- Page 1 USER MANUAL PLE ASE R E AD T H E INST RUCT IONS CARE FULLY BEFORE RIDING TEMPERATURE CONTROL DUAL MOTOR DISC BRAKE SYSTEM Shenzhen Tianshengle Robot Co.,Ltd.
-
Page 2: Table Of Contents
CONTENT · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · GENERAL INFORMATION ·... - Page 3 This manual was written to help you undertsand the proper use and maintenance of the iENYRID line of Electric Scooter. It is important to understand the functions and features of the new iENYRID before operating it as it will allow you to enjoy the most of it from the first and every ride.
- Page 4 MAX SPEED: 25-60KM/ ELECTRONIC BRAKE + MECH DISC BRAKE SYSTEM TURN SIGNAL NFC KEY LOCK CONTROLLER: 52 V /25A*2 ELECTRONIC HORN MAX RANGE: 50-70KM 4.5 INCH LARGE SCREEN LCD BATTERY: 52V/20AH FOLDING SWITCH 1200W REAR MOTOR REAR SUSPENSION PNEUMATIC TYRE 10×3INCH DISC BRAKE SYSTEM DISC BRAKE SYSTEM FRONT SUSPENSION...
- Page 5 Net weight: 30KG Gross weight: 35.5KG Packing Size 135*28*60cm Suspension FRONT-REAR SUSPENSION Motor Power 52V 1200W×2 BRUSHLESS MOTORS Controller 52V/25A*2 Max Load 130KG Maximum load and speed may vary depending on the rider's weight, riding style and terrain. TECHNICAL FEATURES iENYRID...
-
Page 6: Intelligent Temperature Control Management System
Intelligent temperature control management system INTELLIGENT TEMPERATURE CONTROL MANAGEMENT SYSTEM Intelligent overheat protection The intelligent temperature control system will reduce the output current to protect the controller when it detects that the temperature of the controller is too high. At this time, you should stop driving vigorously. If you continue to ride at high power consumption, the intelligent temperature control system will cut off the power supply to the motor. - Page 7 Intelligent temperature control management system iENYRID series electric scooter intelligent temperature control system Model iENYRID ES30 Temperature protection Remove thermal protection 90 ℃ 85 ℃ （Current-limiting） （According to the local topography±5℃） Temperature protection Remove thermal protection （Cut power to the motor）...
- Page 8 NFC card area Speed (KM/H) Speed Level Battery Indicator Basic operation: 1、 Function 1. Displayed content Speedometer / Voltage leve Odometer / Trip meter / Battery level / Cruise-control active light / Gear ondocator / Fault warning light 2.
- Page 9 3.1 Speed display area Unit： MPH/KMH The speed signal is taken from the Hall signal inside the motor.Sent to controller by controller(Time of single Hall period,unit:1MS).The display calculate the true speed based on wheel diameter and signal data calculate the true speed(The motor Holzer also needs to set the number of magnetic steel) 3.2 Vehicle power gear adjustment，...
- Page 10 Display P-Codes(programming codes) To accsee this menu,long-press .Use button to scroll through P-codes, to change parameterd P01：Backlight brightness:The 1 level is the darkest，Level 3 brightest；Default: 3 P02：Mileage: unit,0：KM；1：MILE；Default: MILE P03: Voltage level: 24V, 36V, 48V, 52V, 60V, 72V, Default:52V P04: Dormancy time:0 means no dormancy;Other numbers are dormant time.The range is 1-60 minute.Default:5...
- Page 11 2、Introduction of buttons and interfaces 1. When it is shutdown, long-press hold button continuously for 2s to turn on the power. When it is power on ,It can change interface between the ODO、TRIP、VOL, by pressing for short time.
- Page 12 3、Card binding instructions 1.The instrument is not bound to ID card: After starting up, the LCD displays the normal contents, At this time, the meter can directly enter the working state. The diagram below: 2.How to bind ID card:...
- Page 13 3. The NFC display has been bound with NFC card: after starting up,the LCD screen is displayed as CARD. At this time, the motor does not work.The diagram below: Note:Due to the upgrade of the company's products, some of the displayed contents of the products you get may be different from the instruc- tions, but it will not affect your normal use.
- Page 14 1. Horn 6. Handle Folding Mechanism 2. NFC card area 7. Brake 3. Downshift button/Upshift button 8. Turn signal 4. Turn on the light 9. Throttle 5. Power Switch 10.Single motor dual motor switching iENYRID display operation and porgramming...
- Page 15 Long-press the power button [5] for 2 seconds to turn on/off the scooter, then use NFC card to active it.The scooter Power On/Off turns off automatically if not used for 90 seconds Press the [3] button to cycle through the three different speed levels 1 to 3.Use the throttle to control the speed within Speed Control each speed level.
- Page 16 TURNING IT ON Press the for 3 seconds and wait to be prompted for the Token (Card). Tap the Token (Card) to the IR reader NFC PSETTING Press and hold both simultaneously for 3 seconds to access the P Setting interface.
- Page 17 Downshift button/Upshift button Press the Mode button to cycle through the three different speed levels 1 to 3. Press the left turn button, and the left turn light will flash.When BUTTON FOR TURN you're done turning, press the button again to turn off SIGNAL LIGHTS (BLINKERS) the light.
-
Page 18: Folding Handle Bars
Folding handle bar Turn the handle screw anti - clockwise Once loosen, pull the screw catch away from each other to loose the mechanism Loosen the folding buckle Simultaneously fold the handle bar down Folding handle bar... - Page 19 Folding handle bar Take out the hook Fold down the main pole Snap the handlebar's safety hook into the rear shim Folding handle bar...
-
Page 20: Battery And Charging
The use, storage or charging of the iENYRID battery outside specified limits may result in the annulment of the warranty, battery damage and an effective battery charging,... - Page 21 Battery and charging It is important to fully charge the battery before your first use of the scooter. First Charge Your scooter’s battery comes with these built-in features: 1. Balanced charging protection: During charging, the battery automatically balances the voltage among the internal cells to protect each cell. 2.
-
Page 22: Pre Ride Checks
Pre ride checks PRE RIDE CHECKS The tire is pressurized to the standard value on Brakes are working properly the tire Quick release of handlebar is tight Ensure folding mechanism is fully locked in place with a CLICK sound PRE RIDE CHECKS... -
Page 23: Warning
Helmet: Most common and serious injuries from riding are head injuries. This can be prevented by dorning a 2. Provide MUKUTA with a written description of the problem. helmet. You must wear a helmet when riding the iENYRID. The helmet must be warn according to their instruction. -
Page 24: Limited Warranty
4. Products and/or Components that have been repaired or replaced pursuant to the paragraph above will be covered by this Limited Warranty for the balance of the Warranty Period. 5. This Limited Warranty will only be effective when presented together, to either iENYRID or its authorised centres, with proof of date and place of purchase of Products such as the purchase receipt. - Page 25 What can the consumer do in case of a dispute with iENYRID The consumer and iENYRID agree that in the event of a dispute arising from the material and workmanship of the Product; or from this Limited Warranty, parties will attempt to first resolve the matter by negotiating in good faith.
- Page 26 ERROR CODE Error Code Fault Diagnostic Step Resolution Normally ok; Turn off and on Normal Status the scooter to see if the error Normally ok persists Give the brake lever a few Check brake lever on hard presses to ensure that it handlebar and see if brake is not stuck;...
-
Page 27: Error Codes
ERROR CODES Error Code Fault Diagnostic Step Resolution Check if back screw or Tighten back screw or Turnstile Fault magnet has come loose in replace magnet in the throttle the throttle/LCD Controller Fault Replace controller Replace controller Unplug and plug in LCD connector and see if issue Change of wiring hardness Communication... -
Page 28: Included In The Box
Included in the box SERIAL NUMBER ITEM QUANTITY Charger Combination tool Instruction book NFC card Reflective sticker Included in the box... -
Page 29: After-Sales Service
After-sales service For any problem listed in following table,our distributor will provide perfect after-sales service within the scope of warranty. Part Quality issue Warranty period Remarks Seriously broken rubber wheel hub,faulty motor Free repair 12 months Motor Unable to use with normal conditions 3 months Free repair Accelerator... - Page 30 Date of Purchase Serial number Model Invoice Number Battery serial number Name Distributor Contact Note Address: Room505, 5th Floor, Liuwei Business Center, Yangmei Longjing Road, Longgang District, Shenzhen city, China WhatsApp: +8613612953725 Customer support: support@ienyrid.com Official website: www.ienyrid.com After-sales service...
