...
Page 96 Benchmark switch: Click “Benchmark switch”, can select front or rear reference mode. Image 1 Image 2 Note: If select the front reference mode, switch the cross coordinates to icons, the upper reference surface of the tester should be flush with the starting point of the object to be tested. Page.91. www.rsrteng.com...
Page 97 Clear record: clear the testing record of current measurement mode Setting: Select measure unit, meter/foot/inch is optional Export data: Select the record, click “Export data”, will create a CSV file, the file records current testing result and time Page.92. www.rsrteng.com...
Page 98 ①When measuring the distance, the receiving lens and laser emitting port of the instrument should not be covered. As far as possible, the instrument should be placed on a fixed baffle or bracket surface. Do not move the instrument before the software interface displays the measurement results during measurement. Page.93. www.rsrteng.com...
Page 99 (for example, when making measurements in the hot sun), it is advisable to use the laser aiming target (user-supplied). ④Accuracy check of distance measurement You can check the accuracy of the distance measurement by the following methods: Page.94. www.rsrteng.com...
Page 100 Check whether the position of the laser point projection meets the requirements. Move the equipment to re-select the position of the laser point projection suitable for measurement, and then measure again. Page.95. www.rsrteng.com...
Page 101 --- Care should be taken to clean the receiving lens and camera, just as you would clean lenses for glasses and cameras. --- Do not put the instrument in water or other liquids. Page.96. www.rsrteng.com...
Page 102: Automatic Lens Calculation Tool
1. Distance measurement: Click Start, a red laser spot will appear, move the red laser spot to the center of the monitoring screen (on an opaque non-mirror object such as a wall), click "distance measurement" to stat test, and automatically recommends lens according to the test distance. This lens value is for reference only. Page.97. www.rsrteng.com...
Page 103 The actual lens should be selected according to the actual needs. 3. Creating document: Click the “Create Document”, to save the photos and test distance values of the currently tested distance, which is convenient for subsequent viewing. Page.98. www.rsrteng.com...
Page 104: Audio Record
Controller can check the status of the RS485 transmission through the code on the display. (The RS485 communication rate must be the same.) Application: Check the RS485 communication states of the video optical transmitter whether normal. Engineer can analyze the protocol and check the data through the displayed code. Page.99. www.rsrteng.com...
Page 105: Audio Player
SD card. Click on the desired file to play. Click RETURN to exit. To rename or delete an existing file, press the file name for a few seconds until the screen below appears. You can then rename or delete the file by pressing the desired option. Page.100. www.rsrteng.com...
Page 106: Rtsp Player
From the main menu, select the "APP Tool" folder and then select the "RTSP Player" to open the app. If the IP camera uses MJPEG, select the RTSP icon. If the IP camera uses H.264, select the "RTSP HD" icon. Page.101. www.rsrteng.com...
Page 107 Note: In the event the IPC tester does not auto detect the RTSP stream, refer to the specific camera manufacturer for the specific RTSP stream URL. you may find this on line with a search of the camera model number and the word RTSP. Page.102. www.rsrteng.com...
Page 108: Hik Test Tool
Hik test tool app is design for activating and debugging Hikvision camera, can auto-identify inactivated Hikvision camera, also can display image from the Hikvision camera. Tap icon to enter 1. Activation: Select left [online detection] to display the "inactivated" camera and click activate. "Activation" and "Batch activation" are optional. Page.103. www.rsrteng.com...
Page 109 Select "default location" in "content location" is without modification. Select "Customization" to arbitrarily adjust the channel name and display location. Click "OK" and the effects will appear. Press return key or click any area of the screen to return to the upper layer of the interface. Page.104. www.rsrteng.com...
Page 110 Modify network information: Support "modify" and "batch modify" camera IP address, subnet mask and other parameters modification. Enter a new IP address and subnet mask, the default gateway will be auto modified according to the IP address. Click "OK" to save the changes. Page.105. www.rsrteng.com...
Page 111 IP Camera Tester User Manual Modify user information: Modify the camera's user name and password. Factory Reset: Camera factory reset. Page.106. www.rsrteng.com...
Page 112: Dahua Test Tool
IP, user name and password etc. Making Dahua camera test more convenient and quickly. Activation: select left [online detection] to display the "inactivated" camera and click activate. Activate and Batch activate are optional, support reserved phone number for resetting password. Page.107. www.rsrteng.com...
Page 113 IP Camera Tester User Manual Play: When mode display "activated" camera, input correct password, click "Play" poping up "private protocol" and "ONVIF", Select correspond protocol to view the camera image. Page.108. www.rsrteng.com...
Page 114 After selected Channel name, can edit channel name, modify the display position and font size. If select "Default position" of Content location, then no need to modify. If select "customize", then can modify Channel name and display position, click "OK" to view the image. Click "Back" or "Return" button to return previous interface. Page.109. www.rsrteng.com...
Page 115 IP Camera Tester User Manual Modify Network: Support Modify and batch modify two ways, can modify camera IP address, Subnet mask and gateway. Input new IP address, need to input password, click "OK" to save the modification Page.110. www.rsrteng.com...
Page 116 Modify user information: Modify camera user name and password, which is Onvif, Dahua test tool, IPC TESTE user name and password, not web user name and password. Factory reset setting: Camera will be soft reset, and the device's user name, password and network set be saved. Other settings information is factory reset. Page.111. www.rsrteng.com...
Page 117: Update
Update online: Before using online update, need enter settings-user management to register first. System update: Connect the Internet to update systems. 3.3.42 Office Quick office app (support excel, word, ppt format) doc. editable Page.112. www.rsrteng.com...
Page 118: Led Flashlight
For viewing video, use the IP tester's live camera view Apps. The IP camera and IP tester be on the same network segment for the browser to interface with the Page.113. www.rsrteng.com...
Page 119: Notepad
Notepad can auto record the storage date and time. Please click to view the notepad, all saving contents display. Click each record bar to show the details. Press the record bar for several seconds, prompt whether delete it. Page.114. www.rsrteng.com...
Page 120: Professional Wifi Analyzer
IP Camera Tester User Manual 3.3.46 Professional WIFI Analyzer Detect the surrounding WIFI signal and signal strength, support 2.4G and 5G frequency band. Access point list and List format, display WIFI's channel, frequency, signal strength, device information and distance, etc. Page.115. www.rsrteng.com...
Page 121: System Setting
Click icon to enter Language: Select your desired language: English, Chinese, Korean, Russian, Italian, Polish, Spanish, French or Japanese, German, Turkish, etc. Typewriting: You can select typewriting or install other typewriting: Date/Time: Set the Date/time of the IP tester Page.116. www.rsrteng.com...
Page 122 After setting an advanced IP address (refer to the photos above), the unit can test two network segments (192.168.5.0) and (192.168.1.0) WLAN Net: Turn WIFI off or on by pressing the "Open the WIFI" button. Once WIFI is turned on, and click connected WIFI, it will scan for wireless networks in your area. Page.117. www.rsrteng.com...
Page 123 Wired and wireless networks cannot work at the same time. Brightness: Set the desired brightness of the IP tester and adjust the sleep time settings. Volume: Set volume level SD Card: Displays SD Card Capacity. You can also format the SD card or unmount it before removing Page.118. www.rsrteng.com...
Page 124 PTZ address scan: You can toggle the PTZ Address scan off or on before entering the " PTZ controller" app. This needs to be turned on in order to use the PTZ Scan feature of the PTZ app. Page.119. www.rsrteng.com...
Page 125: File Explorer
Restore the factory settings: If the tester to restore factory settings, all your personal files and apps will be removed. 3.3.48 File explorer Click "File" on the top bar tool, can select internal or external storage. Click on the upper right corner Icon"... ". will pop-up menu, you can select other operation or exit. Page.120. www.rsrteng.com...
Page 126 IP Camera Tester User Manual Browse It includes Music, Videos, Pictures, Documents, zip file etc. It is convenient to view and manager. FTP server You can choose internal or external SD card. Other operation details, please refer to FTP settings. Page.121. www.rsrteng.com...
Page 127: Sfp Optical Module Connection
Settings" → "IP Settings" to modify the IP of the tester. 3.3.50 Audio test You can test the audio input from audio pickup devices by connecting the audio pickup device to the IP tester with the supplied audio cable. Page.122. www.rsrteng.com...
Page 128: Specifications
4.1 General Specifications IP Camera Tester【*】models Optional Brand Rsrteng Product IPC-H12 Series Display New 8 inch IPS touch screen Network port 10/100/1000M auto adjust, RJ45, Dual LAN port Built in WIFI, speeds 433M, allows you to connect to a wireless network WIFI and view IP cameras, Operating Frequencies: 2.4G and 5.8G...
Page 129 Send CVI/TVI/AHD/CVBS color bar video signal for testing monitor or vid eo cable, support 4K resolution CVI supported resolution: 4K/8MP_3840x2160p 12.5/15fps,5MP_2592x1944P 20fps, 4MP_2560x1440p 25/30fps,1920x1080p 25/30fps,1280x720p 4K Color bar 25/30/50/60fps, generator *(Optional) TVI supported resolution: 4K/8MP_3840x2160p 12.5/15fps, 5MP_2592x1944p12.5/20fps, 4MP_2560x1440P 15/25/30fps, 3MP_2048x1536p 18fps,1920x1080p 25/30fps, 1280x720p 25/30/50/60fps, AHD supported resolution: Page.124. www.rsrteng.com...
Page 130 PoE power switch, IP setting, WLAN switch, HDMI IN functions etc. Drop-down menu screen lock: password lock screen or pattern lock 1 channel audio signal input and 1 channel audio signal output to connect Audio test headphones Page.125. www.rsrteng.com...
Page 131 Visual fault locator Test fiber's bending and breakage (SM and MM fiber) *(Optional) TDR cable test BNC cable, network cable, telephone cable, RVV cable and elevator cable, *(Optional) cat 5/6 cable’s length and short circuit. measurement range 1.2KM Page.126. www.rsrteng.com...
Page 132: Multi-Meter Specifications
276mmX163mmX44mm / 1.14Kg 4.2 Multi-meter specifications Counts: -6000～+6000 Conversion rate: 3times/s Current modes for clamp meter with ZERO function Isolation: the Multi-meter connector must be isolated with the other connector. DC voltage Range Accuracy Resolution 660mV (Manual range) 0.01-600V± 0.1mV Page.127. www.rsrteng.com...
Page 133 0.1mV 60.0mV 0.1mV 0.01-600V± 6.600V (1.2%+4)/600V-750V± (1.2%+10) 66.00V 10mV 660.0V 100mV DC current Range Accuracy Resolution 6.600mA 66.00mA 10uA ±1.2%+10 660.0mA 100uA 10.00A 10mA AC current Range Accuracy Resolution 6.600mA 66.00mA 10uA ±1.2%+10 660.0mA 100uA 10.00A 10mA Resistance Page.128. www.rsrteng.com...
Page 134 The measurement value less 30Ω±3Ω, the tester will 660.0Ω 0.1Ω sound Diode Range Resolution Function Schottky diode:0.15~0.25V 2.0V rectifier diode:0.6~1.0V triode PN junction:0.5~0.8V Capacitance Range Accuracy Resolution 6.600nF 66.00nF 10pF 660.0nF 100pF 1nF-6000uF± 6.600μF (3.5%+20)/6000uF-60000uF±(5%+4) 66.00μF 10nF 660.0μF 100nF Page.129. www.rsrteng.com...
Page 135: Optical Power Meter Specifications
Working Temperature Operating Temperature -20℃～+70℃ The data above is only for reference and any change of them will not be informed in advance. For more detailed technical inquiries, please feel free to call the Technical Department of our company. Page.130. www.rsrteng.com...
Page 136: Contact Us
5. Contact us The data above is only for reference and any change of them will not be informed in advance. You can get more information and support by: Website: www.rsrteng.com Sales department: sales@rsrteng.com After-sales service department: service@rsrteng.com WhatsApp/WeChat/mobile:: +86 18100275797...
