Summary of Contents for iENYRID IE-M1

  • Page 2 USER MANUAL PLEASE READ THE INSTRUCTIONS CAREFULLY BEFORE RIDING Scan QR Code Or Enter URL for Online Installation https://www.youtube.com/watch?v=MdwoDIU-Z4c...
  • Page 3 1、 This manual was written to help you understand the proper use and maintenance of the iENYRID line of Electric Scooter. 2、 It is important to understand the functions and features of the new iENYRID before operating it as it will allow you to enjoy it from every ride.
  • Page 4 CONTENT Product & Component Display ······································································· 1~2 Product Parameters ···················································································· 3 Products & Accessories ··············································································· 4 Product Installation ···················································································· 5~6 Product Folding ························································································ 7 Power On & Unlock···················································································· 8 Safe Driving Warning ················································································· 9 ~10 Battery & Charging ···················································································· 11~12 Error Code ······························································································...
  • Page 5 Product & Component Display 01: Instrument 06: Front shock absorber 11: Kickstand 02: Headlights 07: Motor 12: Folding Hanger 03: Vertical pole 08: Front wheel 13: Tail lights 04: Folding buckle 09: Charging port 14: Brake pads 05: Front fender 10: Pedal 15: Rear wheel...
  • Page 6 Product & Component Display 01: Left Turn Signal 13: Mileage 07: Total mileage mark 02: Brake lever 14: Battery display 08: Left turn signal icon 03: Bell 15: Folding clasp 09: Lamp 04: Turn signal switch 16: Accelerator 10: Real time speed 05: Power on button 11: Right turn signal icon 17: Right Turn Signal...
  • Page 7 Product Parameters iE-M1 Model Tire Siz 10 inch Solid honeycomb tire Battery 36V/12.5Ah Tyre Typ Powe Charging tim 6~8 hours Display Screen Color Frame Material Aluminum alloy Max Spee 35KM/H Net Weigh 15 KG Rang 25-35KM Gross Weigh 17.8 KG...
  • Page 8 Products & Accessories SERIAL NUMBER ITEM QUANTITY Charger Toolkit Instructions...
  • Page 9 Product Installation Remove the scooter from the Lift the scooter's folding stem Secure the folding latch upright packaging box Ensure that the folding buckle is Place the handle into the upright securely locked, which is a Find the four screws in the tool pole prerequisite for safe driving...
  • Page 10 Tighten the four screws on Assembly completed the handlebar bar...
  • Page 11 Product Folding Lower the scooter's folding Break the folding clasp Push the folding buckle's stem outwards safety catch upwards Locate the slot corresponding Folding to the latch to fix...
  • Page 12 Power On & Unloc Long press the power button to enter the locking interface of P gear , Press the power button 5 times continuously to release the lock mode of P gear ,Then the operation interface is displayed ,you can adjust the corresponding functions as required.
  • Page 13 Helmet: Most common and serious injuries from riding are head injuries. This can be prevented by dorning a helmet. You must wear a helmet when riding the iENYRID Scooter. The helmet must be warn according to their instruction. MECHANICAL SAFETY Before using the iENYRID Scooter: 1) Always perform a visual inspection of all screws and nuts are tight and in place.
  • Page 14 RIDING SAFETY 1) Put one foot on the board and the other on the ground. 2) Press the accelerator lever slightly, and the scooter accelerate, Put both feet on the board after yo can keep balance. Press down the lever to speed the scooter up. 3) Release the accelerator to slow down, Squeeze the brake lever at the left handle bar to stop the scooter.
  • Page 15 Battery & Chargin BATTERY Do not charge indoors. - Do not turn on and operate the scooter while charging. - Keep the battery away from children, pets or direct heat. - Do not expose the battery to high temperature and pressure. - Please use the charger included with the scooter for charging.
  • Page 16 Battery & Chargin First Charge It is important to fully charge the battery before your first use of the scooter. Your scooter ’s battery comes with these built-in features: 1. Balanced charging protection: During charging, the battery automatically balances the voltage among the internal cells to protect each cell.
  • Page 17 Error Cod Error Code Fault Diagnostic Step Solution voltage low Check if the resistance of the instrument line is too high The battery is dead and needs to be charged. Motor current sensor is If there is no problem with each circuit, the motor Check the line of the phase line of the controller or motor 11/12/ abnormal...
  • Page 18 We hope these videos will help you better understand and use our product. If you still have questions or concerns after watching the videos, please feel free to contact our customer service team, and we will be happy to assist you. Thank you again for your purchase and support! Wishing you a pleasant user experience! https://www.youtube.com/@iENYRID https://www.ienyrid.com https://www.facebook.com/iENYRID...
  • Page 19 11. Defects or damages from improper storage, exposure to moisture or dampness, modifications, connections, repairs (except as carried out by iENYRID or its authorised centers), misuse, neglect, abuse, accident, alteration, improper installation, or other acts which are not the fault of iENYRID, including damage caused by dropping, blown fuses, liquid entering the interior of the product.
  • Page 20 Battery serial number Name Distributor Contact Note Shenzhen Tianshengle Technology Co., Ltd. Address: Room 502 ,5th Floor, Building 1, Liuwei Business Center, No.5, Longjing Community, Yangmei Community, Bantian Street, Longgang District, Shenzhen, China WhatsApp: +8613612953725 Customer support: support@ienyrid.com Official website: www.ienyrid.com...
