  • Page 1 IP CAMERA TESTER IPC-7600 Plus series User Manual IPC-7600 Plus IPC-7600CADHS Plus IPC-7600C Plus IPC-7600COTADHS Plus IPC-7600ADH Plus IPC-7600CVTADHS Plus IPC-7600CADH Plus IPC-7600COVTADHS Plus IPC-7600ADHS Plus (V01.00)
  • Page 2 Thank you for purchasing the Rsrteng IP camera tester. Please read the manual before using the IP camera tester and use properly. For using the IP camera tester safely, please first read the [Safety Information] carefully in the manual. The manual should be kept well in case of reference.

  • Page 3: Table Of Contents

    IP CAMERA TESTER User Manual Content 1. Safety information ........................1 2. IP Camera Tester Introduction ....................2 2.1 General ...........................2 2.2 Packing list ..........................2 2.3 Function interface ........................3 3. Operation ............................6 3.1 Installing the Battery.......................6 3.2 Instrument connection ......................7 3.2.1 IP camera connection ......................7 3.2.2 Analog camera connection ....................8 3.2.3 HD Coaxial camera connection ..................9 3.2.4 HDMI and VGA input (* Optional) ................10...
  • Page 4 IP CAMERA TESTER User Manual 3.3.14 SDI Camera Test (*Optional ) ..................45 3.3.15 CVI camera test (*Optional)..................45 3.3.16 TVI camera test (* Optional) ..................52 3.3.17 AHD camera test (* Optional ) ..................53 3.3.18 NET TOOL PRO......................55 3.3.19 PoE power / DC12V 3A and DC 5V 2A USB power output ........62 3.3.20 DC 24V 2A power output....................63 3.3.21 Cable Test ........................64 3.3.22 RJ45 cable TDR test ....................65...
  • Page 5 IP CAMERA TESTER User Manual 3.3.42 System Setting......................94 3.3.43 File explorer ........................98 3.3.44 Audio test ........................100 4. Specifications .......................... 100 4.1 General Specifications ......................100 4.2 Optical power meter specifications ..................104 4.3 Visual fault locator specifications ..................105 5 .

  • Page 6: Safety Information

    1. Safety information ◆ The Rsrteng tester is intended to use in compliance with the local rules of the electrical usage and avoid to apply at the places which are inapplicable for the use of electrics such as hospital, gas station etc.

  • Page 7: Ip Camera Tester Introduction

    2. IP Camera Tester Introduction 2.1 General The Rsrteng 7 inch touch screen IP camera monitor is designed for maintenance and installation of IP cameras, analog cameras, 8MP TVI*, 8MP CVI*, 8MP AHD*, 8MP EX-SDI* cameras, as well as testing 8K H.265 /4K H.264 camera via mainstream, The 1280x800 resolution enables it to display network HD cameras and analog cameras in high resolution.

  • Page 8: Function Interface

    The RS485 data received indicator: it lights red while the data is being received The power indicator: it lights green while the tester is powered on by the adapter Menu key Confirm key Return/Close : Return or cancel while setting parameters of the menu Zoom in the image LED light switch WWW.RSRTENG.COM Page.3.
  • Page 9 IP CAMERA TESTER User Manual Top interface Bottom interface Left interface WWW.RSRTENG.COM Page.4.
  • Page 10 Cut-off button, when the instrument system is abnormal, press it to make the instrument power off immediately. After restarting the instrument with the power key, it can be restored to normal use Audio input Audio output and earphone interface WWW.RSRTENG.COM Page.5.

  • Page 11: Operation

    Notice: When the Charge Indicator turns off, the battery is approximately 90% charged. The charging time can be extended for about 1 hour and the charging time within 12 hours will not damage the battery. WWW.RSRTENG.COM Page.6.

  • Page 12: Instrument Connection

    LAN port, if the link indicator of the tester's LAN port is green and the data indicator flickers, it means the IP camera and the IPC tester are communicating. If the two indicators don't flicker, check if the IP camera is powered on or the network cable is not functioning properly. WWW.RSRTENG.COM Page.7.

  • Page 13: Analog Camera Connection

    PoE switch can receive the data via the the tester. Warning: PoE switch or PSE power sourcing equipment only can be connected to tester "PSE IN" port, otherwise will damage the tester. 3.2.2 Analog camera connection WWW.RSRTENG.COM Page.8.

  • Page 14: Hd Coaxial Camera Connection

    1) Connect the SDI camera's video output to the IP tester's "SDI IN" interface, the image will display on the tester. The tester only come with SDI input interface. There is no SDI output interface. 2) Connect the SDI camera or the speed dome RS485 controller cable to the tester RS485 interface. WWW.RSRTENG.COM Page.9.

  • Page 15: Hdmi And Vga Input (* Optional)

    The built-in HDMI output port can output the tester's imege to other monitors. Resolutions up to 4K 3840x2160 60fps are supported. 3.3 OSD menu Press the key 2 seconds to turn on Press the key again to turn off Short press the key to enter sleep mode, press it again to test. WWW.RSRTENG.COM Page.10.

  • Page 16: Drop-Down Menu

    IP Setting: Enter IP Settings interface. LAN INFO: Display network port or WIFI connection real-time upload and download speeds and other network parameters. TOUCH POINT: Display contact point place. NETWORK SPEED: Turn on WLAN net and displays current WLAN status. WWW.RSRTENG.COM Page.11.

  • Page 17: Short-Cut Menu

    You can long press any app in the all applications list, it will auto move to shortcut menu. If delete any app in the shortcut menu, please select a app and press several seconds, it will be deleted. WWW.RSRTENG.COM Page.12.

  • Page 18: Screen Capture

    Tap icon "Link Monitoring" at left corner on the screen to enter. It can detect instrument port rate 10/100/1000M, signal quality detection, upload and download speed, etc. in real time. It can be used to detect whether the network video access bandwidth of devices such as NVR is normal. WWW.RSRTENG.COM Page.13.
  • Page 19 IP CAMERA TESTER User Manual When using a four-core cable to connect to a Gigabit device, would prompt "the link limited". Advanced link monitor It is for monitoring CVBS loop, Ethernet statistics, error frame statistics, frame length etc WWW.RSRTENG.COM Page.14.

  • Page 20: Testerplay

    At this time, the mobile phone will display the real-time screen projection of the Tester, and you can touch the screen to control the Tester. (If the screen is not displayed, please quickly slide the left menu of the Tester interface system settings or switch the Tester interface) WWW.RSRTENG.COM Page.15.

  • Page 21: Ip Discovery

    Tester. (The phone can also install VLC player for screen projection viewing) IP discovery 3.3.6 Press IP discovery , tester auto-scan the whole network segment IP, as well as auto-modify the tester's IP to the same network segment with the scanned camera's IP. WWW.RSRTENG.COM Page.16.

  • Page 22: Ipc Test Pro

    IP, and auto-modify tester's IP address, greatly improved engineering efficiency . IPC Test pro 3.3.7 Camera test often need to open multiple apps, "IPC Test pro" app, using new technology and combine multiple functions to one APP, it can increase efficiency. WWW.RSRTENG.COM Page.17.

  • Page 23: Rapid Onvif

    It lists cameras name and IP address on the Left of screen. Tester can auto login camera and display camera image. Factory default use admin password to auto login, if you modified the password, then default use the modified password to login. WWW.RSRTENG.COM Page.18.
  • Page 24 Click the button “Refresh”, tester will scan the ONVIF camera again. Click the newly displayed ONVIF camera on the “Device List”. The tester will show the IP camera’s relative information and settings. Pop-up settings menu when click the icon of the upper left corner WWW.RSRTENG.COM Page.19.
  • Page 25 Stretch two fingers outward or inward on the touch screen to zoom the image in or out. While in the “Live video” menu, click “Video Menu” at the top right of the image to access the following tools: Snapshot, Record, Photo, Playback, PTZ and Settings WWW.RSRTENG.COM Page.20.
  • Page 26 PTZ rotation direction is displayed on top left corner of the image. IP camera video settings: Click “Video Set” to enter the IP camera’s encoder and resolution settings. Make the desired changes and click “OK” to save. WWW.RSRTENG.COM Page.21.
  • Page 27 Profiles: Click “profiles"，can view video streaming current configuration files, as well as switch between Major stream and minor stream . Preview pictures: Quickly preview and zoom in or out pictures, automatically and manual refresh Identification: click “Identification” to view information of the camera WWW.RSRTENG.COM Page.22.
  • Page 28 IP CAMERA TESTER User Manual Time set: click “Time set”, Select " Manual set" to set up the time of camera WWW.RSRTENG.COM Page.23.
  • Page 29 IP CAMERA TESTER User Manual Maintenance: For camera software reset or restore to factory settings. Network setting:Click “Network Set” to change the IP address. Some cameras cannot support change IP address, so there is no change after saving. WWW.RSRTENG.COM Page.24.
  • Page 30 This is greatly helpful for the installers to ensure the IP camera’s video coverage and decide the IP camera’s install site. Image can only be enlarged on SD mode (The icon “ONVIF” is SD mode.) WWW.RSRTENG.COM Page.25.
  • Page 31 Click on the “Stop” icon to stop recording and save the video file to the TF card. Playback: Click the “Playback” icon to view saved videos. Double click the video you want to play. Click to return to the last menu WWW.RSRTENG.COM Page.26.
  • Page 32 To rename or delete a photo, click and hold on the file until this screen appears: Video files can play in the Video player on the main menu. Modify channel name: clicking “OSD” will pop up OSD settings, including time, channel name and other optional items. WWW.RSRTENG.COM Page.27.
  • Page 33 Set preset position: Move the camera to preset position, enter the preset number on the Bottom right corner to complete position preset. Call the preset position: Select the preset number on the left, click "Call" to call preset WWW.RSRTENG.COM Page.28.
  • Page 34 IP CAMERA TESTER User Manual PTZ Speed set: Horizontal and Vertical Speed set RTSP: Get RTSP address of the current camera Doc: Auto generate test reports document of camera, click “generate document”. Click Preview to view the report document WWW.RSRTENG.COM Page.29.
  • Page 35 IP CAMERA TESTER User Manual Enter the camera test information, click "Create Document" to complete the report. Click doc menu again, you can preview the report document. Icons description: the description of function icons on the bottom toolbar WWW.RSRTENG.COM Page.30.

  • Page 36: Non-Onvif

    "Manual": Click IP camera type, list Honeywell, Kodak, Tiandy, Aipu-waton, ACTi, IP camera etc. If the brand has offered official original protocols, please select camera type, input IP camera address, user name and password, click "official" to enter the camera image display interface(Currently, only support DAHUA official protocols) WWW.RSRTENG.COM Page.31.
  • Page 37 IP address. If the tester is connected to a PoE switch, it will find and display several IP address. IPC User Name: Enter IP camera's user name. IPC Password: Enter IP camera's login password. IPC Port: When you select the IP camera type, it will default the camera's port number and doesn't WWW.RSRTENG.COM Page.32.

  • Page 38: Hdmi And Vga ( *Optional )

    When tester receives HDMI in image, the top tool bar shows the resolution of this image. You can select "resolution" to set resolution in the setting menu. Tap screen by twice, full image display. Support resolution up to 4K 3840× 2160P 24/25/30fps, 2K 2560× 1440P 60fps, 1920× 1080P WWW.RSRTENG.COM Page.33.
  • Page 39 Click the icon "Snapshot", when the video in, to take a picture and save the current video frame in the SD card as JPEG file. If the unit is set to the manual mode an "Input Name" pop up box will appear and you can enter a title WWW.RSRTENG.COM Page.34.
  • Page 40 Chinese character, English letter or digit) to store in TF card, tester will hereby store the files in TF card after recording. if select "Auto-storage", tester will auto store the files in TF card after recording. WWW.RSRTENG.COM Page.35.
  • Page 41 Click the "Playback" icon to view your recorded videos. Tap on the video file image you want to watch. To rename or delete a video, click and hold on the file until this screen appears: Video files also can play in the main menu "Video Player". WWW.RSRTENG.COM Page.36.

  • Page 42: Analog Camera Test

    Use the up and down arrow keys to move the yellow cursor to the "protocol", set corresponding Protocol and support more than thirty PTZ protocols. Such as Pelco-D, Samsung, Yaan, LiLin, CSR600, Panasonic, Sony-EVI etc. B. Port Click and move to "port" Select the communication port for the PTZ camera controlling (RS485) WWW.RSRTENG.COM Page.37.
  • Page 43 To control PTZ by screen touch: Tap left, right, upward and downward on the touch screen to control the PTZ rotation direction. By two fingers move outward and inward on the touch screen to zoom in and out the PTZ. WWW.RSRTENG.COM Page.38.
  • Page 44 Using the touch screen to control PTZ camera movement: Tap left, right, upward or downward on the video image to move the PTZ camera in a desired direction. Stretch two fingers outward or inward on the touch screen to zoom the image in or out. WWW.RSRTENG.COM Page.39.
  • Page 45 Chinese character, English letter, or digit) to store in SD card, tester will hereby store the files in SD card after recording. if select "Auto-storage", tester will auto store the files in SD card after recording. WWW.RSRTENG.COM Page.40.
  • Page 46 (7) Recorded video playback Click the "Playback" icon to view your recorded videos. Tap on the video file image you want to watch. To rename or delete a video, click and hold on the file until this screen appears: WWW.RSRTENG.COM Page.41.

  • Page 47: Auto Hd ( *Optional )

    3.3.12 Auto HD ( *Optional ) Auto-recognize the resolution and Auto-display the image of the connected camera. Support coaxial PT Z control and call OSD menu, support up to 8MP TVI/CVI/AHD cameras. WWW.RSRTENG.COM Page.42.

  • Page 48: Hd Coaxial & Analog Level Test (* Optional )

    Reference value: The normal value at this resolution, it is used to reference and compare test results, click "value" to modify. Threshold: Critical value at this resolution. Lower this value, will appear image noise on the screen, click "value" to modify. WWW.RSRTENG.COM Page.43.
  • Page 49 IP CAMERA TESTER User Manual Reset: Click "Reset" to reset the reference value and threshold. Create documents: The testing report can save customer information, level meter test information, camera information and Instrument information. WWW.RSRTENG.COM Page.44.

  • Page 50: Sdi Camera Test (*Optional )

    HD CVI camera, CVI dome camera test and PTZ control, click icon to enter When HD CVI signal input, the tester will display the image resolution on the top bar. Double-taps on the screen to make the image displayed full screen. WWW.RSRTENG.COM Page.45.
  • Page 51 1920x1080P 30FPS/2560x1440P 25FPS/2560x1440P 30FPS/ 2592x1944P 20FPS / 2960x1920P 20FPS / 3840 x 2160P 12.5/15 FPS (1)PTZ control 1.1 Coaxial PTZ control Click the icon "PTZ" on the right toolbar to do the corresponding setting. "Port": select coaxial control WWW.RSRTENG.COM Page.46.
  • Page 52 Tap left, right, upward and downward on the touch screen to control the PTZ rotation direction, PTZ cameras will rotate accordingly. By two fingers move outward and inward on the touch screen to zoom in and out the PTZ. WWW.RSRTENG.COM Page.47.
  • Page 53 Setup preset position, move the PTZ camera to the preset position, the Tap it and input preset position number. Tap "Set position" to complete set preset position. Call preset position Tap the preset position: Tap the preset position area, input preset position number. Tap "call position" to complete call preset position. WWW.RSRTENG.COM Page.48.
  • Page 54 IP CAMERA TESTER User Manual 1.2 RS485 control Operation instructions, please refer to "3.3.1 PTZ (1) PTZ control parameters setting". (2)Coaxial camera menu setting Tap icon "UTC", select "menu setting" to enter the dome camera menu. WWW.RSRTENG.COM Page.49.
  • Page 55 IP CAMERA TESTER User Manual Input calling dome camera menu address code, after finishing the parameter settings, you can click the “enter menu” icon to call the dome camera menu. WWW.RSRTENG.COM Page.50.
  • Page 56 Tap "close menu" to close camera menu. (4) Save setting Click icon "Set" on the right toolbar to enter storage setting. Support auto-storage and manual storage. When select manual storage, user can name and store the files. WWW.RSRTENG.COM Page.51.

  • Page 57: Tvi Camera Test (* Optional)

    1920x1080P 25FPS / 1920x1080P 30FPS / 1920x1080P 50FPS / 1920x1080P 60FPS //2048x1536P 18FPS/2048x1536P 25FPS/2048x1536P 30FPS /2560x1440P 15FPS/2560x1440P 25 FPS/2560x1440P 30FPS/2688x1520P 15FPS/2592x1944P 12.5FPS/2592x1944P 20FPS/3840 x 2160P 12.5/15 FPS Coaxial camera menu settings Tap icon "UTC", select "menu setting" to enter the dome camera menu. WWW.RSRTENG.COM Page.52.

  • Page 58: Ahd Camera Test (* Optional )

    AHD camera, AHD dome camera test and PTZ control, Click icon to enter The tester supports resolution as follows: 1280x720P 25,30FPS / 1920x1080P 25FPS / 1920x1080P 30FPS/2048x1536P 18,25FPS/2048x1536P 30FPS /2560x1440P 15 FPS/2560x1440P 25,30 FPS/2592x1944P 12.5,20FPS/3840 x 2160P 15FPS WWW.RSRTENG.COM Page.53.
  • Page 59 UTC control: select "PTZ control or PTZ control-2"(AHD camera has two different order, if select "PTZ" cannot control, please go "PTZ-2") If to coaxial PTZ control the AHD camera, no parameters setting is needed. More operation instructions please refer to "3.3.6 CVI camera test" WWW.RSRTENG.COM Page.54.

  • Page 60: Net Tool Pro

    Connect the cable to the LAN port. Set your IP address search range by changing the Start and End IP addresses. Click the "Start" button to scan the IP address range. You can also input an IP address in the Port Number Scan to scan for open ports. WWW.RSRTENG.COM Page.55.
  • Page 61 To use the Network tester, you will need two IP testers. One is used as a Server and the other as a Client. Both devices must be on the same network segment in order to communicate. Click the icon to open the Network Tester app. WWW.RSRTENG.COM Page.56.
  • Page 62 Start send packet test: Using the other IP tester, type in the Server's IP address at the top right corner of the screen. This app is used to send packets for network speed testing. Click the "Start" button to send the packets and start testing. WWW.RSRTENG.COM Page.57.
  • Page 63 IP address. Input Server's IP address 192.168.0.39 in the tester and click "Start" to test network bandwidth. Or use tester as a Server, computer as test Client (select Client, input tester's IP address to test) WWW.RSRTENG.COM Page.58.
  • Page 64 Click "Start". The IP tester sends a unique signal to make the connected LAN port of the switch flash. If the tester and PoE switch are connected well, the LAN port of POE switch flash at special frequency, If not, no any changes on the LAN port WWW.RSRTENG.COM Page.59.
  • Page 65 Click on the DHCP icon to open the DHCP server app. Select the "Start" check box at the top and make any desired changes to the network settings. Click "Save" to start assigning dynamic IP addresses for IP cameras and other networked devices. Click the "Refresh" button to check your Client list. WWW.RSRTENG.COM Page.60.
  • Page 66 Link Monitor list, click "Start". If the IP address status shows a check mark the IP address is occupied. If the IP address status shows an X the IP address is available. Click "Stop" to stop the testing WWW.RSRTENG.COM Page.61.

  • Page 67: Poe Power / Dc12V 3A And Dc 5V 2A Usb Power Output

    Supports PoE, the PoE power is delivered via pins 1, 2, 3, and 6 ； 4, 5, 7 and 8 on the LAN port. The IP tester will Display "48V ON" at the top of the screen when the POE power is still on. Note: WWW.RSRTENG.COM Page.62.

  • Page 68: Dc 24V 2A Power Output

    Notice: a. Don't input any power into the "DC24V/2A OUTPUT" port of the tester to avoid destroy. WWW.RSRTENG.COM Page.63.

  • Page 69: Cable Test

    The number of the cable tester is 255. If need several different number other types cable testers, should pay the additional cost. WWW.RSRTENG.COM Page.64.

  • Page 70: Rj45 Cable Tdr Test

    3.3.22 RJ45 cable TDR test Connect cable to tester's LAN port, click icon " " to enter RJ45 cable TDR test app. Single test: Test cable status, length and attenuation. Repeat test: Continue to test cable status, length and attenuation. WWW.RSRTENG.COM Page.65.
  • Page 71 Skew: After 1000M link up, when skew value is 0ns, it is the best quality communication, if over 50ns, will cause a Bit Error Rate in the transmission. Cable sequence diagram: A straight- through and cross-over cable diagram, the cable sequence display for reference. WWW.RSRTENG.COM Page.66.
  • Page 72 IP CAMERA TESTER User Manual Click "Help" to check the instruction of all parameters. WWW.RSRTENG.COM Page.67.

  • Page 73: Cable Tracer (*Optional )

    Press the "MUTE" button of cable tracer for 2 seconds. After the "Di" sound, the silent mode is turned on. In the silent mode, can judge cable type according to the indicator light. Press the "MUTE" button again to exit the silent mode. WWW.RSRTENG.COM Page.68.

  • Page 74: Tdr Cable Test (*Optional)

    Connect Alligator clip cable to the TDR port, and the cable must connect well before testing, otherwise it will influence the accuracy. Built-in BNC cable, network cable, RVV control cable, Telephone line and TVVB cable etc. can test. 11 groups user-defined cable can be set. WWW.RSRTENG.COM Page.69.
  • Page 75 Click "Cable" "Type" to select cable and start testing. One tap on "Start", do one testing. If select built in cable type for testing, click "+" and "-" to adjust cable's wave speed. WWW.RSRTENG.COM Page.70.
  • Page 76 "BNC", if testing communication cable 75-2, select SYV 75-2. 3. Click "+" or "-" to adjust wave speed, while display length is the same with the actual Length, click "Save" to save calibration data. It can be used for the same cable testing next time. WWW.RSRTENG.COM Page.71.

  • Page 77: Poe Voltage Test

    Connect a network cable from a PoE switch to the IP tester's PSE IN port. Connect an IP camera or other PoE using node to IP tester's LAN port, the PoE voltage and the cable's pin connection status show on the screen. WWW.RSRTENG.COM Page.72.

  • Page 78: Power Input Test

    Warning: Not allow connect device with input power over 17V to tester "12V IN" port, otherwise it will damage the machine. WWW.RSRTENG.COM Page.73.

  • Page 79: Optical Power Meter (*Optional)

    While testing, set the wavelength for measurement. Click "relative"(difference) to test, the tester Auto save current fiber power value as the base reference value. Input another optical fiber to be measured, the displayed new measurement and relative value is red color. Press it again to quit. WWW.RSRTENG.COM Page.74.
  • Page 80 IP CAMERA TESTER User Manual Data hold and Relative measuring use together, the data is yellow while the function is effect. WWW.RSRTENG.COM Page.75.

  • Page 81: Visual Fault Locator (*Optional)

    30mins, 60mins and 120mins). Click "Steady mode", red laser source emits steady, click again to quit. Click icons "Evasive 1Hz"or "Evasive 2Hz" to enter pulse mode, the red laser source is emitted by a certain frequency, press it again to quit WWW.RSRTENG.COM Page.76.

  • Page 82: Audio Record

    Controller can check the status of the RS485 transmission through the code on the display. (The RS485 communication rate must be the same.) Application: Check the RS485 communication states of the video optical transmitter whether normal. Engineer can analyze the protocol and check the data through the displayed code. WWW.RSRTENG.COM Page.77.

  • Page 83: Audio Player

    SD card. Click on the desired file to play. Click RETURN to exit. To rename or delete an existing file, press the file name for a few seconds until the screen below appears. You can then rename or delete the file by pressing the desired option. WWW.RSRTENG.COM Page.78.

  • Page 84: Rtsp Player

    From the main menu, select the "APP Tool" folder and then select the "RTSP Player" to open the app. If the IP camera uses MJPEG, select the RTSP icon. If the IP camera uses H.264, select the "RTSP HD" icon. WWW.RSRTENG.COM Page.79.

  • Page 85: Hik Test Tool

    Hik test tool app is design for activating and debugging Hikvision camera, can auto-identify inactivated hikvision camera, also can display image from the Hikvision camera. Tap icon to enter 1. Activation: Select left [online detection] to display the "inactivated" camera and click activate. WWW.RSRTENG.COM Page.80.
  • Page 86 Play: Security status shows the "activated" camera. Enter the correct camera password in the right [password] and click [play] to pop up the "private protocol" or "speed ONVIF" two options. Select the protocol you need to see the camera images. WWW.RSRTENG.COM Page.81.
  • Page 87 Click "OK" and the effects will appear. Press return key or click any area of the screen to return to the upper layer of the interface. Modify network information: Support "modify" and "batch modify" camera IP address, subnet mask WWW.RSRTENG.COM Page.82.
  • Page 88 IP CAMERA TESTER User Manual and other parameters modification. Enter a new IP address and subnet mask, the default gateway will be auto modified according to the IP address. Click "OK" to save the changes. WWW.RSRTENG.COM Page.83.

  • Page 89: Dahua Test Tool

    3.3.35 Dahua test tool Dahua test tool is developed for installation and debugging of the Dahua IP camera, it can display image, and modify IP, user name and password etc. Making Dahua camera test more convenient and quickly. WWW.RSRTENG.COM Page.84.
  • Page 90 IP CAMERA TESTER User Manual Activation: select left [online detection] to display the "inactivated" camera and click activate. Activate and Batch activate are optional, support reserved phone number for resetting password. WWW.RSRTENG.COM Page.85.
  • Page 91 IP CAMERA TESTER User Manual Play: When mode display "activated" camera, input correct password, click "Play" poping up "private protocol" and "ONVIF", Select correspond protocol to view the camera image. WWW.RSRTENG.COM Page.86.
  • Page 92 After selected Channel name, can edit channel name, modify the display position and font size. If select "Default position" of Content location, then no need to modify. If select "customize", then can modify Channel name and display position, click "OK" to view the image. Click "Back" or button to return previous interface. WWW.RSRTENG.COM Page.87.
  • Page 93 IP CAMERA TESTER User Manual Modify Network: Support Modify and batch modify two ways, can modify camera IP address, Subnet mask and gateway. Input new IP address, need to input password, click "OK" to save the modification WWW.RSRTENG.COM Page.88.

  • Page 94: Update

    Other settings information is factory reset. 3.3.36 Update Copy the downloaded update file to SD card "update" directory, if no directory, please create one. Click the icon to open the Update menu. Select "Local Update" to update via the SD card or WWW.RSRTENG.COM Page.89.

  • Page 95: Office

    Update online: Before using online update, need enter settings-user management to register first. System update: Connect the Internet to update systems. 3.3.37 Office Quick office app (support excel, word, ppt format) doc. editable WWW.RSRTENG.COM Page.90.

  • Page 96: Led Flashlight

    NOTE: You will not be able to view live video in the web browser. For viewing video, use the IP tester's live camera view Apps The IP camera and IP tester be on the same network segment for the browser to interface with the WWW.RSRTENG.COM Page.91.

  • Page 97: Notepad

    Notepad can auto record the storage date and time. Please click to view the notepad, all saving contents display. Click each record bar to show the details. Press the record bar for several seconds, prompt whether delete it. WWW.RSRTENG.COM Page.92.

  • Page 98: Professional Wifi Analyzer

    IP CAMERA TESTER User Manual 3.3.41 Professional WIFI Analyzer Detect the surrounding wifi signal and signal strength, support 2.4G frequency band. Access point list and List format, display WIFI's channel, frequency, signal strength, device information and distance, etc. WWW.RSRTENG.COM Page.93.

  • Page 99: System Setting

    Language: Select your desired language: Chinese, English, Polish, Italian, Korean, Russian, Spanish, Japanese, French, German, Turkish, Portuguese, Serbian, Czech, Vietnamese, etc. Typewriting: You can select typewriting or install other typewriting: Date/Time: Set the Date/time of the IP tester WWW.RSRTENG.COM Page.94.
  • Page 100 WLAN Net: Turn WiFi off or on by pressing the "Open the wifi" button. Once WiFi is turned on, and click connected WIFI, it will scan for wireless networks in your area. Select and press "WIFI" several seconds, to set static IP address. WWW.RSRTENG.COM Page.95.
  • Page 101 Wi-Fi hotspot: Input "SSID" name and "password", and then click "ok" to create Wi-Fi hotspot. Brightness: Set the desired brightness of the IP tester and adjust the sleep time settings. Volume: Set volume level SD Card: Displays SD Card Capacity. You can also format the SD card or unmount it before removing WWW.RSRTENG.COM Page.96.
  • Page 102 PTZ address scan: You can toggle the PTZ Address scan off or on before entering the " PTZ controller" app. This needs to be turned on in order to use the PTZ Scan feature of the PTZ app. WWW.RSRTENG.COM Page.97.

  • Page 103: File Explorer

    Restore the factory settings: If the tester to restore factory settings, all your personal files and apps will be removed. 3.3.43 File explorer Click "File" on the top bar tool, can select internal or external storage. Click on the upper right corner Icon"... ". will pop-up menu, you can select other operation or exit. WWW.RSRTENG.COM Page.98.
  • Page 104 IP CAMERA TESTER User Manual Browse It includes Music, Videos, Pictures, Documents, zip file etc. It is convenient to view and manager. FTP server You can choose internal or external SD card. Other operation details, Please refer to FTP settings. WWW.RSRTENG.COM Page.99.

  • Page 105: Audio Test

    You can test the audio input from audio pickup devices by connecting the audio pickup device to the IP tester with the supplied audio cable. 4. Specifications 4.1 General Specifications [*]Indicates Features supported by some models Brand Rsrteng Series IPC-7600 Plus Series IPC-7600 Plus IPC-7600C Plus IPC-7600ADH Plus IPC-7600CADH Plus IPC-7600ADHS Plus Models:...
  • Page 106 3840 x 2160P 25/30 fps, UTC control and call OSD menu 1 channel CVI input (BNC interface, resolution support 720P CVI video signal test 25/30/50/60fps,1080P 25/30fps,2560x1440P 25/30fps,2592x1944 20fps, *(Optional) 2960x1920 20fps,3840x2160 12.5/15 fps. UTC control & call OSD menu WWW.RSRTENG.COM Page.101.
  • Page 107 1280× 720P 60/50fps, 720× 576P 50fps, 640x480P 60fps RJ45 cable TDR test and cable quality test, to test cable pair status, RJ45 cable TDR test length, attenuation reflectivity, impedance, skew and other parameter. DC24V 2Apower Output DC24V/2A power to camera output WWW.RSRTENG.COM Page.102.
  • Page 108 CAT.III 1000V / CAT.IV 600V, CE Measures PoE switch voltage and displays pin configuration PoE/PSE voltage test Optical power meter Calibrated Wavelength(nm): 850/1300/1310/1490/1550/1625nm Power range(dBm): -70～+10dBm *(Optional) Visual fault locator Test fiber's bending and breakage ( SM and MM fiber) *(Optional) WWW.RSRTENG.COM Page.103.

  • Page 109: Optical Power Meter Specifications

    Dimension/Weight 203x140x47mm(8x5.5x1.85inch) / N.W. 940g(2.07lbs) 4.2 Optical power meter specifications -70～+10dBm Measure Range(dBm) Wavelength(nm) 850nm,1300nm,1310nm,1490nm,1550nm,1625nm Detector InGaAs ＜± 3%dB(-10dBm,22℃), ＜± 5%dB(full range,22℃) Uncertainly Display Resolution Linear:0.1% ; Nonlinear:0.01dBm -10～+50 Operating Temperature(℃) -20～+70 Storage Temperature (℃) FC/PC Connector type WWW.RSRTENG.COM Page.104.

  • Page 110: Visual Fault Locator Specifications

    The data above is only for reference and any change of them will not be informed in advance. You can get more information and support by: Website: www.rsrteng.com Sales department: sales@rsrteng.com After-sales service department: service@rsrteng.com Tel: +86-755-32974680 Thank you! WWW.RSRTENG.COM Page.105.
