- Page 1 USB 2.0 Extender 1 x 1 EXP-USB-3000 User Manual Version: 20241024...
- Page 2 Cat.5/5e/6 cable up to 50 meters at data rate of High Speed (480Mb/s), Full Speed (12Mb/s)and Low Speed (1.5Mb/s) .Setting up the EXP-USB-3000 is quite simple. Using the RJ-45 Connector, plugging it in the connections without confusion or difficulty. It takes only minutes to setup, and there is no configuration necessary, like all USB hardware.
- Page 3 Features Support USB 2.0 (480Mb/s) Compatible with USB 1.1 full-speed ( 12 Mb/s ) ,low-speed ( 1.5 Mb/s ) USB devices Allows a USB device to have its cable length extended up to Support Hot Plug ...
-
Page 4: Structure Diagram
STRUCTURE DIAGRAM INSTALLATION 1. Connect the Local Unit to the Host System (or PC) via the supplied USB Cable on Local Unit. 2. Connect the USB 2.0 Extender Local Unit and Remote Unit together with a Cat.5, Cat 5e or Cat. 6 Cable (supplied by user). 3. -
Page 5: Specification
Specification EXP-USB-3000 Specification Connection Port USB Type A Male x 1,RJ45 x1 Local Unit Power Bus-Powered Connection Port USB Type A Female x 1,RJ45 x1 Remote Unit Bus-powered 5V/1A Built In Cable 1 Feet Length USB 2.0/1.1 High(480Mb/s),Full(12Mb/s),low Specification speed(1.5Mb/s)
