BRIDGE MIXERS
1" Hole
1 /2"
• U.4788X • U.4789L
• U.4790X • U.4791L
Fitted With U.6793
Temp Range:
Min 1°C/34°F
Max 85°C/185°F
Recommended
Working Pressure:
Min 1bar/15psi
Max 5bar/75psi
Ideal performance obtained with equal hot & cold pressures.
The Traditional Kitchen Collection
Installation & User Guide
• U.4719L • U.4718X
1" Hole
1 /2"
1 9/16"
Max
HOT
IN
COLD
IN
1" Hole
1 /2" NPT
1 7/8"Max
• U.4790X • U.4791L
Fitted With U.6792
1 9/16"
Max
1 1/8"
Hole
Hose
Length
47"

Advertisement

loading
Need help?

Need help?

Do you have a question about the Traditional Kitchen U.4719L and is the answer not in the manual?

Questions and answers

Related Manuals for Perrin & Rowe Traditional Kitchen U.4719L

Summary of Contents for Perrin & Rowe Traditional Kitchen U.4719L

  • Page 1 The Traditional Kitchen Collection Installation & User Guide BRIDGE MIXERS • U.4719L • U.4718X 1" Hole 1 9/16" 1 /2" 1 9/16" 1" Hole 1 /2" 1 1/8" Hole COLD • U.4788X • U.4789L • U.4790X • U.4791L Hose Fitted With U.6793 Length 47"...
  • Page 2 The Traditional Kitchen Collection Installation & User Guide Congratulations on the purchase of your Perrin & Rowe Kitchen Product. Correctly installed and with sensible care, this product will give you many years of trouble free service. IMPORTANT INFORMATION Before you proceed... We recommend you engage the services of a registered plumber to install this product.
  • Page 3 Important - Do not cut brass tube. Carefully feed the side spray connector over the protruding brass tube and secure tightly onto the shank. Ensure black rubber washer is in place before securing side spray to flexible hose. Side Holding the side spray, screw the Spray flexible hose onto the end of side spray and place into side spray unit socket.
  • Page 4 ROHL WARRANTY POLICY All products supplied by ROHL carry warranties against manufacturing defects. Perrin & Rowe products carry a Limited Lifetime Warranty. ROHL LLC will provide free of charge, as its options, replacement part(s) or product (or a comparable alternative product) to replace those which have proven defective in materials or workmanship.
