- Page 1 User Manual EXP-HDBASET-100 HDMI Extender HDBaseT All Rights Reserved Version: EXP-HDBASET-100_2022...
-
Page 2: General Safety Instructions
EXP-HDBASET-100 GENERAL SAFETY INSTRUCTIONS When using electronic products, please review the following safety precautions before installing or using the products. i. Read these instructions. ii. Keep these instructions. iii. Follow all instructions. iv. Heed all warnings. v. Be sure all cables and equipment are connected to the unit as described in the manual. -
Page 3: Table Of Contents
EXP-HDBASET-100 Table of Content GENERAL SAFETY INSTRUCTIONS ................... 2 INTRODUCTION........................4 PACKAGE CONTENTS ......................4 SYSTEM REQUIREMENTS ....................4 CONNECTION DIAGRAM ......................5 DEVICE FUNCTION ......................... 6 Transmitter Panel ....................... 6 Receiver Panel ........................7 IR Pin Assignment ....................... 8 SPECIFICATION ........................ -
Page 4: Introduction
EXP-HDBASET-100 INTRODUCTION EXP-HDBASET-100 with us allows one HDMI, Bi-direction IR to be connected up to 60meters via single CAT.6 cable for Computer, Laptop, BD Player, Game Console and others HDMI source devices. Supporting 4Kx2K/30Hz UHD resolution with 8bit deep color and lossless compressed audio that make EXP-HDBASET-101 a smart choice for home entertainment, company conference, commercial advertising and other applications. -
Page 5: Connection Diagram
EXP-HDBASET-100 CONNECTION DIAGRAM... -
Page 6: Device Function
4. DC IN : 5VDC / 2.0 Amp Locking Power Jack 5. RJ45: Connect to EXP-HDBASET-100 Receiver with single Cat.6 cable for HDMI, IR Blaster, IR Receiver signal transmission. 6. HDMI IN : Connect to HDMI source devices, such as SetTop Box, BD Player, Computer, Laptop, Game Console, Media Player and Camcorder. -
Page 7: Receiver Panel
4. DC IN : 5VDC / 2.0 Amp Locking Power Jack 5. RJ45 : Connect to EXP-HDBASET-100 Transmitter with single Cat.6 cable for HDMI, IR Blaster, IR Receiver signal transmission. 6. HDMI OUT : Connect to HDMI sink devices, such as LED/LCD Monitor, LED/LCD TVs, Projector and AV Receiver. -
Page 8: Ir Pin Assignment
EXP-HDBASET-100 IR Pin Assignment IR Receiver IR Blaster SPECIFICATION Specification Model No EXP-HDBASET-100 TX EXP-HDBASET-100 RX HDMI Bandwidth 340MHz HDMI Resolution 720P/1080P(60m),4K30 4:4:4(40m),4k60 4:2:0(40m) Audio Format LPCM 、 DTS Digital, Dolby Digital HDCP 1.4/2.2 Input Port HDMI x 1 RJ45 x 1... -
Page 9: Cable Specifications
EXP-HDBASET-100 Cable Specifications 1080p/60Hz 4K/30Hz 4K/60Hz Cable Length 8 bit 8 bit 4:4:4 8 bit 4:2:0 HDMI Cable Cat.5e/6/6e/7 Support Resolution Supported Resolutions (Hz) 800x600@ 60 72 75 1024x768@60 70 75 1280x720p@50 59 60 1280x960@60 85 1280x1024@60 75 85 1360x768@60... -
Page 10: Warranty
Limited 3 Year Warranty aegis Multimedia INC. (“Manufacturer”) warrants that this product is free of defects in both materials and workmanship for a period of 3 years as defined herein for parts and labor from date of purchase. This Limited Warranty covers products purchased in the year 2019 and after.
