  • Page 1 G50 GNSS Receiver User Manual Guangzhou GEOSURV Information Technology Co.,Ltd. 2024/12/16...
  • Page 2: Table Of Contents

    2024/12/16 ........................1 Chapter I: Overview ........................- 1 - §1.1 Introduction ........................ - 1 - §1.2 Highlights of G50 ...................... - 1 - §2.1 Introduction ........................ - 2 - §2.2 Introduction of G50 ....................- 4 - §2.2.1 Structure and Interface ..................- 4 - .......
  • Page 3 §2.3.3 Bluetooth Connection ..................- 9 - §2.4 Introduction of Accessories ..................- 10 - §2.4.1 Packing List of G50+P3 ..................- 10 - §2.4.2 Charger ......................- 10 - §2.4.3 UHF Radio Antenna ..................- 11 - §2.4.4 TYPE - C Cable .................... - 11 - Chapter III: Mode Setting ......................
  • Page 4: Chapter I: Overview

    2. Clearer & Brighter Laser Spot Emitting Class 2 red laser, G50 targets the objects in a brighter and clearer laser point, achieving more efficient laser measurement. 3. Measure any Objects Accurately With higher-intensity laser emission and superior reflectivity, G50 maintains stable raging results in measuring objects, regardless of their colors and materials.
  • Page 5: Chapter Ii: Product Introduction

    7. Up to 120 ° Tilt Within 2.5cm Accuracy The use of fourth-generation measurement technology ensures the G50 can still get fixed for tilt measurement work at even 120°measurement angles. 8. G-FIX Correction outage Technology Extending Fix solution up to 10 minutes Reducing downtime waiting to re-establish RTK corrections 9.
  • Page 6 - 3 -...
  • Page 7: Introduction Of G50

    §2.2 Introduction of G50 §2.2.1 Structure and Interface Sticker and Serial number SIM card interface Type-c interface Connecting UHF antenna interface screw hole Camera Laser module Camera - 4 -...
  • Page 8: Buttons And Indicators

    Charging and data transmission UHF Antenna interface Built-in radio: supports low power and high power options Connecting screw hole Used to fix the G50 on the base or pole Serial number To identify each device and register code Sticker To show some information about G50...
  • Page 9: Function Of Button

    When G50 is working normally, click the power button, then a voice will broadcast the current working mode. (mode, communication mode, solution state) Ⅱ Power on In shutdown state, long press the power button, when G50 ticks and all the lights on, release the button and G50 will power on. Ⅲ Power off In boot on state, long press the power button, when the voice broadcast "press again to power...
  • Page 10: P3 Controller

    §2.3 P3 Controller §2.3.1 Appearance - 7 -...
  • Page 11: Keyboard

    §2.3.2 Keyboard Section Specification Numeric keys Enter numbers Special Orange icons take effects when "Fn" is locked function key The functions of F1-F6 can be customized by users in "Settings" Power button Turn on/off device/sleep/wake up @key Enter the character @ Input method sw Input uppercase/lowercase/digital switch itching...
  • Page 12: Bluetooth Connection

    §2.3.3 Bluetooth Connection Start the G50 first, and then use P3 controller to perform the following operations: 1. Open CreateYours software and click "Connection" to enter the connection interface. 2. Select the manufacturer as "GINTEC", the device Model as "RTK", and the communication mode as "Bluetooth"...
  • Page 13: Introduction Of Accessories

    2.4 Introduction of Accessories § §2.4.1 Packing List of G50+P3 §2.4.2 Charger Standard configuration includes charger and charging cable: While charging, when the power indicator is red, it means charging; when the indicator is - 10 -...
  • Page 14: Uhf Radio Antenna

    UHF radio antennas are required for the built-in radio Base mode and the built-in radio Rover mode. §2.4.4 TYPE - C Cable TYPE - C cable is to connect the G50 with computer, used for transmission of static data or receiver firmware upgrading. - 11 -...
  • Page 15: Chapter Iii: Mode Setting

    §3.1.3 Rover Setup After successful set up of the base station, now we can start the rover setting. Install the G50 on the centering lever, install the radio antenna, bracket, clamp the controller. The steps are as follows: - 12 -...
  • Page 16: Rtk Mode(Network Mode

    Set up the tripod, fix the G50. §3.2.2 Starting Base 1) After setting, please make sure there is a workable Sim card inside G50 base. Then open CreateYours in the controller, Click "Device"→ “Base” to set Base station. - 13 -...
  • Page 17: Rover Setup

    §3.2.3 Rover Setup After successful set up of the base station, now we can start the rover setting. Install the G50 on the centering lever, install the bracket, clamp the controller. The steps are as follows: 1) Turn on the G50 and controller, open CreateYours software and connect Bluetooth.
  • Page 18: Laser Measurement

    When it shows "Fixed", it is correctly setting, now you can start the surveying work. § 3.3 Laser Measurement 1)Turn on CreateYours software, Click "Device"- “Connection”, Connection Mode choose "WIFI" 2)Click "Rover" - Choose “Controller/Receiver Internet” and finish the “CORS setting” to make the G50 meet “Fixed” solution. - 15 -...
  • Page 19 3)Go to “Survey” interface, click “ Point Survey” There will pop up a window to inform you to confirm the antenna height so that IMU Sensor works well. Do make sure the antenna height is the correct height. Then click “Confirm”...
  • Page 20 Find the Laser icon in the list on the left to turn on Laser. If you can’t find this icon, you need go to the “Setting” interface to add the Laser first from the “TOOL Bar”, then click “Confirm” to add it. If the IMU is not ready, there will pop up a window to inform you “...
  • Page 21 Observe the Y value in the upper right corner, if the value is greater than 0.2, it means that the current laser acquisition accuracy is not optimal, at this time, you need to hold the pole and walk around for a few seconds, and observe that the Y value is less than 0.2 - 18 -...
  • Page 22 § 3.4 Laser Stakeout 1) Make connection to G50 Receiver by CreateYours software, do the operation as above Rover setting in “Laser Measurement” and make G50 meet fix solution. 2) Click "Survey" - “Point Stakeout”, choose the point what you want to stakeout and click "Laser"...
  • Page 23 Note: While staking out points, do make sure the Y value is below 0.2. § 3.5 AR Stakeout 1) Turn on CreateYours software, Click "Device"- “Connections”, Connection Mode choose "WIFI" - 20 -...
  • Page 24 2) Click "Survey" - “Point Stakeout”, choose the point what you want to stakeout and click "AR" 4)Find lofting points by following the arrows and line segments.(This is the phone AR mode,The camera settings for the lofting can be changed through settings) When the Default stakeout mode is set to“Phone AR+RTK AR”, the RTK AR prompt Range(m) is the boundary distance between the phone AR and the RTK AR.(e.g.If set to 10 meters, when the device distance from greater than 10m to less than 10m,the mobile phone...
  • Page 25: Chapter Iv: Web Ui

    Chapter IV: WEB UI §4.1 WEB UI Login Start the G50 properly, use a mobile terminal such as a laptop or mobile phone, open WiFi, and find the G40Plus hotspot. The hotspot name format is the device SN number. After connecting successfully, enter 192.168.10.1 in the browser and go to the WEBUI background...
  • Page 26: Common Function From Web Ui

    The user name and password needs to be entered when first time login WEBUI through a new browser. User name: admin Password: password §4.2 Common Function from WEB UI §4.2.1 Code Registering Click "Management-System Manage"-”Device Registration”, you can paste the register code here to active the G50. - 23 -...
  • Page 27: Time Zone Setting

    §4.2.2 Time Zone Setting Click "Settings-Parameter Setting", where you can modify time zone. You can also modify other parameters here. §4.2.3 Data Download Methods I: WEBUI Click "File Upload and Download - Raw Data", choose the right data format and date to get the data list.
  • Page 28: Device Firmware Update

    Methods II: USB cable Connect G50 with your PC by USB to Type-C cable, your computer will automatically read a G50 storage folder. Open it and choose the "record" to the folder you want and download the file you need.
  • Page 29: Appendix A: G50 Technical Specifications
