sisel ENDA EHTC7425A Manual

Read this document carefully before using this device. The guarantee will be expired by
damaging of the device if you don't attend to the directions in the user manual. Also we don't
accept any compensations for personal injury, material damage or capital disadvantages.
ENDA EHTC7425A HUMIDITY AND TEMPERATURE CONTROLLER
Thank you for choosing ENDA EHTC7425A Humidity and Temperature Controller
72 x 72mm sized.
Dual 4 digits display.
0/4-20mA, 0-10V, 1- 5V analog or digital input (Specify at Order).
Heating or cooling control selection.
PID, On-Off Temperature control selection.
PID Auto-calculation (SELF TUNE).
Humidification or drying control selection.
Internal supply output for sensor.
Time and temperature-dependent fan relay output selection.
2 Relay outputs with time setting for incubation operations.
Adjustable buzzer alarm feature for measurement values.
CE marked according to European Norms.
Order Code : EHTC7425A -
1 - Supply Voltage
2 - Input
UV........90-250V AC
AS.......Analog Input
LV........10-30V DC /
DS........Digital Input
8-24V AC
TECHNICAL SPECIFICATIONS
ENVIRONMENTAL CONDITIONS
Ambient/stroge temperature
Max. Relative humidity
Rated pollution degree
Height
KEEP AWAY device from exposed to corrosive, volatile and flammable gases or liquids and DO NOT USE the device in similar hazardous
locations.
ELECTRICAL CHARACTERISTICS
Supply
Power consumption
Wiring
Temperature input range
Humidity input range
EMC
Safety requirements
INPUTS
Input Type Measurement Range
0-20mA
4-20mA
AS
-40.0....125.0 ºC
1-5V
0-10V 0....100 %RH
DS
EHTD-CB-100
When the device is in current measurement mode, the input impedance is 10Ω. Therefore voltage input should not be connected to the device while
in current mode. Otherwise the device will deteriorate. If it is necessary to switch from the voltage measurement mode to the current measurement
mode while the device is running, It must be removed and then changed to one of the input type current measurement modes.
OUTPUT
15VDC , Max. 50mA
Sensor Supply
Life expectancy for relay 30.000.000 Switching for no-load operation; 300.000 switching for 10A resistive load at 250VAC.
SSR Output Max. 12VDC 30mA.
HOUSING
Housing type
Suitable for flush-panel mounting according to DIN 43 700.
W72xH72xD97mm
Dimensions
Weight Approx. 350g (after packing)
Self extinguishing plastics
Enclosure Material
Avoid any liquid contact when the device is switched on.
DO NOT clean the device with solvent (thinner, gasoline, acid etc.) and / or abrasive cleaning agents.
SİSEL MÜHENDİSLİK ELEKTRONİK SAN. VE TİC. A.Ş.
Şerifali Mah. Barbaros Cad. No:18
ÜMRANİYE/İSTANBUL-TURKEY
Tel : +90 216 499 46 64 Pbx.
url : www.enda.com.tr
- -
2 3
1
3 - Modbus
RS.........Modbus
(Specify at Order)
Please see page 6 for
Modbus Connection
Diagram.
0 ... +50°C/-25 ... 70°C (Without icing)
80 % Relative humidity for temperatures up to 31
According to EN 60529 Front panel : IP65
Max. 2000m
90-250V AC 50/60Hz ; 10-30V DC / 8-24V AC SMPS
Max. 7VA
2.5mm² screw-terminal connections
0~20mA / 0~10V can be selected for analog output sensors. Temperature range for digital output Enda Sensor is -40~125°C
0~20mA / 0~10V can be selected for analog output sensors. Humidity range for digital output Enda Sensor is 0~100 RH
EN 61326-1: 2013
EN 61010-1: 2010 (pollution degree 2, overvoltage category II)
Measurement Accuracy
±%0,5 (Full scale)
Y.Dudullu 34775
Fax : +90 216 365 74 01
°C, decreasing linearly to 50% at 40°C.
, Rear panel : IP20
Input Resistance
Approx. 10Ω
Approx. 100kΩ
---------------
1/8
EHTC7425A
HEAT
%RH
Fan
L
Rotate
R
SET
TSET HSET C(on/off)
ENDA
HUMIDITY TEMPERATURE CONTROLLER
ENDA
EHTC7425A-EN-10-220103
°C
%RH
TM
