SALSA SAGUARO EXP Series Instructions

At Salsa, we believe that a sense of adventure makes life better.
The bicycle can be so much more than just a bike; it's a path to
new places, new people, and amazing experiences.
Thank you for your purchase. We hope it makes a good riding
experience even better!
Salsa. Adventure by bike.
®
WARNING: Cycling can be dangerous. Bicycle products
should be installed and serviced by a professional mechanic.
Never modify your bicycle or accessories. Read and follow all
product instructions and warnings including information on the
manufacturer's website. Inspect your bicycle before every ride.
Always wear a helmet.
WARNING: Entanglement of cargo or straps in your wheel could
stop the rotation of the wheel, causing a loss of control or crash
that could lead to serious injury.
WARNING: Make sure that the half frame bag does not interfere
with the function of your bicycle BEFORE attempting to ride.
Ensure even cargo distribution and confirm lights and reflectors
are not obstructed by the bag.
Intended Use & Compatibility
The EXP Series Saguaro Seat Bag is compatible with most saddles
with conventional (2) saddle rails. A minimum of 14 cm / 5.5" of
clearance under the saddle is required.
Max Weight: 2.72 kg / 6 lb
ASTM Condition 2
Intended for ASTM 2 conditions, defined as unpaved
and gravel roads and trails with moderate grades.
In this set of conditions, contact with irregular terrain
and loss of tire contact with the ground may occur.
Drops are intended to be limited to 15 cm / 6" or less.
WARNING:There must be a minimum of 14 cm / 5.5" of
clearance between the bottom of the seat bag and the top of the
rear tire. On full-suspension frames, check to make sure that the
seat bag does not come in contact with the tire when the rear
shock is fully compressed.
Parts Included
• 1 dry bag
• 1 holster
• 1 double-sided hook-and-loop strap
Installation Instructions
1. Remove the dry bag from the holster.
2. Thread the double-sided hook-and-loop strap through the
die-cut slots at the nose of the holster.
3. Align the holster with your saddle, keeping the double-sided
hook-and-loop strap towards the seat post and the Salsa logo
and buckle on top (fig. 1).
1440615 9/23 | 85-001491_INST_A
SAGUARO EXP SERIES SEAT BAG INSTRUCTIONS
For additional product and safety information go to salsacycles.com/support
4. Loosely attach the double-sided hook-and-loop strap around
the seatpost (fig. 1).
5. Locate the two coated hook-and-loop straps that are sewn to
the holster and route each one over the nearest saddle rail
from the inside to the outside (fig. 2). Fasten loosely.
6. Locate the two webbing straps behind the coated hook-and-
loop straps you just fastened. Route each one over the nearest
saddle rail from the inside to the outside (fig. 3). Buckle the
straps, but do not tighten them.
7. Load the dry bag, packing heavier items first. Turn the purge
valve counterclockwise to open it. Close the end of the bag by
pulling the buckles apart from each other and bringing the flat
ends of the bag together. Purge as much air as possible from
the bag and turn the purge valve clockwise to close it. With the
flat ends of the bag lying together, fold the rigid end of the bag
under and over at least three times and snap the buckles
together (fig. 4). If you cannot fold the ends at least three
times, the bag is overstuffed, and you will have to repack or
remove some of its contents.
Figure 4
Figure 1
Figure 2
Figure 3
1
