MiniMalist Rack installation
7
6
Item #
Description
1
Minimalist rack
2
Mounting strut and hardware kit
3
M5 plain washer (narrow)
4
Minimalist thru-hole alloy block
5
M6 x 1 x 50mm bolt
6
M6 nylon lock nut
7
M6 washer
8
M5 x 0.8 x 12mm screw
9
M5 x 0.8 x 16mm screw
8835 04/12
4
3
5
3
9
For additional product and safety information go to salsacycles.com
8
1
9
2
Quantity
1
2
4
1
1
1
2
2
2
2
2
1
