- Page 1 G30 Gnss Receiver User Manual 12/28/2021...
-
Page 2: Table Of Contents
Menu Chapter I: Overview ....................... - 1 - § 1.1 Introduction ....................... - 1 - § 1.2 Highlights of G30 ...................... - 1 - Chapter II: Product Introduction ................... - 4 - § 2.1 Introduction ....................... - 4 - § 2.2 Introduction of G30 ....................- 4 - §... - Page 3 § 4.2.2 Language/Time Zone Setting ............... - 23 - § 4.2.3 Data Download ..................... - 23 - § 4.2.4 Device Firmware Update ................- 24 - Appendix A: G30 Technical Specifications ................- 25 - Appendix B: Packing List ....................... - 27 - - 2 -...
-
Page 4: Chapter I: Overview
//www.gintec.cn/. This manual is G30 measurement system as an example, for how to install, set up, upgrade, daily maintenance, the use of accessories and how to use RTK system operation to explain. Even if you have used other models of RTK products of our company, it is recommended that you read this instruction carefully before using the instrument for better use. - Page 5 G30 GNSS Receiver User Manual Type-c interface design and PD fast charging scheme make charging and transmission more convenient and efficient ➢ All constellation all frequency point Full constellation full frequency point reception, fully support Beidou third generation satellites, support ups to 16 frequency signal calculation.
- Page 6 G30 GNSS Receiver User Manual Optional PPP differential function can provide centimeter-level differential positioning services in the Asia-pacific region. - 3 -...
-
Page 7: Chapter Ii: Product Introduction
By reading this chapter, you can master the composition, installation, and functions of the G30 measurement system in detail. § 2.1 Introduction G30 measurement system is mainly composed of host, manual and accessories, as shown in the figure: Schematic diagram of G30 measurement system §... - Page 8 As a power interface, can be connected to power bank and other power supply equipment. As a serial port output Five-pin power interface interface, you can view the output data and debug G30 through the serial port software UHF antenna interface...
-
Page 9: Buttons And Indicators
G30 GNSS Receiver User Manual § 2.2.2 Buttons and Indicators G30 has four indicators and one button.: Buttons and indicators Function Condition Power on, power off, confirm the Switch on/off, modification item, and select the confirm, modify modification content Bluetooth indicator... -
Page 10: Function Of Button
Ⅳ Mode setting In boot on state, press the power button for more than 6 seconds and release, G30 will say "Start to set work mode", then take turns playing the various work modes. Click to select the mode you want to set when broadcasting Ⅴ... -
Page 11: P9Iii Controller
G30 GNSS Receiver User Manual Ⅵ Restore factory setting Long press the power button for more than 20 seconds and it will say “start to restore manufactory default”, release to restore factory settings. § 2.3 P9III Controller § 2.3.1 Appearance §... - Page 12 G30 GNSS Receiver User Manual Description Number Number keys 0-9,input number keys（also can be used to make phone call in /alphabet special model.） The second function keys（Press “Shift” key at the same time）: keys 1- ！,2- @,3- #,4- $,5- %,6- ^,7- &,8-*,9- (,0- ) Alphabet keys A-Z, input alphabet.
-
Page 13: Connector
TF card slot To install TF card. § 2.3.4 Bluetooth Connection Start the G30 first, and then use P9III controller to perform the following operations: 1. Open SurPad/Create Yours software and click "Communication" to enter the connection - 10 -... -
Page 14: Introduction Of Accessories
G30 GNSS Receiver User Manual interface. 2. Select the manufacturer as "Gintec", the device as "G30", and the communication mode as "Bluetooth". 3. Select the corresponding SN and click "Connect". The connection succeeds after the progress bar ends. 2.4 Introduction of Accessories §... -
Page 15: Uhf Radio Antenna
UHF radio antennas are required for the built-in radio Base mode and the built-in radio Rover mode. § 2.4.4 TYPE - C Cable TYPE - C cable is to connect the G30 with computer, used for transmission of static data or receiver firmware upgrading. - 12 -... -
Page 16: Chapter Iii: Mode Setting
3) Record SN, point name, instrument height and start time. 4) Switch on the G30 and connect with controller software, set the receiver to static mode, and set the parameters as the picture shows. (The memory capacity of G30 must be sufficient. -
Page 17: Rtk Mode（External Radio
Setting steps: Set up the tripod as shown in the figure above, hang up the radio, fix the G30, and connect the extension rod and the large radio transmitting antenna. -
Page 18: Starting Base
1) Open SurPad in the controller, Click“Device”→“Base” to set Base station. 2) Under “Base Mode Settings”, Choose “Data link” to be “External Radio” and apply. 3) Disconnect G30 receiver and Open “External Radio Configuration” under “Tools” in SurPad. - 15 -... - Page 19 G30 GNSS Receiver User Manual 4) In “External Radio configuration”, choose “Radio type” to be “Geoelectron” and “Connection mode” to be “Bluetooth”, then search TRU35 radio and connect it.(Pairing code is “1234”). 5) After connected, you will come to “Functional selection” interface, click “Parameter settings”, click “Get”...
-
Page 20: Rover Setup
G30 GNSS Receiver User Manual § 3.2.3 Rover Setup After successful set up of the base station, now we can start the rover setting. Install the G30 on the centering lever, install the radio antenna, bracket, clamp the controller. UHF Antenna Pole... -
Page 21: Rtk Mode（Internal Radio
Do not set it up near high-voltage power transmission, transformation equipment, near radio communication equipment antenna, or under trees and near water. Set up the tripod as shown in the figure above, fix the G30, and connect the radio antenna. § 3.3.2 Starting Base 1) Open SurPad in the controller, Click “Device”→... -
Page 22: Rover Setup
Do not set it up near high-voltage power transmission, transformation equipment, near radio communication equipment antenna, or under trees and near water. Set up the tripod as shown in the figure above, fix the G30, and connect the radio antenna. § 3.4.2 Starting Base 1) After setting, please make sure there is a workable Sim card inside G30 base. -
Page 23: Rover Setup
§ 3.4.3 Rover Setup After successful set up of the base station, now we can start the rover setting. Install the G30 on the centering lever, install the radio antenna, bracket, clamp the controller. The steps are as follows: 1） Turn on the G30 and controller, open SurPad software and connect Bluetooth. - Page 24 G30 GNSS Receiver User Manual 2） Clip “Device” - “Rover”, choose “Data link” as “Phone/Device Internet”(When use “Device Internet”, please input the correct the APN setting as your mobile network service provider ask for). 3） Clip “Cors Setting” and choose the same item as what your base used.
-
Page 25: Chapter Iv: Web Ui
Chapter IV: WEB UI § 4.1 WebUI Login Start the G30 properly, use a mobile terminal such as a laptop or mobile phone, open wifi, and find the G30’s hotspot. The hotspot name format is “GINTEC_XXXX”(GINTEC_3260). After connecting successfully, enter 192.168.10.1 in the browser and go to the WebUI background page. -
Page 26: Language/Time Zone Setting
Methods II: USB cable Connect G30 with your PC by USB to Type-C cable, your computer will automatically read a G30 storage folder. Open it and choose the “Date – Format” to the folder you want and download the file you need. -
Page 27: Device Firmware Update
Methods II: USB cable Connect G30 with your PC by USB to Type-C cable, your computer will automatically read a G30 storage folder. Copy the firmware to this folder and restart the G30 to automatically upgrade the firmware. - 24 -... -
Page 28: Appendix A: G30 Technical Specifications
G30 GNSS Receiver User Manual Appendix A: G30 Technical Specifications Configuration Detailed Indicators 1 5 9 8 Channels GPS: L1/L1C/L2C/L5 /L2P/ GLONASS: G1/G2/G3 BDS-2: B1I/B2I/B3I BDS-3: B1I/B3I/B1C/B2a/B2b Signal Tracking Galileo: E1/E5a/ E5b/ E6C Measurement SBAS: L1 Performance QZSS: L1 /L2C/ L5... - Page 29 G30 GNSS Receiver User Manual : –25 °C~+65 °C Operating Temperature : –35 °C~+80 °C Storage Humidity 100% Non-condensing IP68 Protection Withstand 2 meters pole drop Shock Power Supply 6-28V DC, overvoltage protection Power and Internal Li-on, 6800mAh, 7.2V Battery...
-
Page 30: Appendix B: Packing List
G30 GNSS Receiver User Manual Appendix B: Packing List - 27 -...
