Summary of Contents for Aegis EXP-HDBASET-7000
- Page 1 User Manual EXP-HDBASET-7000 HDMI Extender HDBaseT with PoE functions All Rights Reserved Version: EXP-HDBASET-7000_2021...
-
Page 2: General Safety Instructions
EXP-HDBASET-7000 GENERAL SAFETY INSTRUCTIONS When using electronic products, please review the following safety precautions before installing or using the products. i. Read these instructions. ii. Keep these instructions. iii. Follow all instructions. iv. Heed all warnings. v. Be sure all cables and equipment are connected to the unit as described in the manual. -
Page 3: Table Of Contents
EXP-HDBASET-7000 Table of Content GENERAL SAFETY INSTRUCTIONS ................... 2 INTRODUCTION........................4 PACKAGE CONTENTS ......................4 SYSTEM REQUIREMENTS ....................4 CONNECTION DIAGRAM ......................5 DEVICE FUNCTION ......................... 6 Transmitter Panel ....................... 6 Receiver Panel ........................7 IR Pin Assignment ....................... 8 SPECIFICATION ........................ -
Page 4: Introduction
EXP-HDBASET-7000 INTRODUCTION EXP-HDBASET-7000 with us allows one HDMI, Bi-direction IR to be connected up to 100meters via single CAT.6 cable for Computer, Laptop, BD Player, Game Console and others HDMI source devices. Supporting 4Kx2K/30Hz UHD resolution with 8bit deep color and lossless compressed audio that make EXP-HDBASET-7000 a smart choice for home entertainment, company conference, commercial advertising and other applications. -
Page 5: Connection Diagram
EXP-HDBASET-7000 CONNECTION DIAGRAM... -
Page 6: Device Function
4. DC IN : 48VDC / 0.5 Amp Locking Power Jack 5. RJ45: RJ45 : Connect to EXP-HDBASET-7000 Receiver with single Cat.6 cable for HDMI, IR Blaster, IR Receiver signal transmission. 6. HDMI IN : Connect to HDMI source devices, such as SetTop Box, BD Player, Computer, Laptop, Game Console, Media Player and Camcorder. -
Page 7: Receiver Panel
3. LINK LED : This LED will illuminate when TX connect compatible RX and RJ45 signal start to transmission. 4. RJ45 : Connect to EXP-HDBASET-7000 Transmitter with single Cat.6 cable for HDMI, IR Blaster, IR Receiver signal transmission. 5. HDMI OUT : Connect to HDMI sink devices, such as LED/LCD Monitor, LED/LCD TVs, Projector and AV Receiver. -
Page 8: Ir Pin Assignment
EXP-HDBASET-7000 IR Pin Assignment IR Receiver IR Blaster SPECIFICATION Specification Model No EXP-HDBASET-7000 TX EXP-HDBASET-7000 RX HDMI Bandwidth 340MHz HDMI Resolution 720P/1080P(100m),4K30 4:4:4(70m),4k60 4:2:0(70m) Audio Format LPCM、DTS Digital, Dolby Digital HDCP Input Port HDMI x 1 RJ45 x 1 Output Port... -
Page 9: Cable Specifications
EXP-HDBASET-7000 Cable Specifications 1080p/60Hz 4K/30Hz 4K/60Hz Cable Length 8 bit 8 bit 4:4:4 8 bit 4:2:0 HDMI Cable Cat.5e/6/6e/7 100m Support Resolution Supported Resolutions (Hz) 800x600@ 60 72 75 1024x768@60 70 75 1280x720p@50 59 60 1280x960@60 85 1280x1024@60 75 85... -
Page 10: Warranty
Limited 3 Year Warranty aegis Multimedia INC. (“Manufacturer”) warrants that this product is free of defects in both materials and workmanship for a period of 3 years as defined herein for parts and labor from date of purchase. This Limited Warranty covers products purchased in the year 2019 and after.
