Summary of Contents for Aegis 4KEXTENDER-100
- Page 1 User Manual 4KEXTENDER-100 4KEXTENDER-100-KVM 4K UHD HDMI EXTENDER All Rights Reserved Version: 4KEXTENDER-100&100-KVM_2019V.1.6.1...
-
Page 2: General Safety Instructions
4KEXTENDER-100 4KEXTENDER-100-KVM GENERAL SAFETY INSTRUCTIONS When using electronic products, please review the following safety precautions before installing or using the products. i. Read these instructions. ii. Keep these instructions. iii. Follow all instructions. iv. Heed all warnings. v. Be sure all cables and equipment are connected to the unit as described in the manual. -
Page 3: Table Of Contents
4KEXTENDER-100-KVM ....................... 9 IR Pin Assignment ......................11 RS232 Pin Assignment ...................... 11 TECHNICAL SPECIFICATION ....................12 4KEXTENDER-100 : Transmitter Specification ..............12 4KEXTENDER -100: Receiver Specification ................ 13 4KEXTENDER-100-KVM: Transmitter Specification ............14 4KEXTENDER-100-KVM : Receiver Specification ..............15 Resolution Specifications .................... -
Page 4: Introduction
4KEXTENDER-100-KVM INTRODUCTION 4KEXTENDER-100 with us allows one HDMI, Bi-direction IR and Bi-direction RS232 to be connected up to 100meters via single CAT.6 cable for Computer, Laptop, BD Player, Game Console and others HDMI source devices. Supporting 4Kx2K/60Hz UHD resolution with 12 bit deep color and lossless compressed audio that make 4KEXTENDER-100 a smart choice for home entertainment, company conference, commercial advertising and other applications. -
Page 5: Connection Diagram
4KEXTENDER-100 4KEXTENDER-100-KVM CONNECTION DIAGRAM 4KEXTENDER-100... - Page 6 4KEXTENDER-100 4KEXTENDER-100-KVM 4KEXTENDER-100-KVM...
-
Page 7: Device Function
6. IR RX: Receiving IR signal to remote control HDMI sink devices via IR Receiver Cable. 7. RS-232: Connect to a Computer, Laptop and other serial control device via 3.5mm to RS232 Cable. 8. RJ45: Connect to 4KEXTENDER-100 Receiver with single Cat.6 cable for HDMI, IR Blaster, IR Receiver and RS232 signal transmission. - Page 8 6. IR RX: Receiving IR signal to remote control HDMI source devices via IR Receiver Cable. 7. RS-232: Connect to a serial control device via 3.5mm to RS232 Cable. 8. RJ45: Connect to 4KEXTENDER-100 Transmitter with single Cat.6 cable for HDMI, IR Blaster, IR Receiver and RS232 signal transmission.
-
Page 9: 4Kextender-100-Kvm
7. IR RX: Receiving IR signal to remote control HDMI sink devices via IR Receiver Cable. 8. RS-232: Connect to a Computer, Laptop and other serial control device via 3.5mm to RS232 Cable. 9. RJ45: Connect to 4KEXTENDER-100-KVM Receiver with single Cat.6 cable for HDMI, IR Blaster, IR Receiver and RS232 signal transmission. - Page 10 8. IR RX: Receiving IR signal to remote control HDMI source devices via IR Receiver Cable. 9. RS-232: Connect to a serial control device via 3.5mm to RS232 Cable. 10. RJ45: Connect to 4KEXTENDER-100-KVM Transmitter with single Cat.6 cable for HDMI, IR Blaster, IR Receiver and RS232 signal transmission.
-
Page 11: Ir Pin Assignment
4KEXTENDER-100 4KEXTENDER-100-KVM IR Pin Assignment IR Receiver IR Blaster RS232 Pin Assignment... -
Page 12: Technical Specification
4KEXTENDER-100 4KEXTENDER-100-KVM TECHNICAL SPECIFICATION 4KEXTENDER-100 : Transmitter Specification HDMI Bandwidth 600MHz / 18.0Gbps HDMI Resolution 480P, 720P, 1080P/24,30,50,60Hz, 4Kx2K/24,30,60Hz. Audio Format 2 Channel 16/20/24bit PCM at 32/44.1/48KHz IEC 61937 Compress audio with IEC 60958 frame rate at 2/44.1/48KHz, up to 8 channels. -
Page 13: 4Kextender -100: Receiver Specification
4KEXTENDER-100 4KEXTENDER-100-KVM 4KEXTENDER -100: Receiver Specification HDMI Bandwidth 600MHz / 18.0Gbps HDMI Resolution 480P, 720P, 1080P/24,30,50,60Hz, 4Kx2K/24,30,60Hz. Audio Format 2 Channel 16/20/24bit PCM at 32/44.1/48KHz IEC 61937 Compress audio with IEC 60958 frame rate at 2/44.1/48KHz, up to 8 channels. -
Page 14: 4Kextender-100-Kvm: Transmitter Specification
4KEXTENDER-100 4KEXTENDER-100-KVM 4KEXTENDER-100-KVM: Transmitter Specification HDMI Bandwidth 600MHz / 18.0Gbps HDMI Resolution 480P, 720P, 1080P/24,30,50,60Hz, 4Kx2K/24,30,60Hz. Audio Format 2 Channel 16/20/24bit PCM at 32/44.1/48KHz IEC 61937 Compress audio with IEC 60958 frame rate at 2/44.1/48KHz, up to 8 channels. IEC Compressed audio format. -
Page 15: 4Kextender-100-Kvm : Receiver Specification
4KEXTENDER-100 4KEXTENDER-100-KVM 4KEXTENDER-100-KVM : Receiver Specification HDMI Bandwidth 600MHz / 18.0Gbps HDMI Resolution 480P, 720P, 1080P/24,30,50,60Hz, 4Kx2K/24,30,60Hz. Audio Format 2 Channel 16/20/24bit PCM at 32/44.1/48KHz IEC 61937 Compress audio with IEC 60958 frame rate at 2/44.1/48KHz, up to 8 channels. -
Page 16: Resolution Specifications
4KEXTENDER-100 4KEXTENDER-100-KVM Resolution Specifications Supported Resolutions (Hz) HDMI Output 720x400p@70 85 720x480i@60 720x480p@60 720x576i@50 720x576p@50 800x600@56 60 72 75 85 848x480p@60 1024x768@60 70 75 85 1152x864@75 1280x720p@50 60 1280x768@60RB/60 75 85 1280x800@60RB/60 75 85 1280x960@60 85 1280x1024@60 75 85 1360x768@60... -
Page 17: Cable Specifications
4KEXTENDER-100 4KEXTENDER-100-KVM Supported Resolutions (Hz) HDMI Output 3840x2160p@24 25 30 3840x2160p@50 60 ( 4:2:0 ) 3840x2160p@24 25 30 HDR10 3840x2160p@50 60 ( 4:2:0 ) HDR10 3840x2160p@50 60 4096x2160p@24 25 30 4096x2160p@50 60 ( 4:2:0 ) 4096x2160p@24 25 30 HDR10 4096x2160p@50 60 ( 4:2:0 ) HDR10... -
Page 18: Acronyms
4KEXTENDER-100 4KEXTENDER-100-KVM ACRONYMS ACRONYM DESCRIPTION Audio/Video Cat.6 Category 6 Cable Cat.6e Category 6 Enhance Cable Cat.7 Category 7 Cable EDID Extended Display Identification Data HDMI High Definition Multimedia Interface Cable HDCP High Bandwidth Digital Content Protection High Dynamic Range Infrared... -
Page 19: Warranty
Limited 1 Year Warranty aegis Multimedia INC. (“Manufacturer”) warrants that this product is free of defects in both materials and workmanship for a period of 1 years as defined herein for parts and labor from date of purchase. This Limited Warranty covers products purchased in the year 2019 and after.
