Please Note: This model does not suit incoming water pressure
below 100kPa or higher than 500kPa. The spray rinse model
requires a minimum inlet pressure of 100kPa to successfully
divert the water flow from the main tap to the spray rinse. The
stop cocks provided with this tap contain gauze filters. Please
ensure your plumber is advised of the minimum and maximum
water pressure, and to install the stop cocks as failure to do so
voids the tap warranty.
Roeburn
AUSH.4841 - MONOBLOC MIXER
AUSH.4846 - MONOBLOC MIXER WITH SPRAY RINSE
mm
hole
COLD
IN
G 1/2" to suit
dual check valve
Con-Serv DC
CFF
HOT
IN
hole
Temperature Range
Working Pressure
Flow Rates
Ideal performance obtained with equal hot & cold pressures.
min
mm
Min 1°C. Max 70°C
Min 100kPa (14.5psi). Max 500kPa (72.5psi)
AUSH.4841
AUSH.4846
1 Bar: 5.9L/min
1 Bar: 5.3L/min
2 Bar: 9.7L/min
2 Bar: 9.3L/min
3 Bar: 12.5L/min
3 Bar: 11.2L/min
Advertisement
Table of Contents
Related Manuals for Perrin & Rowe SHAWS Roeburn AUSH.4841
Summary of Contents for Perrin & Rowe SHAWS Roeburn AUSH.4841
- Page 1 Roeburn AUSH.4841 - MONOBLOC MIXER AUSH.4846 - MONOBLOC MIXER WITH SPRAY RINSE hole hole COLD G 1/2” to suit dual check valve Con-Serv DC Please Note: This model does not suit incoming water pressure Temperature Range Min 1°C. Max 70°C below 100kPa or higher than 500kPa.
-
Page 2: Installation Requirements
Roeburn | INSTALLATION AND USER GUIDE Congratulations on the purchase of your Shaws by Perrin & Rowe kitchen product. Correctly installed and with sensible care, this product will give you many years of trouble-free service. INSTALLATION REQUIREMENTS Perrin & Rowe tapware must be installed by a Licensed Plumber in accordance with the installation instructions provided, best trade practices and must comply to local plumbing regulations in your area. -
Page 3: Before Use
Base seal To install the spray rinse attachment, secure the rinse unit socket WORK SURFACE in a suitable position using a tap wrench of a 36 AF spanner. Hole Place the flexible hose through the top of the rinse unit socket as shown in the diagram. -
Page 4: Care And Maintenance
Roeburn | INSTALLATION AND USER GUIDE SPRAY RINSE Retaining ring The additional bench-mounted spray rinse tap features a flexible insulated 1.2m hose and a simple diverter button which can be Faceplate activated with a press of your thumb. The water ceases to run through Button retaining Mesh filter... - Page 5 Avoiding Damage (continued) To avoid dye and patterning transfer from wet cloths, avoid hanging them over the spout of the tap. Porous surfaces such • as nickel, pewter and unlacquered brass finishes may be affected by chemicals in or on the cloth. Damage caused through the actions described above would not be covered by Perrin &...
-
Page 6: Warranty And Liability
Roeburn | INSTALLATION AND USER GUIDE WARRANTY AND LIABILITY Perrin & Rowe tapware, or Shaws x Perrin & Rowe tapware and accessories sold by Luxe by Design in Australia, or via an authorised Australian dealer are warranted to be free from manufacturing defects in the materials and workmanship for 15 years from the date of purchase. -
Page 7: Servicing And Warranty Claims
SERVICING AND WARRANTY CLAIMS To initiate a warranty claim, please contact the dealer from whom the product was purchased. Proof of purchase will be required. Warranty and servicing claims will be processed by Luxe by Design during regular business hours via a nominated service agent in state capital cities. - Page 8 I MP ORT ER S & DIST RI BU TOR S OF FINE KITCHE N A ND BATHROO MWARE 07 3265 7133 | 30 French Avenue, Brendale QLD 4500 | aftersales@luxebydesign.com.au | www.luxebydesign.com.au 10.23...
