Summary of Contents for iENYRID iE-ES6
- Page 1 iE-ES6...
- Page 2 USER MANUAL PLEASE READ THE INSTRUCTIONS CAREFULLY BEFORE RIDING Scan QR Code Or Enter URL for Online Installation Video https://www.youtube.com/watch?v=LcnNukP-Kmo...
-
Page 3: Read This Manual Before Using
1、 This manual was written to help you understand the proper use and maintenance of the iENYRID line of Electric Scooter. 2、 It is important to understand the functions and features of the new iENYRID before operating it as it will allow you to enjoy it from every ride. -
Page 4: Table Of Contents
CONTENT Product & Component Display ······································································· 1~2 Product Parameters ···················································································· 3 Products & Accessories ··············································································· 4 Product Installation ···················································································· 5~7 Product Folding ························································································ 8~9 Power On & Unlock···················································································· 10 Safe Driving Warning ················································································· 11 Battery & Charging ··················································································· 12~13 Error Code ····························································································· 14 After Sales ·····························································································... -
Page 5: Product & Component Display
Product & Component Display 1.Meter 8.Front motor 15.Disc brake 2.Accelerator 9.Brake disc 16.Taillight 3.Brake 10.Disc brake 17.Seat 4.Pole buckle 11.Turn signal 18.Colored light 5.Pole 12.Rear shock absorber 19.Charging port 20.Folding safety device 6.Headlight 13.Rear motor 7.Front shock absorber 14.Brake disc... - Page 6 Product & Component Display 01.Brake 07.Horn 13.Battery level 02.Upshift 08.Menu button 14.Battery voltage 03.Light switch 09.Gear display 15.Accelerator 04.Power button 10.Speed display 16.Brake 05.Downshift 11.Max speed&Error code 06.Turn signal 12.Total mileage...
-
Page 7: Product Parameters
Product Parameters Model iE-ES6 Tire Size 10 inch Battery 48V/20.8Ah Tyre Type Off-road Air tires Power 1000*2 Charging time 7~9 hours Display Screen Color Frame Material Aluminum alloy Max Speed 55KM/H Net Weight 30.34KG Range 40-55KM Gross Weight 35KG Max Load... -
Page 8: Products & Accessories
Products & Accessories SERIAL NUMBER ITEM QUANTITY Charger Toolkit Seat Bag Instructions... -
Page 9: Product Installation
Product Installation Press down Remove the scooter from the Lift the pole upward folding lever and lift up packaging box the upright lever After the pole is fully Use a tool to remove the Remove the screws and set extended, snap the golden locking screws of the seat them aside safety buckle into place... - Page 10 Insert the screws and secure the Press the seat back and Insert the seat seat install it into place Screw the handle in and Remove screws Lift the handle tighten it completely from the handle...
- Page 11 Match male female Remove the two screws on Take out the meter and secure it connectors, and connect the meter the left and right and set them completely with screws line with the assembly line and aside brake line according to the arrows Press the limit button of the After adjusting to the Release the pole fixing...
-
Page 12: Product Folding
Product Folding Lift the seat base buckle upward and pull back to release the Release the seat fixing buckle Take out the seat bag buckle Push the seat post forward Loosen the handle fixing Fold the handle while pressing inwards and knob level it... - Page 13 Pull back to release the gold Pull the folding lever Folding completed safety buckle back and fold the body...
-
Page 14: Power On & Unlock
5 times in a row to enter the menu settings. Please note that when using this function to adjust parameters, please contact the iENYRID engineer for the operation guide. If you modify the parameters by yourself, it may cause the product to malfunction. -
Page 15: Safety Gear
Helmet: Most common and serious injuries from riding are head injuries. This can be prevented by donning a helmet. You must wear a helmet when riding the iENYRID Scooter. The helmet must be warn according to their instruction. MECHANICAL SAFETY Before using the iENYRID Scooter: 1) Always perform a visual inspection of all screws and nuts are tight and in place. -
Page 16: Battery & Charging
Battery & Charging BATTERY Do not charge indoors. - Do not turn on and operate the scooter while charging. - Keep the battery away from children, pets or direct heat. - Do not expose the battery to high temperature and pressure. - Please use the charger included with the scooter for charging. - Page 17 Battery & Charging First Charge It is important to fully charge the battery before your first use of the scooter. Your scooter’s battery comes with these built-in features: 1. Balanced charging protection: During charging, the battery automatically balances the voltage among the internal cells to protect each cell.
-
Page 18: Error Code
Error Code Error Code Fault Diagnostic Step Solution Check whether the motor line and controller are If there is no problem with each circuit, the E-01 Motor Hall Fault connected normally. motor needs to be replaced. If the brake lever resets normally, the brake E-02 Brake failure Check whether the brake lever is reset. -
Page 19: After Sales
We hope these videos will help you better understand and use our product. If you still have questions or concerns after watching the videos, please feel free to contact our customer service team, and we will be happy to assist you. Thank you again for your purchase and support! Wishing you a pleasant user experience! https://www.ienyrid.com https://www.facebook.com/iENYRID https://www.youtube.com/@iENYRID... -
Page 20: Limited Warranty
11. Defects or damages from improper storage, exposure to moisture or dampness, modifications, connections, repairs (except as carried out by iENYRID or its authorised centres), misuse, neglect, abuse, accident, alteration, improper installation, or other acts which are not the fault of iENYRID, including damage caused by dropping, blown fuses, liquid entering the interior of the product. -
Page 21: Warranty Card
Serial number Model Invoice Number Battery serial number Name Distributor Contact Note Shenzhen Tianshengle Technology Co., Ltd. Address: Room502, 5th Floor, Liuwei Business Center, Yangmei Longjing Road, Longgang District, Shenzhen city, China WhatsApp: +8613612953725 Customer support: support@ienyrid.com Official website: www.ienyrid.com...
