BM-02 BABY BREATHING MONITOR
We would like to congratulate you on the birth of your child and thank you for buying our product. With this
monitor you can be at ease while your baby is asleep.
BM-02 BABY BREATHING MONITOR
The BM-02 Baby breathing monitor is a certifi ed Class IIb medical device that monitors a baby's breathing.
It cannot be used to restore vital functions and is not a therapeutic device. It does not replace proper childcare.
It is intended for use by health care providers and for care in the home environment. The product is intended to
provide a warning, by an optical and acoustic warning, that the respiration has stopped or the respiration rate has
decreased. It thus warns of the possible danger of respiratory arrest that may occur in young infants (for example,
due to sudden infant death syndrome - SIDS) or due to other causes (suffocation, an illness, etc.). Due to the
nature and purpose of use, no side effects and other contraindications are known.
BM-02 consists of a sensor pad with a sensitive detector that is placed under the baby's mattress and of an
electronic unit with indication lamps and an acoustic alarm. The device has a very simple control. It is battery
operated and runs its proper function auto-test upon startup. It does not affect or restrict the baby's movement.
In oxygen-enriched environments just the sensor pad can be used.
Recommended measures to reduce the risk of SIDS
o
Do not put the baby to sleep on her tummy but on her back or side.
o
Do not smoke during pregnancy and after childbirth in the presence of the baby, not even within resi-
dential premises. Nicotine has a proven inhibitory effect on the baby's respiratory center. Its presence
was repeatedly detected in the blood of dead babies. When in contact with her baby a mother-smoker
exhales cigarette smoke and nicotine residues even 30 minutes after fi nishing her last cigarette!
o
Make sure the baby is neither too warm nor too cold during sleep. Hyperthermia may boost bacteria
growth in the airways. Their presence may trigger a complex immunologic response that may even lead
even to a respiratory center arrest.
o
Leave the baby's head uncovered. Do not place any soft covers and pillows in the crib of a baby that is
not at least 12 months old and that could pull such covers or pillows over her head.
o
Do not use any straps in the crib, make sure the baby's toys are free of strings or tapes longer than 30
cm. Never place plastic bags in the crib.
Product designation
3
MFV52125
(859405253BM02ES)
EN
Advertisement
Table of Contents
Related Manuals for nanny BM-02
Summary of Contents for nanny BM-02
- Page 1 BM-02 consists of a sensor pad with a sensitive detector that is placed under the baby’s mattress and of an electronic unit with indication lamps and an acoustic alarm. The device has a very simple control. It is battery operated and runs its proper function auto-test upon startup.
-
Page 2: Installation Instructions
Warning: The BM-02 does not prevent the occurrence of sleep apnea in an infant! If operated and used in accor- dance with this manual, the monitor is unlikely to fail. Installation instructions 1. Place the sensor pad into the crib (pram, Moses basket, etc.) under the mattress (or cushion) underneath the area where the baby will be sleeping –... -
Page 3: Alarm Status
– it fl ickers to indicate a low battery. Using the BM-02 monitor Before using the BM-02 read this manual carefully, especially paying close attention to the chapter “First Aid – General Procedures of Emergency Child Care”! More information can be found at: www.monitor- nanny.com. -
Page 4: Function Test
Check the operation of the device as follows (recommended testing frequency is once a week): 1. When the baby is in the crib and the BM-02 is on, the green indicator must fl icker with the rhythm of the baby’s breath. -
Page 5: Battery Replacement
10 m from any part of the BM-02. Interferences can prevent the BM-02 from monitoring the infant‘s breathing. Therefore we always recommend you to test the device functions before use. You should avoid using mattresses made of hard materials (foam polystyrene, etc.) that absorb dis- turbing vibrations caused by the movement of the ambient air. - Page 6 We will be happy to help you solve any problems so that the BM-02 can keep a reliable eye on your baby. However, if a technical defect occurs, we will fi nd the best solution for you as soon as possible so that your baby is not left unmonitored.
-
Page 7: Technical Data
Technical data Power 3 V 2×1.5 V AA LR6 size alkaline batteries Standby current 0.2 mA Alarm current 100 mA Battery low indication level 2.38 V ± 0.15 V Monitored breathing frequency <8 breaths/minute (i.e.<0.13 Hz) Average battery life - home health care 6 months (gets reduced by frequent alarm testing) Average battery life - health care providers 4 months (gets reduced by frequent alarm testing) - Page 8 BM-02 Usability Specifi cations 1. Designated health indications The BM-02 breathing monitor can be used to preventively monitor breathing in healthy individuals (children). It is recommended to monitor the following indications: Whooping cough - the monitor is recommended for 1 month after diagnosis - however, many children have coughing fi...
- Page 9 3. The BM-02 medical device is not intended for direct contact or transferred contact with the patient’s body. 4. Minimum specifi ed user profi le Age: 12 years + , with the ability to judge appropriate to his or her age.
-
Page 10: General Procedures For Child Emergency Care
General procedures for child emergency care First aid – steps designed to save someone’s life in the case of arrested breathing or blood circulation. Warning: First aid should be administered by an experienced fi rst-aider! The basic procedures of child emergency care include a sequence of steps designed to restore suffi cient breathing and blood circulation in children who have suffered breathing or blood circulation arrest. - Page 11 If the respiration problem continues, repeat the individual steps 1–3 times and call – or have somebody call – your local emergency telephone number 999 or 112. 3. Restore breathing Listen and look to check whether the baby is breathing (Fig. 5). If the baby does not breathe, start rescue breathing immediately;...
- Page 12 After completing every 3rd to 5th cycle check whether respiration and blood circulation have been restored. 5. Putting the baby in the recovery position If your resuscitation efforts are successful and the baby’s respi- ration and blood circulation are restored, put her in the recovery position.
