B. Memory Capacity
DIMM Socket
Location
DIMMA1
DIMMB1
C. Dual Channel Memory installation
To trigger the Dual Channel function of the motherboard, the memory module
must meet the following requirements:
Install memory module of the same density in pairs, shown in the following
table.
Dual Channel Status
Disabled
Disabled
Enabled
(O means memory installed, X means memory not installed.)
The DRAM bus width of the memory module must be the same (x8 or
x16)
GF8100 M2+ TE/GF8200C M2+
DDR2 Module
256MB/512MB/1GB/2GB/4GB
256MB/512MB/1GB/2GB/4GB
DIMMA1 DIMMB1
O X
X O
O O
Total Memory
Size
Max is 8GB.
