User's Manual
Type B
1. Roll paper cover
2. Ribbon cassette cover
3. Control panel
4. Power supply switch
Epson Stampante ad
English
Type D
M00155900 EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the i TM-U220IIB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Epson i TM-U220IIB

  • Page 1 Neither Seiko Epson Corporation nor its affiliates shall be liable to the purchaser of this product or third parties for damages, losses, costs, or expenses incurred by purchaser or third parties as a result of: accident, misuse, or abuse of this product or unauthorized modifications, repairs, or alterations to this product, or (excluding the U.S.)
  • Page 2: Important Safety Information

    English Important Safety Information This section presents important information intended to ensure safe and effective use of this product. Read this section carefully and store it in an accessible location. The symbols in this manual are identified by their level of importance, as defined below.
  • Page 3: Safety Label

    English Do not place heavy objects on top of this product. Never stand or lean on this product. Equipment may fall or collapse, causing breakage and possible injury. Take care not to injure your fingers on the manual cutter • When you remove printed paper •...
  • Page 4 English Notes on Connecting the Power Supply Unit Be sure to use the correct power supply unit as listed below: TM-U220II (types A, B, and D) "AC adapter,C1", "PS-180" or "PS-190" Purpose of This Manual This manual provides information to operators of the TM-U220II to describe basic operations to enable safe and correct use of the printer.
  • Page 5: Downloading Drivers, Utilities, And Manuals

    Drivers, utilities, and manuals can be downloaded from one of the following URLs. For customers in North America, go to the following web site and follow the on-screen instructions. https://www.epson.com/support/ For customers in other countries and regions, go to the following web site: https://epson.sn Control Panel...
  • Page 6: Power Supply Switch And Power Supply Switch Cover

    CAUTION: Never turn the ribbon cassette’s feed knob in the opposite direction of the arrow marked on the cassette; otherwise the ribbon cassette may be damaged. Note: Use the EPSON ERC-38 ribbon cassette for your printer. 6 TM-U220II User’s Manual...
  • Page 7 English 1. Open the ribbon cassette cover by using the tabs on the sides of the cover. 2. Turn the knob two or three times in the direction of the arrow. 3. Insert the ribbon in the position shown in the illustration below and push the ribbon cassette down until it clicks.
  • Page 8: Inserting Roll Paper

    English 4. Again turn the ribbon cassette’s knob 2 or 3 times in the direction of the arrow and close the ribbon cassette cover. CAUTION: Be careful not to touch the print head with your fingers when turning the ribbon cassette knob because the print head is hot and you might be burned.
  • Page 9 English 3. Type A only: Open the unit by using the unit open lever. 4. Insert the roll paper. Note: Note the direction the paper comes off the roll. When using 2-ply roll paper, be sure that the top and bottom sheets are aligned at the paper exit.
  • Page 10 English 5. If you are not using a take-up spool, pull out a small amount of roll paper and close the roll paper cover; then tear off the paper with the manual cutter. You can skip steps 6 through 11. 6.
  • Page 11 English 8. Insert the end of the bottom paper (journal paper) into the paper take- up spool. 9. Insert the paper take-up spool in the printer. Be sure that the paper is aligned with the spool’s flange. 10. Feed the paper with the (FEED) button so that the paper is taken up by the spool.
  • Page 12: Replacing Roll Paper

    English Note: Do not open the roll paper cover during printing or paper feeding. When using the printer, be sure to cut the roll paper with the manual cutter after paper feeding is complete. Replacing Roll Paper 1. Open the roll paper cover by using the tab. 2.
  • Page 13: Troubleshooting

    English Troubleshooting Printing stops before all the lines are printed or the printer prints the same line repeatedly If the correct power supply unit is not used, the printer cannot operate correctly. Make sure the correct power supply unit is connected to the printer, referring to the table below: TM-U220II (types A, B, and D) "AC adapter,C1", "PS-180"...
  • Page 14: Removing Jammed Paper

    English 2. Use a ballpoint pen or tweezers to turn the knob of the autocutter in the direction indicated by the arrow until you see a round shaft in the hole. Removing jammed paper CAUTION: The print head becomes very hot during printing. Allow it to cool before you reach into the printer.
  • Page 15 English 2. If you have a printer, remove the take-up spool and open the Type A unit by using the unit open lever. 3. Remove the jammed paper. 4. Re-insert the roll paper and close the roll paper cover. TM-U220II User’s Manual 15...
  • Page 16: Dip Switch Tables

    English DIP Switch Tables DIP switch settings vary depending on the model in use. DIP switch type (US/STD) can be verified by performing a self-test. Use the following procedure to perform a self-test. 1. Make sure all covers are closed. 2.
  • Page 17 English 2. Remove the screw on the bottom of the printer to remove the DIP switch cover. 3. Use an object with a thin tip to set DIP switch settings. 4. Close the DIP switch cover and tighten the screw. TM-U220II User’s Manual 17...
  • Page 18 English US (for Type A printer) Serial interface (DIP Switch 1) Other interfaces (DIP Switch 1) Function Function Data receive error Ignored Prints “?” Auto line feed Enabled Disabled Receive buffer capacity 40 bytes 20 KB Receive buffer capacity 40 bytes 20 KB Handshaking XON/XOFF...
  • Page 19 English US (for Type B and Type D printer) Serial interface (DIP Switch 1) Other interfaces (DIP Switch 1) Function Function Printing mode Right side up Normal Printing mode Right side up Normal printing mode printing printing mode printing mode mode Receive buffer capacity 40 bytes...
  • Page 20 English Serial interface (DIP Switch 1) Other interfaces (DIP Switch 1) SW Function Function Data receive error Ignored Prints “?” Auto line feed Enabled Disabled Receive buffer capacity 40 bytes 20 KB Receive buffer capacity 40 bytes 20 KB Handshaking XON/XOFF DTR/DSR 3–7...
  • Page 21 English TM-U220II Specifications 9-pin serial impact dot matrix method Printing method Font A: 7 × 9, Font B: 9 × 9 Print font Font (standard) 7 × 9/9 × 9: Column capacity 76 mm: 40/33 (columns) 69.5 mm: 36/30 57.5 mm: 30/25 1.2 ×...
  • Page 22 *3: Be sure to use a safety-standards-applied power source that meets the following specifications. Rated output: 24 V/1.3–10.0 A, Maximum output: 240 VA or less *4: Average power under operating conditions used by Epson. Performance may vary depending on the operating conditions and model in use.
