F SF110
INSTRUCTION MANUAL
Para Español ver página 12
WE'RE HERE TO HELP
Want to watch a video that
shows how easy this DIY
project will be?
Watch it now at:
SANUS.com/2772
Get it right the first time.
HeightFinder™ shows you
where to drill.
Check it out at:
SANUS.com/1171
+
Our US-based install experts
are standing by to help.
Call us at:
888-333-9952
Or, chat at:
SANUS.com/chatSV
4K HDMI
Cable
Advertisement
Related Manuals for SANUS VuePoint FSF110
Summary of Contents for SANUS VuePoint FSF110
- Page 1 F SF110 4K HDMI Cable INSTRUCTION MANUAL Para Español ver página 12 WE’RE HERE TO HELP Want to watch a video that Get it right the first time. Our US-based install experts shows how easy this DIY HeightFinder™ shows you are standing by to help.
-
Page 2: Wall Construction
IMPORTANT SAFETY INSTRUCTIONS – PLEASE READ MANUAL PRIOR TO USE – SAVE THESE INSTRUCTIONS Please read through these instructions completely to be sure you’re comfortable with this easy install process. Check your TV owner’s manual to see if there are any special requirements for mounting your TV. If you do not understand these instructions or have doubts about the safety of the installation, assembly or use of this product, contact Customer Service 1-888-333-9952. -
Page 3: Before You Begin
Dimensions TV INTERFACE 7.87in 200mm 2.95in 75mm 7.87in 200mm 2.95in 3.94in 75mm 100mm 7.87in 200mm WALL PLATE TOP VIEW - EXTENDED SIDE VIEW - EXTENDED 3.03in 16deg 16deg 77mm DOWN 10.18in 10.46in 258.6mm 265.7mm WITHOUT WITH 8.50in 6.40in EXTENSION EXTENSION 215.9mm 162.6mm BRACKETS... - Page 4 Supplied Parts and Hardware WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service. Never use damaged parts! NOTE: Not all hardware included will be used.
- Page 5 M5 x 35mm STEP 1 Attach TV Bracket to TV 1.1 Measure Your TV Hole Pattern 1.2 Assemble Your TV Bracket Determine which TV bracket configuration to use, A, B, or C Measure the width and height of your TV hole pattern in mm. based on your TV hole pattern measurements.
- Page 6 1.3 Select TV Screw Diameter 1.4 Select TV Screw Length and Spacers Only one screw size fits your TV. NO SPACER SPACER NEEDED • Flat Back TV • Flat Back TV • Rounded or Irregular Back TV with extra space needed [for deep inset holes or cable interference] [TV brackets NOT resting flat on your TV] [TV brackets lay flat on your TV]...
- Page 7 Wood Stud Installation STEP 2A Attach Wall Plate CAUTION: Avoid potential personal injury or property damage! ● Drywall covering the wall must not exceed 5/8 in. (16 mm) ● Minimum wood stud size: nominal 2 x 4 in. (51 x 102 mm) actual 1 ½ x 3 ½ in. (38 x 89 mm) Locate your stud.
- Page 8 Solid Concrete or Concrete Block Installation STEP 2B Attach Wall Plate CAUTION: Avoid potential personal injury or property damage! Concrete Installation Kit CMK1 is not included ● Mount wall plate assembly directly onto concrete surface (no wall covering) Contact Customer Service to inquire about ●...
-
Page 9: Manage Cables
STEP 3 Hang TV onto Wall Plate HEAVY! You may need assistance with this step. Position the arm of wall plate assembly so the elbow is bent 90 degrees and pressed against the wall. Hang the TV onto the arm of wall plate assembly by first hooking the top support, then resting the TV into place. -
Page 10: Tilt Adjustment
TV Adjustments TILT ADJUSTMENT TILT ADJUSTMENT Your TV should adjust easily when moved, then stay in place. If your TV is too loose or too tight, adjust the tilt tension knob by hand. NOTE: Once your TV is in place, tighten the tilt tension Tighten knob to prevent unwanted movement. -
Page 11: Removing The Tv
EXTENSION/RETRACTION ADJUSTMENT EXTENSION/RETRACTION ADJUSTMENT Your TV should adjust easily when moved, then stay in place. If your TV is too loose or too tight, adjust the arm tension screws using hex key and a 9/16 in. (14 mm) socket. Tighten Arm Tension Loosen Screw... - Page 12 INSTRUCCIONES IMPORTANTES DE SEGURIDAD ESPAÑOL – – LEA TODO ESTE MANUAL ANTES DE UTILIZAR ESTE PRODUCTO GUARDE ESTAS INSTRUCCIONES Lea atentamente estas instrucciones en su totalidad para asegurarse de que está familiarizado con el sencillo proceso de instalación. Consulte igualmente el manual de su televisor para conocer si existen requisitos especiales para el montaje de su aparato. Si no entiende las instrucciones o si tiene dudas acerca de la seguridad de la instalación, el montaje o el uso del producto, póngase en contacto con el Servicio de Atención al Cliente o llame a nuestro servicio técnico al número 1-888-333-9952 .
- Page 13 ESPAÑOL Piezas y accesorios suministrados Ver pagina 4 ADVERTENCIA: Este producto contiene piezas pequeñas que, si fuesen tragadas, podrían producir asfixia. Antes de iniciar el ensamblaje, compruebe que todas las piezas estén incluidas y en buenas condiciones. Si faltan piezas o alguna está dañada, no devuelva el artículo al distribuidor;...
- Page 14 ESPAÑOL PASO 2A Fijar la placa mural montantes de madera Ver pagina 7 PRECAUCIÓN: Evite lesiones y daños materiales. ● El yeso que recubre la pared no debe exceder los 16 mm (5/8''). ● Tamaño mínimo del montante de madera: nominal 51 mm x 102 mm (2'' x 4''); real 38 mm x 89 mm (1½'' x 3½''). NOTA: TV se desplaza 21.8 mm (0.86 pulg.) a la derecha oa la izquierda cuando está...
-
Page 15: Ajustes Del Televisor
ESPAÑOL PASO 3 Colgar el televisor en la placa mural Ver pagina 9 ¡ELEMENTO PESADO! Es posible que necesite ayuda en este paso. Coloque el brazo del ensamblaje de la placa mural de modo que el codo quede flexionado a 90 grados y presionado contra el muro. Para colgar el televisor en el brazo del ensamblaje de la placa mural , primero enganche el soporte superior y luego apoye el televisor en su lugar. - Page 16 Thank you for choosing SANUS Vuepoint! Please take a moment to let us know how we did: Call us: 1-888-333-9952 Email us: info@sanus.com Leave a review: Vuepoint.SANUS.com Legrand AV Inc. and its a liated corporations and subsidiaries (collectively, “Legrand”), intend to make this manual accurate and complete. However, Legrand makes no claim that the information contained herein covers all details, conditions, or variations.
