Summary of Contents for thomann fun generation Colour Burst MKll

  • Page 1 Colour Burst MKll LED Flower Effect...
  • Page 2 Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 Internet: www.thomann.de 16.04.2025, ID: 532463 (V2)

  • Page 3: Table Of Contents

    Table of contents Table of contents General information..........................5 1.1 Symbols and signal words....................... 5 Safety instructions............................. 8 Features............................... 11 Installation..............................12 Connections and controls........................17 Operating..............................19 Technical specifications........................22 Cleaning............................... 24 Protecting the environment......................25 Colour Burst MKll LED Flower Effect...
  • Page 4 Colour Burst MKll LED Flower Effect...

  • Page 5: General Information

    Our products and documentation are subject to a process of continuous development. They are therefore subject to change. Please refer to the latest version of the documentation, which is ready for download under www.thomann.de. 1.1 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this document.
  • Page 6 General information Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided. WARNING! This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in death or serious injury if it is not avoided.
  • Page 7 General information Warning signs Type of danger Warning – danger zone. Colour Burst MKll LED Flower Effect...

  • Page 8: Safety Instructions

    Safety instructions Safety instructions Intended use This device is intended for use as an electronic lighting effect by means of LED technology. The device is designed for professional use only and is not suitable for use in households. Use the device only as described in this user manual.
  • Page 9 Safety instructions DANGER! Danger to life due to electric current! Within the device there are areas where high voltages may be present. Never remove any covers. There are no user-serviceable parts inside. Do not use the device when covers, safety equipment or optical components are missing or damaged. WARNING! Risk of eye damage caused by high light intensity! The device generates highly intense light radiation.
  • Page 10 Safety instructions NOTICE! Damage to the device if operated in unsuitable ambient conditions! The device can be damaged if it is operated in unsuitable ambient conditions. Only operate the device indoors within the ambient conditions specified in the “Technical specifications” chapter of this user manual. Avoid operating it in environments with direct sun‐ light, heavy dirt and strong vibrations.

  • Page 11: Features

    Features Features Compact effect spotlight for large-area RGBW dot rotation effects. 4 × RGBW LEDs, each 2 W Direct control on the device or via the supplied infrared remote control Pre-programmed automatic shows Sound control USB-C power supply not included For technological reasons, the light output of LEDs decreases over their lifetime.

  • Page 12: Installation

    Installation Installation Unpack and check carefully there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the product against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively.
  • Page 13 Installation NOTICE! Risk of overheating and fire due to inadequate distance and bad ventilation! If the distance between the light source and the illuminated surface is too short or the device is badly ventilated, the device can overheat and cause fires. Make sure that illuminated surfaces are more than 2 m away.
  • Page 14 Installation Mounting options You can install the device in hanging or standing positions. When in use, the device must always be attached to a solid surface or an approved mount. Use the openings provided on the bracket for attaching. Always work from a stable platform whenever installing, moving or servicing the device. While you do this, the area underneath the device must be cordoned off.
  • Page 15 Installation Inserting the battery into the remote control Loosen the screw of the battery holder on the back of the remote control. Push the lock of the battery holder towards the centre of the housing and pull out the battery holder like a drawer. Insert the batteries.
  • Page 16 Installation NOTICE! Possible damage due to leaking batteries! Batteries can leak and cause permanent damage to the device. Take the batteries out of the device if it is not going to be used for an extended period of time. Colour Burst MKll LED Flower Effect...

  • Page 17: Connections And Controls

    Connections and controls Connections and controls ö & Colour Burst MKII CLOSE AUTO SOUND 5V/2A Colour Burst MKll LED Flower Effect...
  • Page 18 Connections and controls 1 Mounting bracket 2 Locking screws for the mounting bracket 3 RGBW LEDs 4 Sensor for the signals from the included IR remote control 5 Safety cable eyelet 6 Mode selection switch [CLOSE] | Activates operation via the supplied remote control [AUTO] | Activates automatic mode [SOUND] | Activates sound-control 7 [DC 5V] | Connection socket for a USB-C power supply for the power supply of the device...

  • Page 19: Operating

    Operating Operating Connect the USB-C power supply (not included) to the power supply to start operation. After a few seconds the device is ready for use. Automatic mode Slide the switch on the back of the device to [AUTO] to activate automatic mode. The preprog‐ rammed automatic programmes are played automatically.
  • Page 20 Operating Functions of the infrared remote control Button labelling: Function [AUTO] Enabling / disabling the automatic mode [MUSIC] Enabling / disabling the sound control – [ON/OFF] Blackout Increasing the strobe effect flash frequency No function Reducing the strobe effect flash frequency [A] Enabling/disabling the strobe effect [B], [C] No function [1] Selecting fixed colour red...
  • Page 21 Operating Button labelling: Function [7] Selecting mixed colour red (55%) and green (30%) [8] Selecting mixed colour red and white [9] Selecting mixed colour red and green [0] Selecting mixed colour green and blue (30%) No function Colour Burst MKll LED Flower Effect...

  • Page 22: Technical Specifications

    Technical specifications Technical specifications Light source 4 × RGBW LEDs, each 2 W Control Controls on the device, infrared remote control Input connections Power supply Connection socket USB-C Power consumption 10 W Power supply External power adapter, 100 - 240 V 50/60 Hz 135 mm Operating voltage/current...
  • Page 23 Technical specifications Further information Similar design Beam effect DMX control Master/slave Remote control Included Sound control Display Colour Burst MKll LED Flower Effect...

  • Page 24: Cleaning

    Cleaning Cleaning Optical lenses Clean the optical lenses, that are accessible from the outside, regularly in order to optimize the light output. The frequency of cleaning depends on the operating environment: wet, smoky or particularly dirty surroundings can cause more accumulation of dirt on the optics of the device.

  • Page 25: Protecting The Environment

    Protecting the environment Protecting the environment Disposal of the packing material Environmentally friendly materials have been chosen for the packaging. These materials can be sent for normal recycling. Ensure that plastic bags, packaging, etc. are disposed of in the proper manner. Do not dispose of these materials with your normal household waste, but make sure that they are collected for recycling.
  • Page 26 When disposing of the device, comply with the rules and regulations that apply in your country. You can also return your old device to Thomann GmbH at no charge. Check the current conditions on www.thomann.de.
  • Page 28 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
