Ram Mounts GDS Tab-Conn Assembly & Disassembly Instructions

Parts Index
* not to scale
A
(1) Tab-Conn Body
™
WARNING:
If you are using a tablet with a case, tablet cannot be removed from case unless GDS
removed from tablet.
How to Assemble
If you are using a case, ensure tablet is properly
1
installed in the case and that the back of your case is
thoroughly cleaned. If you are not using a case,
ensure the back of your tablet is thoroughly cleaned.
Adhere one side of all (B) Adhesive Pads to the
2
inside cavities of the (A) Tab-Conn
B
Carefully peel away remaining film from each (B)
3
Adhesive Pad.
TIP: Use of tweezers or
needle nose pliers may
aid in removing film
To see more mounting options, visit rammount.com
rammount.com
1.800.497.7479
support@rammount.com
B
(16 ) Adhesive Pads
.
™
This document, including images, may not be reproduced partly or fully without the expressed written consent of National Products, Inc.
GDS
®
C
(1) USB-C Cable
Style may vary
While holding upside down, align bottom of (A) Tab-Conn
4
to be centered with the USB-C port of your tablet. Keep
angled away to prevent adhesives from making contact with
tablet. Once fully aligned, bring (A) Tab-Conn
to back of tablet. Press firmly and evenly for proper
connection.
Connect straight end of (C) USB-C Cable into back of (A)
5
Tab-Conn . Connect 90-degree angle side of cable into
™
A
the USB port of your tablet.
Insert (D) Cable Cover into back of (A) Tab-Conn
6
clicking into place and covering USB connection.
Tab-Conn with Rear Pogo Pads
™
Assembly & Disassembly Instructions
Patented & Pats. Pend
D
(1) Cable Cover
® Tab-Conn ™ is fully disassembled and
A
A
A
RPR-INS-GDS-TABC1B
.
rammount.com/ip
E
(1) Hand Strap
™
in to adhere
™
A
C
,
™
D
