Perlick HP15CI-L Instruction Manual

Self-contained clear ice maker

Hide thumbs

Table Of Contents

Quick Links

Download this manual

Self-Contained

Clear Ice Maker

INSTRUCTION MANUAL

PERLICK RESIDENTIAL UNDERCOUNTER

ICE MAKER MODELS

HP15CI-L(-R)(-W) - 15" Signature Series Clear Ice Maker

HA15CI-L(-R)(-W) - 15" ADA Compliant Clear Ice Maker

To prevent appliance damage and injury, read these

instructions thoroughly prior to installation.

Form No. Z2517

Rev. 04.29.25

1A7987-010

Table of Contents

Need help?

Do you have a question about the HP15CI-L and is the answer not in the manual?

Questions and answers

Summary of Contents for Perlick HP15CI-L

Page 1 Clear Ice Maker INSTRUCTION MANUAL PERLICK RESIDENTIAL UNDERCOUNTER ICE MAKER MODELS HP15CI-L(-R)(-W) - 15” Signature Series Clear Ice Maker HA15CI-L(-R)(-W) - 15” ADA Compliant Clear Ice Maker To prevent appliance damage and injury, read these instructions thoroughly prior to installation.
Page 2: Warranty Registration
WARNING Only qualified service technicians should install and service the appliance. To obtain the name and phone number of your local Perlick Certified Service Representative, visit www.perlick.com. No installation or service should be undertaken until the technician has thoroughly read this Instruction Manual.
Page 3: Table Of Contents
Important Safety Information ....................4 I. Specifications ........................9 A. Construction ........................9 B. Electrical and Refrigerant Data ................... 10 C. Dimensions/Connections .....................11 1. HP15CI-L(-R) ......................11 2. HP15CI-W......................12 3. HA15CI-L(-R) ......................13 4. HA15CI-W......................14 II. Installation Instructions ....................15 A.
Page 4: Important Safety Information
• No service should be undertaken until the federal or local regulations. technician has thoroughly read the Service Manual available at www.perlick.com. • Do not pierce or burn. All safety precautions must be followed. • Be aware that refrigerants may not contain •...
Page 5 • Do not store explosive substances such as lu attentivement le manuel d'entretien aerosol cans with a flammable propellant disponible sur le site www.perlick.com. in this appliance. Toutes les précautions de sécurité doivent • Check that cabling will not be subject être suivies.
Page 6 DANGER Continué • Vérifier que le câblage ne sera pas soumis • Les pièces doivent être remplacées à l'usure, à la corrosion, à une pression par des pièces similaires, de manière excessive, à des vibrations, à des arêtes à réduire au minimum le risque d'inflammation dû...
Page 7 WARNING The appliance should be destined only to • THE APPLIANCE MUST BE the use for which it has been expressly GROUNDED. The appliance is equipped conceived. Any other use should be with a NEMA 5-15 three-prong grounding considered improper and therefore plug to reduce the risk of potential dangerous.
Page 8 NOTICE WARNING continued • Test the drain pump operation every time • The appliance is not intended for use by the appliance is cleaned and sanitized. persons (including children) with reduced See "IV.D. Drain Pump" for details. physical, sensory, or mental capabilities, If the drain pump is not operating properly, or lack of experience and knowledge, water could back up and overflow, leading...
Page 9: Specifications
I. Specifications A. Construction Top Panel Ice Making Mechanism Bin Control Thermistor Scoop Holder Gasket (Magnet) Slope Front Panel Control Switch Door Power Cord Louver...
Page 10: Electrical And Refrigerant Data
The nameplate provides electrical and refrigerant data. The nameplate is located inside the ice storage bin. For certification marks, see the nameplate. We reserve the right to make changes in specifications and design without prior notice. Model Number HP15CI-L(-R)(-W) HA15CI-L(-R)(-W) AC SUPPLY VOLTAGE ~115/60/1...
Page 11: Dimensions/Connections
C. Dimensions/Connections 1. HP15CI-L(-R)
Page 12: Hp15Ci-W
2. HP15CI-W...
Page 13: Ha15Ci-L(-R)
3. HA15CI-L(-R)
Page 14: Ha15Ci-W
4. HA15CI-W...
Page 15: Installation Instructions
(operating or storage) Superficie Minimale du Local R-290 Refrigerant (service ou stockage) Model Charge g (oz.) m² (ft²); m² (pi²) HP15CI-L(-R)(-W) 65 g (2.3 oz.) 3.1 m² (33.5 ft.²) HA15CI-L(-R)(-W) 57 g (2.0 oz.) 2.7 m² (29.4 ft.²) ≥ Area m ) (see "Minimum Room Floor Area"...
Page 16 DANGER continued R-290 Refrigerant Charge: • If greater than 114 g (4 oz.), do not install in public corridor or lobby. • If greater than 152 g (5.3 oz.), do not install within 6 m (20 ft) of open flame. Charge de réfrigérant R-290: •...
Page 17: Built-In Installation Site
• Do not install the appliance in a corner where the door will interfere with other equipment or where the appliance cannot be pulled out for service. Installation Space Model Height Width Depth HP15CI-L(-R)(-W) 34" (864 mm) minimum 15" (381 mm) minimum 24" (610 mm) minimum HA15CI-L(-R)(-W) 32" (814 mm) minimum Between Two Cabinets...
Page 18: Checks Before Installation
B. Checks Before Installation • Visually inspect the exterior of the shipping container and immediately report any damage to the carrier. Upon opening the container, any concealed damage should also be immediately reported to the carrier. • Remove the shipping carton, tape, and packing material. If any are left in the appliance, it will not work properly.
Page 19: Hp15Ci-W, Ha15Ci-W Door
C. HP15CI-W, HA15CI-W Door 1. HP15CI-W, HA15CI-W a) Overlay Panel Fabrication and Attachment IMPORTANT The overlay panel must be crafted by a professional cabinet maker to ensure quality results. (1) Parts Ensure that all parts required for the overlay panel assembly are contained in the accessories bag.
Page 20 (2) Overlay Panel Specification Use the specification that applies to your appliance (HP15CI-W or HA15CI-W) and the directions that follow to prepare your overlay panel. (a) HP15CI-W HP15CI-2 Overlay Panel Specification Overlay Panel Height 29 17/32" (750 mm) Overlay Panel Width 14 13/16"...
Page 21 (b) HA15CI-W HA15CI-W Overlay Panel Specification Overlay Panel Height 27 9/16" (700 mm) Overlay Panel Width 14 13/16" (376 mm) Overlay Panel Thickness 5/8" (16 mm) minimum; 3/4" (19 mm) maximum Overlay Panel and Door Weight (total) 20 lb. (9 kg) maximum...
Page 22 Otherwise, the overlay panel cannot be properly fastened to the door. 4) Mount the door handle hardware. Perlick recommends that the door handle hardware be mounted on the edge opposite of the door hinge side (optional hinge reversal is covered in step 6).
Page 23 6) If you would like to reverse the door swing, do the following: a) Contact your local distributor to purchase Kit HS-0229. The kit contains "hinge (A)-left." b) Remove the 2 screws securing the top panel, then lift it off. See Fig. 4. c) Remove hinge (A)-right and the bracket from the right side of the unit.
Page 24 7) Remove the bushings from hinge (C1) and hinge (C2) (the hinges attached to the door). See Fig. 9. 8) Remove the gasket from the door. See Fig. 10. Bushing Gasket (Magnet) Hinge Fig. 10 Fig. 9 9) Temporarily fasten the overlay panel to the door using 2 of the M4×25 pan head screws provided.
Page 25 (4) Attachment of Overlay Panel to Door 1) Fasten the sheet metal bracket to the overlay panel using the two M4×8 truss head screws provided. Snug the screws, but do not tighten. See Fig. 13. 2) Temporarily fasten the overlay panel to the door using 2 of the M4×25 pan head screws provided.
Page 26 7) Tighten the four M4×25 pan head screws installed in step 5. See Fig. 19. 8) Replace the door gasket in its proper orientation. Reinsert the bushings into hinge (C1) and hinge (C2) (the hinges attached to the door). See Fig. 20. Bushing Tighten the screws.
Page 27: Setup
D. Setup 1) Position the appliance in the selected permanent location. 2) Level the appliance from side-to-side and front-to-rear by adjusting the feet.
Page 28: Electrical Connection
E. Electrical Connection WARNING • Electrical connection must meet national, state, and local electrical code requirements. Failure to meet these code requirements could result in death, electric shock, serious injury, fire, or severe damage to equipment. • This appliance requires an independent power supply of proper capacity. See the nameplate for electrical specifications.
Page 29: Water Supply And Drain Connections
• In areas where water damage is a concern, install in a contained area with a floor drain. • Water line installation to the appliance is not warranted by Perlick. • Water-hammer issues must be resolved by a qualified plumber before installing the appliance.
Page 30 • Drain line should not be piped directly to the sewer system. An air gap of a minimum of 2 vertical inches (5 cm) must be between the end of the drain pipe from the icemaker and the floor drain. •...
Page 31 c) Existing Drain Pipe Installation: When connecting to a suitable existing drain pipe (sink), the drain line must be installed in accordance with applicable national, state, and local codes and regulations. IMPORTANT! Confirm with local and state plumbing codes before connecting to an existing drain pipe. An air gap device (not included) may be required.
Page 32: Final Checklist
G. Final Checklist 1. Pre-Startup 1) Is the icemaker level? 2) Is the icemaker in a site where the ambient temperature is within 45°F to 100°F (7°C to 38°C) and the water temperature within 45°F to 90°F (7°C to 32°C) all year around? 3) Have the shipping carton, tape, and packing material been removed from the icemaker? Has the protective plastic film been removed from the panels? 4) Have all electrical and water connections been made? Do electrical and water...
Page 33: Operating Instructions
III. Operating Instructions R-290 Class A3 Flammable Refrigerant Used DANGER Risk of Fire or Explosion. Flammable Refrigerant Used. • Be sure to follow all Important Safety Information located at the beginning of this manual. • Failure to install, operate, and maintain the appliance in accordance with this manual will adversely affect safety, performance, component life, and warranty coverage and may result is costly water damage.
Page 34: Startup And Bin Control Check
B. Startup and Bin Control Check WARNING • All parts are factory-adjusted. Improper adjustments may adversely affect safety, performance, component life, and warranty coverage. • To reduce the risk of electric shock, do not touch the power switch, control switch, or plug (on corded models) with damp hands.
Page 35 9) Move the control switch to the "ICE" position to start the automatic icemaking process. 10) During the first 5 minutes of the freeze cycle (compressor energized), confirm bin control operation by holding ice in contact with the bin control thermistor. See Fig.
Page 36 16) Move the control switch to the "ICE" position. 17) Check the drain pump back-up safety switch: Pour another 24 to 30 oz. (710 to 890 ml) of water into the icemaker's ice storage bin, then completely restrict/block the appliance hard pipe drain line or the appliance vinyl tubing drain line while the drain pump is operating.
Page 37: Maintenance
IV. Maintenance This appliance must be maintained in accordance with the instruction manual and labels provided with the appliance. Consult with your local Perlick Certified Service Representative about maintenance service. WARNING • Only qualified service technicians should service this appliance.
Page 38: Cleaning And Sanitizing Instructions
B. Cleaning and Sanitizing Instructions This appliance must be cleaned and sanitized at least once a year. More frequent cleaning and sanitizing may be required in some water conditions. WARNING • To prevent injury to individuals and damage to the appliance, do not use ammonia type cleaners.
Page 39 5) Slowly pour the cleaning solution into the water tank. 6) Move the control switch to the "WASH" position. 7) Allow the cleaning solution to circulate for 30 minutes, then move the control switch to the "OFF" position. 8) Disconnect the suction tube. Allow the water tank to drain, then reconnect the suction tube.
Page 40 4) Disconnect the suction tube. Allow the water tank to drain. 5) Spread out the tabs to unlock the water tank, then slide it out. See Fig. 35. 6) Lift the ice chute up from the left and right brackets. See Fig. 36. Left Bracket Right Bracket Ice Chute...
Page 41 13) Position and lock the ice chute onto the left and right brackets by pushing the ice chute down until it clicks onto both brackets. See Fig. 41. 14) Slide in the water tank along the rails at the bottom of the left and right brackets until it locks into place.
Page 42: Ice Storage Bin Drain
C. Ice Storage Bin Drain In some conditions, slime may build up inside the ice storage bin drain and prevent water from draining properly. To prevent this buildup, perform the following procedure once every 3 months or as often as necessary for conditions. NOTICE If the ice storage bin drain becomes clogged, water could build up in the bin and overflow, leading to costly water damage.
Page 43: Condenser
E. Condenser Check the condenser once a year, and clean if required by following the steps below. More frequent cleaning may be required depending on location. WARNING • Move the control switch to the "OFF" position and unplug the icemaker from the electrical outlet before cleaning the condenser.
Page 44: Preparing The Appliance For Periods Of Non-Use
V. Preparing the Appliance for Periods of Non-Use WARNING Only qualified service technicians should service this appliance. NOTICE • During extended periods of non-use, extended absences, or in sub-freezing temperatures, follow the instructions below to reduce the risk of costly water damage.
Page 45: Decommissioning And Disposal
VI. Decommissioning and Disposal R-290 Class A3 Flammable Refrigerant Used DANGER Risk of Fire or Explosion. Flammable Refrigerant Used. • Be sure to follow all Important Safety Information located at the beginning of this manual and at the beginning of section "III.A. Safety Precautions When Servicing." •...
Page 46 The appliance contains refrigerant and must be disposed of in accordance with applicable national, state, and local codes and regulations. Refrigerant must be recovered and safely disposed of by properly trained service personnel. Before carrying out this procedure, it is essential that the technician is completely familiar with the equipment and all its detail.
Page 47 Follow the steps below for decommissioning and disposal: 1. Recovery 1) Recover the refrigerant, and safely dispose of the refrigerant. 2) Evacuate the appliance. 3) Purge the refrigeration system with nitrogen. 4) Cut out the compressor and drain and dispose of the compressor oil. Compressor oils are to be removed, ensure that they have been evacuated to an acceptable level to make certain that flammable refrigerant does not remain within the lubricant.
Page 48 © 2025 Perlick Corporation 8300 West Good Hope Road, Milwaukee, WI 53223, USA perlick.com • (800) 558-5592 Form No. Z2517 Rev. 04.29.25 1A7987-010...
