4K Two-Way Talk & Siren Fixed Camera
User Manual
Thank you for purchasing our product. If there are any
questions, or requests, do not hesitate to contact the
dealer.
This manual applies to the models below:
This manual may contain several technical mistakes or
printing errors, and the content is subject to change
without notice. The updates will be added to the new
version of this manual. We will readily improve or
update the products or procedures described in the
manual.
Model
DS-2CE16U0T-LPTS
DS-2CE16U0T-LPXTS
DS-2CE16U0T-LTS
DS-2CE16U0T-LXTS
DS-2CE17U0T-LTS
DS-2CE17U0T-LXTS
DS-2CE19U0T-LTS
DS-2CE19U0T-LXTS
DS-2CE78U0T-LPTS
DS-2CE78U0T-LPXTS
DS-2CE78U0T-LTS
DS-2CE78U0T-LXTS
User Manual
Advertisement
Table of Contents
Related Manuals for HIKVISION DS-2CE16U0T-LPTS
Summary of Contents for HIKVISION DS-2CE16U0T-LPTS
- Page 1 User Manual User Manual Thank you for purchasing our product. If there are any questions, or requests, do not hesitate to contact the dealer. This manual applies to the models below: Model DS-2CE16U0T-LPTS DS-2CE16U0T-LPXTS DS-2CE16U0T-LTS DS-2CE16U0T-LXTS DS-2CE17U0T-LTS DS-2CE17U0T-LXTS DS-2CE19U0T-LTS DS-2CE19U0T-LXTS...
-
Page 2: Legal Disclaimer
Any part of the Document, including text, pictures, graphics, etc., belongs to Hikvision. No part of this Document may be excerpted, copied, translated, or modified in whole or in part by any means without written permission. - Page 3 IN THE EVENT OF ANY CONFLICTS BETWEEN THIS DOCUMENT AND THE APPLICABLE LAW, THE LATTER PREVAILS. © Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved. Regulatory Information EU Compliance Statement This product and - if applicable - the supplied accessories too are marked with "CE"...
- Page 4 This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss.
-
Page 5: Overview Of Cables
If cleaning is necessary, use clean cloth with a bit of ethanol and wipe it gently. Do not aim the camera at the sun or extra bright places. The sensor may be burned out by a laser beam, so ... -
Page 6: Installation
2 Installation 0°~360 0°~360 ° ° 0°~360 0°~360° ° 0°~90° 0°~180° 0°~360 0°~360° ° 0°~360 0°~360° ° 0°~90° 0°~180°... - Page 7 0°~360° 0°~75° 0°~360° 0°~360° 0°~360° 0°~75° 0°~360° 0°~360° 0°~360° 0°~75° 0°~75° 0°~360°...
- Page 8 0°~355 -30°~30° ° 0°~75° 0°~360° 0°~355° 0°~75° 0°~360 ° 0°~75°...
-
Page 9: Waterproof Measures
3 Waterproof Measures If the camera is installed outdoor, you should use the waterproof tapes to waterproof the cables. Otherwise the cables might get wet or a short circuit occurs. Note: Waterproof tapes should be purchased separately. After routing and connecting the cables, use the waterproof tapes to wrap up the cables. -
Page 10: Video Format
VIDEO FORMAT EXPOSURE MODE ANTI-BANDING EXPOSURE BACK EXIT SAVE & EXIT LIGHTING MODE SMART/IR/WHITE LIGHT SMART IR THRESHOLD LIGHTING SETTINGS LEVEL BACK EXIT SAVE & EXIT IMAGE MODE WHITE BALANCE BRIGHTNESS CONTRAST SHARPNESS VIDEO SETTINGS SATURATION MAIN MENU BACK EXIT SAVE &... -
Page 11: White Light
4.2 EXPOSURE EXPOSURE MODE You can set the EXPOSURE MODE to GLOBAL, BLC, HLC, and DWDR. GLOBAL GLOBAL refers to the normal exposure mode which adjusts lighting distribution, variations, and non-standard processing. BLC (Backlight Compensation) BLC (Backlight Compensation) compensates light to the object in the front to make it clear, but this may cause over-exposure of the background where the light is strong. -
Page 12: Video Settings
THRESHOLD The higher the threshold is, the more sensitive the device is to dark environment. LEVEL You can adjust the maximum brightness of supplement light. 4.4 VIDEO SETTINGS Move the cursor to VIDEO SETTINGS and click Iris+ to enter the submenu. IMAGE MODE, WHITE BALANCE, BRIGHTNESS, CONTRAST, SHARPNESS, SATURATION and DNR are adjustable. -
Page 13: Audio Settings
SATURATION Saturation is the proportion of pure chromatic color in the total color sensation. Adjust this feature to change the saturation of the color. DNR refers to digital noise reduction. This function reduces noise in video stream. 4.5 AUDIO SETTINGS You can turn on or off the sound pickup function of the microphone under this sub-menu.
