INSTALLING THE CHUTE
1. Use the supplied hex wrench to
loosen the two bolts in the chute
housing and remove them (Fig. 8).
2. Align the grooves of the chute with the
slot on the chute housing, and then
push the chute into place (Fig. 9).
3. Use the hex wrench to lock the chute
in place with the two bolts (Fig. 10).
WARNING:
rotation handle located at the operator's
position, make sure that the chute rotates
properly with the discharge opening never
crossing operator controls.
WARNING:
snow blower without the complete
discharge chute in place.
16
56V LITHIUM-ION CORDLESS SNOW BLOWER — SNT2100/SNT2100-FC
Using the chute-
Never operate the
8
9
Groove of the Chute
Slot on
the Chute
Housing
10
Chute
Housing
