- Page 1 LED Theatre Spot 120 FC LED Spotlight...
- Page 2 Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 Internet: www.thomann.de 07.03.2025, ID: 543403 (V2)
-
Page 3: Table Of Contents
7.2 Functions in 4-channel DMX mode................... 29 7.3 Functions in 6-channel DMX mode................... 29 7.4 Functions in 8-channel DMX mode................... 30 Technical specifications........................33 Plug and connection assignments....................35 Troubleshooting............................36 Cleaning............................... 38 Protecting the environment......................39 LED Theatre Spot 120 FC LED Spotlight... - Page 4 LED Theatre Spot 120 FC LED Spotlight...
-
Page 5: General Information
Our products and documentation are subject to a process of continuous development. They are therefore subject to change. Please refer to the latest version of the documentation, which is ready for download under www.thomann.de. 1.1 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this document. - Page 6 Warning signs Type of danger Warning – high-voltage. Warning – dangerous optical radiation. Warning – suspended load. LED Theatre Spot 120 FC LED Spotlight...
- Page 7 General information Warning signs Type of danger Warning – danger zone. LED Theatre Spot 120 FC LED Spotlight...
-
Page 8: Safety Instructions
Always dispose of packaging material properly when it is not in use. Never allow children to use the device without supervi‐ sion. Keep small parts away from children and make sure that the device does not shed any small parts (such knobs) that children could play with. LED Theatre Spot 120 FC LED Spotlight... - Page 9 Never cover the device or the vents. Do not install the device in the immediate vicinity of other heat sources. Never operate the device in the immediate vicinity of naked flames. LED Theatre Spot 120 FC LED Spotlight...
- Page 10 (FI). Ensure that the power cord plug is easily accessible at all times if it is the only device to safely disconnect the device from the mains supply. As a precaution, disconnect the device from the power grid when storms are approaching or it the device will not be used for a longer period. LED Theatre Spot 120 FC LED Spotlight...
- Page 11 Using fuses of a different type than compatible with the device may cause a fire and seriously damage the device. Only use fuses of the same type. Observe the labelling on the device casing and the information in the "Technical data” chapter. LED Theatre Spot 120 FC LED Spotlight...
-
Page 12: Features
For technological reasons, the light output of LEDs decreases over their lifetime. This effect increases with higher operating temperature. You can extend the service life of the illuminants by providing adequate ventilation and operating the LEDs with the lowest possible brightness. LED Theatre Spot 120 FC LED Spotlight... -
Page 13: Installation
Always secure the barn door with a safety cable on the spotlight. The safety cable must run outside the barn door to not interfere with the light emission. LED Theatre Spot 120 FC LED Spotlight... - Page 14 Only use stands whose maximum bearing capacity is at least as high as the weight of the device. Always ensure that the stand is stable. Comply with regulations When installing and operating, make sure to follow the standards and regulations that apply in your country. LED Theatre Spot 120 FC LED Spotlight...
-
Page 15: Mounting Options
Always work from a stable platform whenever installing, moving or servicing the device. While you do this, the area underneath the device must be cordoned off. The safety cable must be attached to the safety eyelet. LED Theatre Spot 120 FC LED Spotlight... -
Page 16: Starting Up
Connect the output of the first DMX device to the input of the second one and so on, to form a series connection. Make sure that the output of the last DMX device in the chain is terminated by a resistor (110 Ω, ¼ W). LED Theatre Spot 120 FC LED Spotlight... - Page 17 Connect the DMX output of the master device to the DMX input of the first slave device. Then connect the DMX output of the first slave device to the DMX input of the second slave device and so on. LED Theatre Spot 120 FC LED Spotlight...
-
Page 18: Connections And Controls
Connections and controls Connections and controls 1 Mounting bracket 2 Locking screw for mounting bracket 3 Front side with barn door attachment ö LED Theatre Spot 120 FC LED Spotlight... - Page 19 5 [DMX OUT] | DMX output 6 Power Twist connector for the power supply of a further device 7 Safety cable eyelet 8 Focus control Adjusts the beam angle in a range from 15° to 45°. LED Theatre Spot 120 FC LED Spotlight...
-
Page 20: Operating
If you do not press any button for 60 seconds, the display will automatically turn off. Any changes you made are not applied. Setting the DMX address Press [Menu]. Press [Up] or [Down] until the display shows ‘Addr’ . LED Theatre Spot 120 FC LED Spotlight... - Page 21 To return to the previous menu level without changes, press [Menu]. Setting the red dimmer Press [Menu]. Press [Up] or [Down] until the display shows ‘rL--’ . Confirm with [Enter]. ð The display shows ‘rLXX’ . LED Theatre Spot 120 FC LED Spotlight...
- Page 22 Use [Up] or [Down] to select the dimmer function in a range from ‘gL00’ (dark) to ‘gL15’ (bright). Confirm with [Enter]. To return to the previous menu level without changes, press [Menu]. Setting the blue dimmer Press [Menu]. Press [Up] or [Down] until the display shows ‘bL--’ . LED Theatre Spot 120 FC LED Spotlight...
- Page 23 ð The display shows ‘oLXX’ . Use [Up] or [Down] to select the dimmer function in a range from ‘oL00’ (dark) to ‘oL15’ (bright). Confirm with [Enter]. To return to the previous menu level without changes, press [Menu]. LED Theatre Spot 120 FC LED Spotlight...
- Page 24 Use [Up] or [Down] to select the speed of the 7-fold colour change in a range from ‘AS00’ (slow) to ‘AS15’ (fast). Confirm with [Enter]. To return to the previous menu level without changes, press [Menu]. LED Theatre Spot 120 FC LED Spotlight...
- Page 25 ð The display shows ‘CTXX’ . Use [Up] or [Down] to adjust the default colour temperature between ‘CT00’ (2,800 K) and ‘CT15’ (21,000 K). Confirm with [Enter]. To return to the previous menu level without changes, press [Menu]. LED Theatre Spot 120 FC LED Spotlight...
- Page 26 ð The display shows ‘LedX’ . Use [Up] or [Down] to select the required display rotation ‘Led0’ (normal) or ‘Led1’ (rotated 180°). Confirm with [Enter]. To return to the previous menu level without changes, press [Menu]. LED Theatre Spot 120 FC LED Spotlight...
- Page 27 To return to the previous menu level without changes, press [Menu]. Using “slave" mode Connect the device to a master device via a suitable DMX cable. ð The device precisely follows the operation of the master it is connected to. LED Theatre Spot 120 FC LED Spotlight...
-
Page 28: Menu Overview
A001 rL00 gL00 bL00 oL00 FL00 A512 rL15 g 15 bL15 oL15 FL15 CE-- CT-- FAdE Led- CH-- ASC- AS00 CE00 CT00 FA00 Led0 CH04 AS15 CE15 CT15 FA15 CH06 Led1 CH08 LED Theatre Spot 120 FC LED Spotlight... -
Page 29: Functions In 4-Channel Dmx Mode
7.3 Functions in 6-channel DMX mode Channel Value Function 0…255 Master dimmer (0% to 100%) 0…255 Dimmer red (0% to 100%) 0…255 Dimmer green (0% to 100%) 0…255 Dimmer blue (0% to 100%) LED Theatre Spot 120 FC LED Spotlight... -
Page 30: Functions In 8-Channel Dmx Mode
Dimmer red (0% to 100%) 0…255 Dimmer green (0% to 100%) 0…255 Dimmer blue (0% to 100%) 0…255 Dimmer white (0% to 100%) 1…14 Cold white 15…29 White 30…44 Light blue 45…59 Blue LED Theatre Spot 120 FC LED Spotlight... - Page 31 Light green 210…224 Green 225…239 Bluish green 240…254 Turquoise 0…255 Strobe effect from slow to fast Shades of grey are set by channels 1 to 6. 6…240 Gradual speed change from slow to fast LED Theatre Spot 120 FC LED Spotlight...
- Page 32 Operating Channel Value Function 241…254 Automatic colour changes LED Theatre Spot 120 FC LED Spotlight...
-
Page 33: Technical Specifications
Lockable output socket devices (Power Twist) POWER OUT max. 6A Output current, max.: 6 A DMX control XLR panel socket, 3-pin Power consumption Max. 135 W Supply voltage 100 - 240 V 50/60 Hz LED Theatre Spot 120 FC LED Spotlight... -
Page 34: Further Information
185 mm × 160 mm × 260 mm Weight 5 kg Ambient conditions Temperature range 0 °C…40 °C Relative humidity 20%…80% (non-condensing) Further information Optic Fresnel Fanless Motorised zoom Housing colour Black Power of the individual LED 120 W LED Theatre Spot 120 FC LED Spotlight... -
Page 35: Plug And Connection Assignments
The unit offers a 3-pin XLR socket for DMX output and a 3-pin XLR plug for DMX input. Please refer to the drawing and table below for the pin assignment of a suitable XLR plug. Configuration Ground, shielding Signal inverted (DMX–, ‘cold signal’) Signal (DMX+, ‘hot signal’) LED Theatre Spot 120 FC LED Spotlight... -
Page 36: Troubleshooting
DMX start address of devices with independent control is always higher by the number of channels that have been set for the DMX mode on another device. LED Theatre Spot 120 FC LED Spotlight... - Page 37 Troubleshooting If the procedures recommended above do not succeed, please contact our Service Center. You can find the contact information at www.thomann.de. LED Theatre Spot 120 FC LED Spotlight...
-
Page 38: Cleaning
The fan grids of the device must be cleaned of any contamination, such as dust, etc. on a reg‐ ular basis. Before cleaning, switch off the device and disconnect mains-operated devices from the mains. Only use pH-neutral, solvent-free and non-abrasive cleaning agents. Clean the unit with a slightly damp lint-free cloth. LED Theatre Spot 120 FC LED Spotlight... -
Page 39: Protecting The Environment
Do not dispose of these materials with your normal household waste, but make sure that they are collected for recycling. Please follow the instructions and markings on the packaging. Observe the disposal note regarding documentation in France. LED Theatre Spot 120 FC LED Spotlight... - Page 40 When disposing of the device, comply with the rules and regulations that apply in your country. You can also return your old device to Thomann GmbH at no charge. Check the current conditions on www.thomann.de.
- Page 41 Notes LED Theatre Spot 120 FC LED Spotlight...
- Page 42 Notes LED Theatre Spot 120 FC LED Spotlight...
- Page 44 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
