- Page 1 ® INJECTOR MODEL C-1500N 5300 Business Drive Huntington Beach, CA 92649 Phone: 714-893-8529 FAX: 714-894-9492 E mail: sales@blue-white.com or customerservice@blue-white.com www.Blue-White.com...
-
Page 2: Table Of Contents
C-1500N Page 2 TABLE OF CONTENTS SECTION HEADING PAGE Introduction Specifications C-1500N Features How to install the C-1500N Mounting location Electrical connections How to install the tubing and fittings How to operate the C-1500N Adjusting the Pump Output - Standard Models Adjusting the Pump Output - Fixed cycle timer Models Measuring the pump’s output - volumetric test How to maintain the C-1500N... -
Page 3: 1500N Features
C-1500N Page 3 C-1500N Features Double-ball ceramic check valves. PVDF (Kynar) valve assemblies. Viton o-rings. High outlet pressure capability of 125 PSIG.* Easy access, top mounted mechanical feed rate adjustment. Ball bearing supported motor drive shaft. Permanently lubricated ball bearing motor. 20:1 adjustment turn down ratio. - Page 4 Risk of chemical overdose. Be certain the WARNING pump does not overdose chemical during backwash and periods of no flow in the circulation system. Strainer Blue-White F-300 ® Circulation Pump Injector Filter Blue-White C-1500N ®...
- Page 5 C-1500N Page 5 Installation Instructions for the Electrical Connections 4.2.1 Input Power Connections Risk of electric shock. Be certain to connect the WARNING pump to the proper supply voltage. Using the incorrect voltage will damage the pump and may result in injury. The voltage requirement is printed on the pump serial label.
-
Page 6: How To Install The Tubing And Fittings
C-1500N Page 6 Cycle Adjustment Timer Potentiometer Board Common Input AC/LOAD Ground (green) Power LOAD JB2 JB3 Neutral Motor JB1, JB2, JB3 = Voltage Selector Jumpers Jumpers Configuration Install JB2 & JB3, (JB1 left open) = 24 V AC input (factory Setting) Install JB1 &... - Page 7 C-1500N Page 7 Discharge Tube (Rigid P.E.) Footvalve Adapter Tube Nut Suction Tubing O-Ring Outlet Adapter Ceramic Ball Ceramic Pump Head Weight O-Ring Inlet Adapter Footvalve Body FootValve Assembly Must be installed in a vertical position. DO NOT LAY ON SIDE! Tube Nut Footvalve Strainer Suction Tubing...
-
Page 8: How To Operate The C-1500N
C-1500N Page 8 How To Operate The C-1500N Adjusting the Pump Output- Standard models (fig. 5.1) - The C-1500N flow rate can be adjusted within a range of 5% -100% of maximum output (20:1 turndown ration) by means of a mechanical, cam type mechanism. The mecha- nism adjusts the pump’s stroke length to an infinite number of settings within the flow range. -
Page 9: 5.3 Measuring The Pump's Output - Volumetric Test
C-1500N Page 9 5.3 Measuring the Pump’s Output - Volumetric Test. This volumetric test will take into account individual installation factors such as line pressure, fluid viscosity, suction lift, etc. This test is the most accurate for measuring the injector’s output in an individual installation. 1. -
Page 10: Replacement Parts Drawing
C-1500N Page10 Replacement Parts Drawing... - Page 11 C-1500N Page 11 C-1500N PARTS LIST Item Part No Description C-535A6-6 Pumphead Kit, HDN Viton C-535A6-6E Pumphead Kit, HDN EP C-340A FootValve S/A, Aflas C-340E FootValve S/A, EP C-346 Ceramic weight C-535FC Cover P/Head, HD Chem-Feed logo C-535F Cover P/Head, HD Noir logo S-535F Cover P/Head, HD Micro logo C-504HD...
- Page 12 Stator S/A, 220V50Hz Thermal Brown-Yellow 70000-020 Stator S/A, 230V60Hz Standard Red-Black 70000-021 Stator S/A, 230V60Hz Thermal Red-Yellow C-615P-4 Stator S/A, 24V60Hz Standard Blue-White 90011-024 Ground Screw 8-32 x .25 Hex SL ST 90010-127 Lead Wire, ground, Green 90011-078 Washer, Ground Screw, #8 Intrl/Star...
- Page 13 C-1500N Page 13...
-
Page 14: Limited Warranty
Page14 Limited Warranty Your Blue-White product is a quality product and is warranted for a specific time from date of purchase (proof of purchase is required). The product will be repaired or replaced at our discretion. Failure must have occurred due to defect in material or workmanship and not as a result of operation of the product other than in normal operation as defined in the product manual. -
Page 15: Authorized Service Centers
Chemical Resistance Warning Blue-White offers a wide variety of wetted parts. Purchasers, installers, and operators of Blue-White products must be well informed and aware of the precautions to be taken when injecting or measuring various chemicals, especially those considered to be irritants, contaminants or hazardous. - Page 16 C-1500N Page16 Users of electrical and electronic equipment (EEE) with the WEEE marking per Annex IV of the WEEE Directive must not dispose of end of life EEE as unsorted municipal waste, but use the collection framework available to them for the return, recycle, recovery of WEEE and minimize any potential effects of EEE on the environment and human health due to the presence of hazardous substances.
