- Page 1 SV3C CLOUD SECURITY CAMERA Indoor Quick Installation Guide Thank you for choosing our security camera. Please read the quick installation guide carefully before using and keep it in good conditions. After-Sale Technical Support: info@sv3ccloud.com...
-
Page 2: Table Of Contents
Catalogue I. Product Packing List ..........1 ll. Appearance Brief ..........2 Ill. Product Instructions .........3~13 ..........3 1.APP Download and Installation ...........4~5 2.Accounts Registration ...........6~8 3.Device Adding ..........9 4.Function Overview ..........10 5.Motion Detection Setting ..........11 6.How to Store Recordings ..........12 7.Video Playback ..........13 8.Camera Sharing ..........14... -
Page 3: Product Packing List
I. Product Packing List 1 Camera 3 Screws 1 Power Adapter Type-C cable Bracket 3 Expansion Bolts 1 Speci cation 1 Quality Certi cate 1 Location Sticker... -
Page 4: Ll. Appearance Brief
II. Appearance Brief TF Card Camera Lens Infrared LEDS Reset Button Status Light Laser for Cats One Touch Call Speaker Power Port Warning: 10ft length cable is provided in package. If it is not long enough, please use extension cord (not included) to ensure the best performance of the camera, not the USB extension cable. -
Page 5: Ill. Product Instructions
III. Product Instructions 1. APP Download and Installation SV3C Cloud is available for both iOS and Android OS. Search the name 'SV3C Cloud' in App Store or Google Play, or scan the QR-Code to download the App. ·Support ipad Android Android OS Download App(IOS&android) -
Page 6: Accounts Registration
2. Accounts Registration Registration process Open the App, click "Sign up now" to register. Step 1: If you already have an account, click “Log in”. Input a legal Email address and �ck the privacy aggreement. Step 2: Then enter the nickname and password. Notes: 1) Please �ck “Agree”... - Page 7 Before you start to pair the camera to the WiFi, please make sure your smartphone is in 2.4G WiFi Signal. 2.4G If you can not see the 2.4G signal in the se�ng of the WLAN, you can turn it on from your router. All routers, no ma�er 5G or dual channel comes with 2.4G signal.
-
Page 8: Device Adding
3. Device Adding Step 1: Refer to the le�most image. Click the "+" in the upper right corner, you can either click "Add Device" directly to add the camera. or select "Scan Code" (skipping the camera model matching step), and scan the QR code on the camera to enter the configura�on. - Page 9 Step 3: View the opera�on instruc�ons of scanning, and then click “Next”. Scan the QR code in your phone with the camera and click “Next”, when the camera comes out "dong dong dong". And you can complete the configura- �on about 30s. Step 4: When connec�ng, you should make sure your router, mobile, and camera are as close as possible.
- Page 10 Step 5: All done. You have added the camera successfully to your phone.Begin to monitor your home. Step 6: In live view interface, click " ", and then you can set up the camera common func�ons.
-
Page 11: Function Overview
4.Function Overview 1. Time Stamp 10. Microphone 2. Mute Bu�on 11. Laser Light 3. Se�ngs 12. Call Pet 4. Network Speed 13. Tease Pet Regularly 5. Resolu�on Bu�on 14. Mo�on Detec�on 6. Full Screen 15. Playback 7. PT Control Panel 16. -
Page 12: Motion Detection Setting
5.Motion Detection Setting ① A�er turning it on, you can choose different detec�on sensi�vi�es to monitor the movement of objects in front of the device and issue an alarm. ② It is possible to choose different detec�on sensi�vi�es. ③ A�er being turned on,an alarm will be issued when a pet appears in front of the device. -
Page 13: How To Store Recordings
6.How to Store Recordings 1. Stored By Manual Go to live video, manually record the video by clicking ‘Record’ bu�on to start or end, exis�ng the live view will automa�cally stop recording. 2. Memory Card The camera supports micro SD card(NOT INCLUDED), up to 128GB. 3. -
Page 14: Video Playback
7.Video Playback 1. Video Playback in SD Card ① Go to the main interface, click “playback” to enter the History, you will see today's mo�on detected events. By sliding the gray progress bar, you can select and play historical video footage. -
Page 15: Camera Sharing
8.Camera Sharing If you need to view the camera with other family members or friends, you can use this device sharing func�on. Only the administrator whose account is bound with the camera for the first �me can share and set the device. Other members can only view the live or playbacks of the device. -
Page 16: Image Settings
9.Image Settings. ① Screen Flip ② Color Mode & Night Vision Mode Selec�on... -
Page 17: Pet Entertainment Features
IV. Pet Entertainment Features 1. Laser Light Click on the "Laser Light" icon in the main interface to enter the laser mode for entertaining your cat. ① Manual Control Mode: Use the PT console to control the laser's path manually. ②... -
Page 18: Call Pet
2.Call Pet Click on "Call Pet" in the main interface, where you can choose from three preset sounds: Ki�en Call, Female Cat Call, and Kibble Sound. You can also record your own custom sound. As shown in the image, click on "Voice Se�ngs" and hold the bu�on to record a voice message. -
Page 19: Tease Pet Regularly
3.Tease Pet Regularly Click on "Tease Pet Regularly" in the main interface to enter the page, where you can view the preset cat-teasing se�ngs. Click the "+" icon in the top right corner to create a new cat-teasing schedule. -
Page 20: Tease Pet Duration
4. Tease Pet Duration. Go to the se�ngs page and click on "Pet Teasing Management" to set the dura�on for teasing your pet. -
Page 21: Installation Instructions
V. Installation Instructions Use the 2 large screws included in the box to fix the bracket to the posi�on where you need to install it. Put the product directly on a clean and flat table. -
Page 22: Troubleshooting
VI. Troubleshooting 1. APP can't be registered successfully ● Please check if the network of the mobile phone is normal; ● Please �ck the so�ware service agreement and privacy policy; ● Please check if the verifica�on code is in the spam mail; ●... - Page 23 MAC se�ngs of the router; ● Connect the network cable to your computer firstly, then check the computer and obtain the IP address. If the IP address of the computer is se�ed by manual, please go to the router and enable the DHCP server to obtain the IP address;...
- Page 24 5. Motion detection messages prompt frequently ● If mo�on detec�on sensi�vity is too high, light changes also can cause alarm; ● Reduce sensi�vity of alarms (recommended low level). 6. After inserting SD, it displays damaged ● Before inser�ng the SD card, Disconnect the power. Connect the power to start a�er plugging in the card;...
- Page 25 Sign in your router account, Rename your Wi-Fi with 2.4G and 5G respec�vely for easy dis�nc�on.(Do not use 5G preferred,2.4Ghz & 5Ghz will mix together if you open it, You don't know whether you have connected to 2.4Ghz Wi-Fi or 5Ghz Wi-Fi) ...
-
Page 27: Notification Of Compliance
Notification of Compliance FCC Compliance Statement This device complies with Part 15 of the FCC Rules. Opera�on is subject to thefollowing two condi�ons: (1) this device may not cause harmful interference, and (2) this device must accept any interfer- ence received, including interference that may cause undesired opera�on. -
Page 28: Security Camera
SECURITY CAMERA Indoor Official Website: www.sv3c.com A�er-Sale Technical Support:info@sv3ccloud.com...
