Before you begin
The front roller blind is the highest and closest to you, so make sure
that when marking the place where you will place the brackets, the
rounded part of the bracket is pointing downwards.
Fitting the brackets
The brackets offer three methods of installation:
Top-Fixing
Where the brackets are
screwed into the lintel (or
'ceiling' of the recess)
Page 1 of 6
If you upgraded to our Twist2Fit system, skip to page 3.
Face-Fixing
Where the brackets screw
into a facing surface (a
wall or window frame)
Side-Fixing
Where the brackets are
screwed into the side
walls of the recess
Control Side
On the control side, clip the chain runner attachment
into the slot in the centre of the bracket (not required
for SmartView Blinds). On the opposite side, clip the
circular tabs into the cross sections of the bracket.
Installation Guide
Double Roller Blinds
Front
Blind
Rear
Blind
Top Tip
Top-fixing or face-fixing are
recommended for most
installations, whereas
side-fixing is only
recommended if the width you
gave us was taken right at the
top of the recess.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for TUISS SmartView
Summary of Contents for TUISS SmartView
- Page 1 On the control side, clip the chain runner attachment into the slot in the centre of the bracket (not required for SmartView Blinds). On the opposite side, clip the circular tabs into the cross sections of the bracket. Page 1 of 6...
- Page 2 Installation Guide Double Roller Blinds Fitting a standard or SmartView Double Roller Blind Front blind (reverse roll) Back blind (standard roll) Install the rear blind first. Begin by placing the spring-loaded pin into the lower cross-shaped hole on the bracket. Push the blind toward the bracket so the spring-loaded pin depresses.
- Page 3 Installation Guide Double Roller Blinds Fitting a Double Twist2Fit Roller Blind Front blind (reverse roll) Back blind (standard roll) Starting with the blockout (front) blind, insert the blind into the recess at an angle and push the tightener against the wall. Lift the control end of the blind until level and release pressure, the blind will hold itself in place.
- Page 4 Installation Guide Double Roller Blinds For larger blinds: Hold the blind securely in place and turn the tightening wheel to tighten the blind in place. If the tightener is on the left side of the blind turn it towards you. If it’s on the right, turn it away from you. Tightener on the left Tightener on the right Once the blind is secured in place, turn the end cap...
-
Page 5: Child Safety
Installation Guide Double Roller Blinds Child Safety Not applicable for SmartView Double Roller Blinds Young children have died by wrapping loose curtain and blind cords or chains around their necks. Secure cords or chains with cord guides or keep them out of reach by winding them around a cleat. - Page 6 On the front of the swing tag that comes with each blind, you’ll find a handy QR code you can scan with your phone. Scan this to download the SmartView app - you’ll be setting up your blinds in moments!
