CORE HEALTH & FITNESS
10TRx
OWNER'S
MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 10TR Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Star Trac 10TR Series

Summary of Contents for Star Trac 10TR Series

  • Page 1 CORE HEALTH & FITNESS 10TRx OWNER'S MANUAL...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS ........................3 IMPORTANT LABEL LOCATIONS ........................5 PRODUCT SPECIFICATIONS ........................5 ASSEMBLY ........................6 REQUIRED TOOLS ..............6 ASSEMBLY PARTS ..............7 PROCEDURE ..............8 OPERATION LED CONSOLES ........................19 MAINTENANCE MODE ..............21 MAINTENANCE ........................23 TOOLS ..............23 REPLACEMENT PARTS ........................24 9-9304-XXXXP0 - 10TRx TREADMILL ............

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS WARNING! Before using this product, it is essential to read the ENTIRE Owner’s Manual and ALL installation instructions. The Owner’s Manual describes equipment operation and instructs members on how to use correctly and safely. Read all warnings posted on the machine. Health related injuries may result from incorrect or excessive use of exercise equipment.
  • Page 4 4. User should run or walk upright with a neutral 14. This equipment is designed for use in a GROUNDING INSTRUCTIONS spine, eyes forward, core engaged, and land commercial gymnasium or health club only. To This product must be grounded. If it should softly on the midfoot.

  • Page 5: Important Label Locations

    KEYPAD, NAV BAR, LED DISPLAYS STICKER, CAUTION, PINCH POINT ICON CAUTION! 050-6022 050-5929 190mm, EXTRUDE DECAL, STAR TRAC START STOP, LED DISPLAYS Shipping Weight (Boxed): 562 lbs (255 kg) Shipping Dimensions: 88.9in x 35.4in x 29.1in (226cm x 90cm x 74cm) Page 5...

  • Page 6: Assembly

    ASSEMBLY REQUIRED TOOLS Fig. 4 9-9304 Shown Required Tools: • Torque Wrench • #2 Phillips Screwdriver • 4mm, 5mm Allen Keys • 13mm Open-Ended Wrench • 4mm, 5mm, 8mm, 13mm Allen Socket • 3/4” Open-Ended Wrench • 15mm, 19mm Socket •...

  • Page 7: Assembly Parts

    ASSEMBLY PARTS Fig. 5 Assembly Parts - Print this page to compare. Description 110-4473 SCREW, M10X1.5,20mm, HHC, HE, AS, BEC, FL, Gr-10.9 110-3671 NUT, “U”, BARREL, TAPERED, M5x0.8mm 110-4497 SCREW, M5X0.8, 16mm, SHC, HK, CS, BEC, DP 110-4329 SCREW, M5x0.8x20, PHM, PH, CS, BZ, DP 110-4229 SCREW, M5x0.8x30, PHM, PH, CS, BZ, DP 110-4467...

  • Page 8: Procedure

    PROCEDURE 110-4473 Route wire bundle from main handrail 715-4479-XX assembly 715-4479-XX through right upright 020-8186 rail 020-7854-XX and right beauty ring 020- 8187. 020-8187 Secure left and right upright rails and left (020-8187) and right (020-8186) beauty rings 020-7853-XX with 4 bolts 110-4473 each side - note that the beauty rings are left-right specific.
  • Page 9 715-4245 Adjust left and right wedges 715-4245 to 63mm by rotating lower bolt 110-4051. With two people, carefully lift the handrail assembly and install it onto the frame. Once the handrail assembly is set onto the frame, check to ensure that the wires are not pinched - adjust the handrail assembly if they are.
  • Page 10 715-3880 715-3881 715-4316 220-0364 12. Plug in all four wires from the mast routed into 220-0373 the motor compartment. • Two wires are plugged directly into the 220-0363 MCB (715-3880): 220-0364 Data Cable 715-4316 Power Cable • The remaining three are plugged into the wiring that comes up through the base of the motor compartment.
  • Page 11 715-4533-XX 110-4497 715-4534-XX 110-4497 15. Using a 4mm allen key install left (715-4534- XX) and right (715-4533-XX) transition rim plastics to the handrail with four screws 110- 4497- DO NOT FULLY TIGHTEN. 16. Connect left and right transition rim plastics with two screws 110-4497 in the bottom two holes - DO NOT FULLY TIGHTEN.
  • Page 12 19. Secure console to frame weldment with four screws 110-4447 as in Fig. 15. TORQUE TO 7.4-11 ft-lbs (10-15 Nm) If installing a PVS kit or 800/900 MHz controller, please refer to the documentation that ships with the accessory before continuing with assembly or scan the QR below: 800/900 MHz Controller 20.
  • Page 13 715-4267-XX 715-4257-XX 110-4229 25. Install motor shroud 715-4257-XX using only 715-4268-XX the back two screws 110-4229. 110-4329 26. Install left and right shrouds onto frame first with 4 screws 110-4329 each side. INSTALL LAST Fig. 18 27. Ensure that treadmill is in final install location. Level the unit by adjusting feet 140-3485 as needed with a 9/16”...

  • Page 14: Power Switch

    220-0277 220-0276 29. Plug power cord into IEC Connector using 240-6929 appropriate power cord for your region. 240-6930 30. Secure power cord with zip tie around IEC Connector. POWER 31. Ensure power switch is on. SWITCH 32. Assembly is complete, please continue to on page 14.

  • Page 15: First Time Setup

    FIRST TIME SETUP SELECT THE MODEL Press and hold the 1, 2 on the left keypad and the 8 key on the right keypad together A beep will sound and “MAINTENANCE MODE” will display momentarily in the Information Window. Release all keys. “SERIAL NO #####” will display in the Information Window.
  • Page 16 PERFORM MOTOR AND ELEVATION CALIBRATIONS Press and hold the 1, 2 on the left keypad and the 8 key on the right keypad together A beep will sound and “MAINTENANCE MODE” will display momentarily in the Information Window. Release all keys. “SERIAL NO #####” will display in the Information Window. Use the Incline keys to scroll in the maintenance menu until “Elev Calibration”...
  • Page 17 FRONT OF TREADMILL CHECK FOR PROPER MOVING TRACKING SURFACE While standing on the moving surface, press the green Quick Start button, then increase the speed to 3mph (5kph). While walking on the moving surface, observe the moving surface: LEFT RIGHT If the moving surface stays centered, skip to step 1 on page 18.
  • Page 18 CHECK FOR PROPER MOVING SURFACE TENSION “STOMP TEST” Press the green Quick Start button, then increase the speed to 3mph (5kph). Walk on the moving surface then abruptly stomp and apply pressure with your foot while holding the handrails in attempt to stop the moving surface: If the moving surface does not stop, the tension is appropriate.

  • Page 19: Operation Led Consoles

    OPERATION LED CONSOLES USING THE CONSOLE QUICK START Key Enables manual operation using a default weight, SPEED and a default time limit. NOTE: Default time and weight are adjustable through Maintenance Mode. STOP Button Press the STOP button to enter pause mode. Workout will be suspended and a countdown timer will begin counting down from 2 minutes.

  • Page 20: Display Measurements

    Display Measurements Message Window The top display window includes several measures: Current total workout time TIME Total distance traveled in mile or DISTANCE Current HR in beats per minute, HEART RATE if available Current total calories CALORIES Progress Window & Track Shows a graphic representation of elevation during a program.

  • Page 21: Maintenance Mode

    MAINTENANCE MODE Maintenance Mode allows access to service and diagnostic information, as well as provides the ability to adjust certain program default parameters. To enter Maintenance Mode: 1. Press and hold the 1, 2 and 8 keys on the left keypad together.

  • Page 22: Manually Updating Firmware

    A complete list of the items that you may display and change in Maintenance Mode: Lowest Highest Lowest Highest Item Default Notes Item Default Notes Value Value Value Value EXIT SYSTEM STATS DISP V0.3.1 (1) 00.09 (02) QUICK ST V2.3.5 MANUAL MCU S/N: 3B0BD...

  • Page 23: Maintenance

    MAINTENANCE TOOLS To watch a maintenance video of Startrac treadmills scan or visit: QR.COREHANDF.COM/TMMAINT Working on this product will require basic and/or sometimes specialty tools based on the type of service that will be performed at any time. To assist, we recommend having the tools listed available when performing maintenance.

  • Page 24: Replacement Parts

    ASSY, CABLE, COAXIAL, 475mm, 10TR 050-5685 LABEL, OPER’L, IS, TRD, WHEN, AWAY, KEEP, CAUTION! 220-0314 ASSY, CABLE, CAT7, CSAFE, 475mm, 10TR 050-6022 190mm, EXTRUDE DECAL, STAR TRAC 220-0334 HOTBAR AND WARMBAR I/O, Cable, TREADMILL 110-1823 NUT, THIN, JAM,1/2-13 x 5/16 THICK, BZ, GR-5 220-0335...
  • Page 25 Part Number Description 715-4333 DECAL, GUARD, SIDE, BELT, LT, DECK, FLEX, TREADMILL 715-4334 DECAL, GUARD, SIDE, BELT, RT, DECK, FLEX, TREADMILL 715-4397 PLATE, NUT, MOUNT, DECK, FLEX, TREADMILL, G2 715-4400-XX ASSY, DECK, PHENOLIC, ADHERED, 10-TRx 715-4479-XX ASSY, HANDRAIL, 10TRX 715-4483 GRIP, HANDRAIL, 10TRX 715-4517 ASSY, HOTBAR, REFRESH, TREADMILL...
  • Page 26 110-4057 440-0273 110-4056 140-3232 715-3880-RF 715-4253 715-4210 715-3802 110-4045 110-3026 110-3776 110-3671 120-3378 715-3801 120-3418 110-4105 110-3672 220-0314 740-8119 260-0967 715-4360 130-1694 240-6930 740-9478 110-4106 740-6116 470-0415 220-0312 110-3709 Fig. 35 Electrical Fig. 36 Elevation 110-4079 720-5318 020-4464 110-3562 715-4257-XX 715-4267-XX 715-4479-XX 715-4483...
  • Page 27 715-4518 715-4517 720-5319 170-0732 731-6986 110-4467 220-0373 715-4555 715-4126 110-4497 715-4316 715-4560-XX 715-4533-XX 220-0363 110-4079 715-4534-XX 020-7878 110-3484 Fig. 39 Hotbar Fig. 40 Mast 020-8187 020-8186 110-4473 120-3266 110-3429 020-7853-XX 110-0180 120-3267 050-1903 260-0934 020-6563 020-7854-XX 560-0069 110-0580 120-0420 120-0425 140-3684 140-3683 715-4245...
  • Page 28 715-4400-XX 715-4329 130-1759 110-4318 110-3704 715-4258-XX 715-4260-XX 715-4284 715-4264-XX 110-3704 715-4270-XX 715-4249-XX 110-3563 715-4259-XX 715-4285 715-4250 120-3353 110-4103 715-3635 715-4542-XX 110-3561 050-6022 715-4262-XX 110-3731 715-4263-XX 120-3403 110-3671 Fig. 43 Rear Rollers Fig. 44 Side and Rear Shrouds 260-0934 715-4212 110-4318 130-0120 715-4236 140-3419...

  • Page 29: 700-0552-Xx - Display Led, Tread

    220-0334 220-0342 220-0364 220-0363 220-0335 220-0373 220-0276 220-0277 715-4529 440-0273 715-3412 715-4360 410-0957 Fig. 47 Wiring and Hardware Card 700-0552-XX - DISPLAY LED, TREAD 700-0557-XX - DISPLAY LED, TREAD, KM Part Number Qty Description Name Description 050-5929 START STOP, LED DISPLAYS 050-5929 START STOP, LED DISPLAYS 050-5937...

  • Page 30: Support & Service

    SUPPORT & SERVICE CORE CONNECT Core Connect is your portal to all things service! Whether you need to order parts or register your warranty, Core Connect is the most effective way to get what you need fast and keep your facility operating smoothly. OFFERS 24-HOUR SELF SERVICE ACCESS TO: •...
  • Page 31 THIS PAGE INTENTIONALLY BLANK Page 31...
  • Page 32 PART NUMBER 620-9102, REV B All rights reserved. Star Trac, the Star Trac logo and StairMaster are registered trademarks of Core Health & Fitness, LLC. Schwinn and Nautilus are registered trademarks of Nautilus Inc. used under license to Core Health & Fitness LLC. Throwdown is a registered trademark of Throwdown Industries, LLC.
