Summary of Contents for UNIVIEW IPC254EB-DX22GK-I0
- Page 1 Network Bullet Cameras Quick Guide V1.03...
- Page 2 Waterproof Requirements Please waterproof cables in accordance with the following instructions. User shall assume all responsibility for device damage caused by water due to improper waterproof measures. NOTE! Before you start, connect all the needed cables and cut off the copper wires for ...
- Page 3 3. Install the supplied waterproof components to the network cable in sequence. CAUTION! You need to mount the rubber ring onto the network cable interface first. 4. If your camera has a DC cable and you will not use it, insert the plug into the interface.
-
Page 4: Packing List
Packing List Contact your local dealer if the package is damaged or incomplete. The package contents may vary with device model. Name Unit Camera Waterproof components （1） Screw components （2） Mount accessories （3） User manual Remarks: * means optional and supplied with certain models only. Including one or more waterproof components such as tape and plug. -
Page 5: Maintenance Precautions
To protect the transparent dome cover from friction, scratch and stain, do not remove the protective film from the cover until mounting is finished. The temperature measurement device is recommended for indoor use. A closed and windless environment with constant temperature is prefered. The working temperature shall be16℃-32℃, and the relative humidity shall be 90% or less. -
Page 6: Installation
Interface Description Interface Description Monitor Audio input Alarm input 1 Alarm input 2 Power/Grounding Fiber Audio output Network RS 485 Alarm output 1 Alarm output 2 NOTE! Please refer to the latest product datasheet for detailed specifications. Installation 4.1 (Optional)Install SD Card and SFP Optical Module You need to install a Micro SD card first if you want to save video on an on-board SD card. - Page 7 NOTE! For recommended SD card specifications, please contact your dealer or technical support. Please format the Micro SD card before use. The Micro SD card can be formatted on the camera's Web interface. Before you insert or remove the Micro SD card, be sure to disconnect power and ...
-
Page 8: Install The Camera
4. Insert the SFP optical module into the module slot, and then connect the optical fiber plug and the optical module. 将尾线中的光纤插入SFP光 模块中 Note: When using a single-fiber optical module, please connect the optical module to the external network switch using the same fiber optic cable (e.g., if you use the FIBER, 0 cable to connect the optical module, you must also use the FIBER, 0 cable to connect to the network switch). - Page 9 1. Drill holes on the wall: Paste the positioning sticker on the wall, then use a Ø6-6.5mm drill bit to drill 30 mm-depth guide holes according to the positions marked by the sticker. Knock the plastic rivets into the guide holes and ensure that they are tightened up.
-
Page 10: Tripod Mount
1. Fasten the universal joint to the 2. Mount antenna: tighten the installation hole on the camera. antenna to the device, and then Loosen two screws on the universal turn the antenna upward as joint shown below. 3. Mount the loop to the pole arm, 4. -
Page 11: Web Login
1. Remove the mounting plate, and 2. Mount the camera installed with install it to the screw hole on the plate to the PT mount. camera. In the figure below, 1 is mounting plate, 2 is the screw hole. 3. Install the PT mount to the tripod, and adjust the tripod to desired monitoring direction. - Page 12 NOTE! DHCP is enabled by default. If a DHCP server is deployed in the network, the IP address of your camera may be assigned dynamically, and you need to use the actual IP address to log in. Install the plug-in as prompted at your first login. Close all your browsers during ...
- Page 13 The product described in this manual may contain proprietary software owned by Uniview and its possible licensors. Unless permitted by Uniview and its licensors, no one is allowed to copy, distribute, modify, abstract, decompile, disassemble, decrypt, reverse engineer, rent, transfer, or sublicense the software in any form by any means.
-
Page 14: Disclaimer Of Liability
To the extent allowed by applicable law, in no event shall Uniview’s total liability to you for all damages for the product described in this manual (other than as may be required by applicable law in cases involving personal injury) exceed the amount of money that you have paid for the product. - Page 15 Keep firmware up to date: It is recommended that your device is always upgraded to the latest version for the latest functions and better security. Visit Uniview's official website or contact your local dealer for the latest firmware. The following are recommendations for enhancing network security of your device: ...
- Page 16 Verify that the device is properly installed before connecting it to power. Do not remove the seal from the device body without consulting Uniview first. Do not attempt to service the product yourself. Contact a trained professional for maintenance.
-
Page 17: Regulatory Compliance
(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Visit http://en.uniview.com/Support/Download_Center/Product_Installation/Declaration/ for SDoC. Caution: The user is cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. - Page 18 WEEE Directive–2012/19/EU The product this manual refers to is covered by the Waste Electrical & Electronic Equipment (WEEE) Directive and must be disposed of in a responsible manner. Battery Regulation- (EU) 2023/1542 Battery in the product complies with the European Battery Regulation- (EU) 2023/1542.
