141-DST
Submitted Model No.: _______________________________________________
Specific Features: __________________________________________________
141-DST / 441-DST
9 3/16"
(233 mm)
360° swing spout
4 7/8"
(124 mm)
2 9/32"
(58 mm)
35"
(889 mm)
36"
(914 mm)
Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue
models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or
www.specselect.com for finish options and product availability.
DSP-K-141-DST Rev. B
441-DST
8 21/64"
(212 mm)
2 1/2"
(64 mm)
Max. Deck
Thickness
3/8" Compression Fitting
4 3/4"
(121 mm)
2"
(51 mm)
Dia.
1"
(25 mm)
Dia.
KITCHEN
FAUCETS
■ Collins™ Series
■ Single Handle Deck Mount
■ 1 and 2 Hole Sink Applications
■ DIAMOND™ Seal Technology
■ Integrated Supply Tubes

STANDARD SPECIFICATIONS:

9 3/16" (233 mm) long spout swings 180°
Lever handle shall return to neutral position
.
when valve is turned off
Control mechanism shall be the diamond coated
ceramic cartridge.
Red/blue graphics on handle button to indicate
.
hot/cold temperature
Model 441 series with spray attachment has
anti-siphon device as integral part of faucet
Vegetable sprayer hose installation on model
441 series.
3/8" O.D. straight, staggered pex supply
tubes - 35" (889 mm) and 36" (914 mm) long.
Standard 3/8" (10 mm) compression gasket fittings.

WARRANTY

Lifetime Faucet and Finish Limited Warranty to the
original consumer purchaser to be free from
defects in material and workmanship.
5 Year Limited Warranty for usage in all industrial,
commercial and business applications.
U P
C
®
®

COMPLIES WITH:

ASME A1 12.18.1 / CSA B125.1
Indicates compliance to
ICC/ANSI A117.1
Pressure (kPa)
0
69
138
207
276
345
414
6
5
4
3
2
1
0
0
10
20
30
40
50
60
Pressure (PSI)
55 E. 111th Street, Indianapolis, Indiana 46280
395 Matheson Blvd. E., Mississauga, ON L4Z 2H2
© 2008 Masco Corporation of Indiana
.
.
483
552
621
22.7
18.9
15.1
11.4
7.6
3.8
0
70
80
90
