- Page 1 Installation Guide Two-Handle Wall-Mount Valve and Handles K-6805 M product numbers are for Mexico (i.e. K-12345M) Los números de productos seguidos de M corresponden a México (Ej. K-12345M) Français, page “Français-1” Español, página “Español-1” 117124-2-A...
-
Page 2: Tools And Materials
Before installation, unpack the components and inspect them for damage. Return the components to the carton until you are ready to install. Kohler Co. reserves the right to make revisions in the design of faucets without notice, as specified in the Price Book. 117124-2-A... - Page 3 Connect the hot and cold supplies to the union joints. They should be 2-1/4″ (5.7 cm) minimum and 3″ (7.6 cm) maximum from the finished wall. Reinstall the plaster guards, valve units, and aspirator that were removed before soldering. Kohler Co. 117124-2-A...
- Page 4 Before removing the valve units, position them to the open position (cold = fully clockwise, hot = fully counterclockwise). Remove the plaster guards. Remove the valve units. Reinstall the valve units opposite their original locations (right to left, left to right). Replace the plaster guards. 117124-2-A Kohler Co.
- Page 5 Close the valves (cold = counterclockwise, hot = clockwise). Turn on the main water supply. Turn on the water to flush debris from valve and check for leaks. Turn off water. Complete the finished wall. Kohler Co. 117124-2-A...
- Page 6 Slip a lever handle through the two holes on each center cap. Reinstall each short sleeve so the curved end fits snugly onto the lever handle arm. Reinstall a plastic washer and tighten an end cap onto the threaded end of each lever handle. 117124-2-A Kohler Co.
- Page 7 Be certain to separate the two O-rings at the center of the handle arm so one remains with each stud. Insert the longer end of each long stud through the holes of each center cap. Kohler Co. 117124-2-A...
-
Page 8: Complete The Installation
Make sure all the connections are tight. Open the drain. Turn on the main water supply and check for leaks. Open the hot and cold valves and check for leaks. Run the water for about a minute and turn off. 117124-2-A Kohler Co.
