- Page 1 LED-F802Pro/F804Pro video control ser ver Instructions for User, V1.1 △ Before using the LED video control server, please read the instruction manual carefully and keep it properly for future reference. LED-F802Pro/F804Pro...
-
Page 2: Update Log
statement Without the written permission of the Company, no unit or individual shall imitate, copy, copy or translate part or all of the contents of this manual. This manual shall not be disseminated in any form or in any means (electronic, mechanical, photocopied, recorded,... -
Page 3: Table Of Contents
catalogue brief introduction .........................1 brand royalty ...............................1 About software ..............................1 product features ..............................2 safety instruction ............................... 3 function Introduction ........................4 summary ................................4 technical specifications ............................6 Use the menu ..........................8 Default status introduction ..........................8 Main menu introduction ..........................9 primary menu ..............................10 screen configuration ..........................10 Screen brightness: .......................... - Page 4 Time task management: ........................21 SOC update: ..............................22 Synchronous Lock Settings: ........................ 22 Warranty instructions ........................23 Complete machine warranty period ......................23 Non-warranty provisions ..........................23...
-
Page 5: Brief Introduction
brief introduction Thank you for purchasing our LED video control server. I hope you can experience the excellent performance of the product. The LED video control server is designed to comply with international, industry standards, but it can still cause personal injury and property damage. To avoid the potential hazards and benefit from your equipment whenever possible, follow the relevant instructions in this manual when installing and operating the product. -
Page 6: Product Features
The maximum single-load limit is 3840 pixels and up to 3820 pixels Support quick light-up screen, no need computer software connection Support the image interception function Support for connecting the MAGNIMAGE C-Link series receiving cards Support free cable connecting Support for single-machine network port backup ... -
Page 7: Safety Instruction
safety instruction The input voltage range of the power supply of this product is 100~2 40V, and 50 / 60Hz. Please use the correct power supply. When you want to connect or remove any signal or control lines, confirm that all power cords have been removed previously. When you want to add the hardware device to this product or when you want to remove the hardware device from this product, please confirm that all the signal lines and power cables have been removed previously. -
Page 8: Function Introduction
Function Introduction summary LED-F802Pro / F804Pro is a video controller with video processor and transmission card as one launched by MAGNIMAGE. Video image input interface includes 3 x HDMI 1.4；1 x USB, supporting full HD signal input; LED-F802Pro with 1.96 million pixels with 2 gigabit port output;... - Page 9 2-LCD screen, display the menu content 3-knob button and return button 4-HDMI 1, HDMI 2, HDMI 3, USB input keys and LOCK keys 5-Company LOGO LED-F802Pro / F804Pro rear panel: LED-F802Pro： LED-F804Pro： 1-2 / 4 road gigabit network port output...
-
Page 10: Technical Specifications
3820 pixels Gigabit Single network port load 0.98 million pixels network port LED-F802Pro whole unit load 1.96 million pixels LED-F804Pro whole unit load 3.92 million pixels Refresh rate: 23-60Hz AUDIO OUT Support HDMI, U disk audio separation output... - Page 11 Complete machine specification Enter the power supply 100-240V AC~50/60Hz 0.6 A working temperature 0-45℃ outline dimension 482.6×217.5×43 mm （L×W×H） net weight 2.9 KG Complete machine power consumption...
-
Page 12: Use The Menu
Use the menu The menu system using the product can be convenient and intuitive to set the local machine to meet the user's requirements. The LED video control server uses a full-color LCD display to display the entire user menu. When the user has no operation or the operation timeout. If the keys in the front panel of the machine are used to set the machine, the LCD screen will display the corresponding menu according to the user's operation to prompt the user to conduct better, faster and more intuitive... -
Page 13: Main Menu Introduction
Serial number of the network port 1-4, when the network port is Port number connected to the network cable, the interface network port icon is displayed in green Press the lock icon, and press the LOCK button to unlock it Main menu introduction The various symbols listed in the following table will appear in the main menu, as shown in the following table:... -
Page 14: Primary Menu
primary menu In the non-menu state, press the "Menu / confirm" button, the menu system will enter the main menu state, the LCD screen As shown in the following below: There are 4 sub-menu items in the main menu. Rotate the knob left and right to select the 4 sub-menu titles listed above. -
Page 15: Output Settings
Output Settings: Quick screen: Manual screen: brightness Adjust the brightness of LED display, 0~256 (0%~100%) Custom output resolution, limit width of 3840 pixels and limit height of 3820 pixels Minimum value of 128, screen horizontal horizontal Output resolution width pixels Settings Output vertical... -
Page 16: Rx Card Pattern
Apply the currently set parameters for the apply output Restore the default 1920X1080 60Hz output reset resolution horizontal The window displays the horizontal position position parameters upright The window displays the vertical position position parameters output Horizontal The window displays the horizontal width window width parameter... -
Page 17: Tx Card Reset
card The default is off state, test screen 1-10 options Pattern When the box mark is opened, the large screen will display the network Cabinet port number and receiving card number of each box, so as to make the Mapping connection diagram intuitively Cabinet mapping (MAPPING) diagram: Description: The number in the upper left corner is the network port number, and the middle number is... -
Page 18: Local Backup
Local backup: Bandwidth extension: TxCard reset Reset the sending card connecting screen parameters Reset the reception card brightness, color temperature, and Gamma Rxcard reset parameters Local backup Specify the network port backup within a single machine The default is on. This function requires the receiving card to support Bandwidth bandwidth expansion. -
Page 19: Image Crop
Image crop: color Adjust the input RGB range, the default automatic state, can be set to range "16-235" and "0-255" state horizontal The minimum value is 0 and the maximum value is the difference between Horizontal Width minus Horizontal Width position vertical The minimum value is 0 and the maximum value is the difference... -
Page 20: Edid Setting
horizonta upright l position position Horizont vertical al width height horizonta 3840 Vertical benchma reference Interception the resulting picture EDID setting: Input audio:... -
Page 21: U-Disk Media Control
U-disk media control: EDID Supports the 3-way HDMI input EDID settings Support input audio switch, and audio output volume adjustment, default input audio volume 64, volume parameter range 0-64 HDMI 1 key is to switch forward key, switch on a video / picture to play disk The HDMI 2 button is a pause button to pause the current... -
Page 22: U-Disk Playback Operation Process
Note: After setting the EDID parameters, different computer or graphics card types may need to restart the computer or unplug the signal line. Select the corresponding resolution in the display Settings menu of the computer. U-disk playback operation process: 1. The U disk format supports three formats: FAT 16, FAT 32 and NTFS; 2. -
Page 23: Image Settings
Description: U disk playback supports 1080 P @ 30 fps video files picture JPG、BMP、PNG、JPEG format MPEG 1 / 2, MPEG 4, SorensonH.263, H.263, H.264 (AVC 1) H.265 (HEVC), Video RV30 / 40, Divx, and Xvid format MPEG 1 / 2 LayerI, MPEG 1 / 2 LayerII, MPEG 1 / 2 LayerIII, AACLC, VORBIS, Audio PCM, and FLAC format... -
Page 24: Functional Options
Color-temperature rendering diagram: Warm colors are normal and cool colors Functional options: Key lock: factory reset: Output Pattern Support output card test, support 10 card test styles Output black Show the current output on a black screen Output freeze Freeze the current frame of the device output screen Support device key lock, short press LOCK button to lock and unlock Key lock the operation... -
Page 25: Time Task Management
Time task management: Time Set the time and date of the machine itself setting Can set 10 time tasks, can be edited separately, select a trigger time, and then select the trigger time point screen brightness ,task operation:Once;Every day; Period; Period time range 1-480 minutes. -
Page 26: Soc Update
SOC update: Synchronous Lock Settings: Upgrade the SOC file (file suffix. Bin) copy to the U USB mode disk inserted into the device’s USB interface to update the SOC program SOC update ISP (In-System Programming) mode, upgrade SOC ISP mode program with SOC dedicated burner, and open ISP mode when burning The default is "off"... -
Page 27: Warranty Instructions
Warranty instructions Complete machine warranty period 12 months from the date of the users purchase invoice; If the user purchase invoice is lost, the 60 days after the production date of this product is the warranty start date for that product. Non-warranty provisions Fault or damage caused by other abnormal use reasons, such as ...
