S e r v i c e L i t e r a t u r e
ML193DFEK series units are high-efficiency gas furnaces
manufactured with Lennox DuralokPlus aluminized steel
clamshell-type heat exch angers, with a stainless steel
condensing coil. ML193DFE units are available in heating
input capacities of 44,000 to 88, 000 Btuh and cooling ap-
plications from 1.5 to 4 tons.
Refer to Engineering Handbook for proper sizing.
Units are factory equipped for use with natural gas. A kit
is available for conversion to LPG operation. All ML193D-
FE units are equipped with a hot surface ignition system.
The gas valve is redundant to assure safety shut-off as
required by C.S.A.
The heat exchanger, burners and manifold assembly can
be removed for inspection and service. The maintenance
section gives a detailed description on how this is done.
The ML193DFEK can be "twinned" with a second unit.
Two units to operate as one, in a shared duct system con-
trolled by a single thermostat.
All specifications are subject to change. Procedures out-
lined in this manual are presented as a recommendation
only and do not supersede or replace local or state codes.
WARNING
Electric shock hazard. Can cause injury
or death. Before attempting to perform
any service or maintenance, turn the
electrical power to unit OFF at disconnect
switch(es). Unit may have multiple power
supplies.

Table of Contents

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
. . . . . . . . . . . . . . . . . . . . . . . . . . 3
Twinning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
I-Unit Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
II Placement and Installation . . . . . . . . . . . . . . . . . . . . 24
III-Start-Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
IV-Heating System Service Checks . . . . . . . . . . . . . . 44
V-Typical Operating Conditions . . . . . . . . . . . . . . . . . 48
VI-Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
VII-Low GWP Application . . . . . . . . . . . . . . . . . . . . . . . . . .51
IX-Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..55
UNIT INFORMATION
UNIT INFORMATION
ML193DFEK WITH R454B SERIES UNITS
. . . . . . . . . . . . . . . . . . . . . . 4
. . . . . . .54
100162
Improper installation, adjustment, alteration, service
or maintenance can cause property damage,
personal injury or loss of life. Installation and service
must be performed by a licensed professional HVAC
instale (or equivalent), service agency or the gas
supplier.
This furnace is equipped with an ignition control
factory enabled for use with A2L refrigerant systems.
Disabling the refrigerant detection functionality on
A2L system is prohibited by safety codes. Refer
to furnace installation instructions for refrigerant
system setup.
As with any mechanical equipment, contact with
sharp sheet metal edges can result in personal
injury. Take care while handling this equipment and
wear gloves and protective clothing.
Page 1
ML193DFEK
WARNING
WARNING
CAUTION
