DELTA ELEKTRONIKA B.V.
DC POWER SUPPLIES
SM15K - Interfaces
• INT MOD M/S-2
• INT MOD CON
• INT MOD SER
• INT MOD DIG
• INT MOD ANA
• INT MOD ANY
Firmware Update
It is strongly recommended, first to perform a firmware update before further
operation. Download the SM15K Quick Start Manual for instructions.
Driver & Example Software
For several applications and Interfaces there is Driver & Example Software
available on our website. See PRODUCTS\SM15K\DOWNLOADS.
PRODUCT MANUAL
Firmware version P0230 and newer
Contents:
1 –
Safety Instructions
2 –
Sicherheitshinweise
3 –
Consignes de Sécurité
4 –
Master Slave Interface
5 –
Isolated Contacts
6 –
Serial Interface
7 –
Digital (User) I/O
8 –
Isolated Analog Interface
9 –
AnyBus CompactCom Interface
1 / 24
DELTA ELEKTRONIKA B.V.
Vissersdijk 4, 4301 ND
www.DeltaPowerSupplies.com
Zierikzee, the Netherlands
Tel. +31 111 413656
rev. March 2025
Advertisement
Related Manuals for Delta Elektronika INT MOD M/S-2
Summary of Contents for Delta Elektronika INT MOD M/S-2
- Page 1 Vissersdijk 4, 4301 ND www.DeltaPowerSupplies.com Zierikzee, the Netherlands Tel. +31 111 413656 DC POWER SUPPLIES SM15K - Interfaces • INT MOD M/S-2 • INT MOD CON • INT MOD SER • INT MOD DIG • INT MOD ANA • INT MOD ANY...
- Page 2 Failure to comply with the safety precautions or warnings in this document violates safety standards of design, manufacture and intended use of this equipment and may impair the built-in protections. Delta Elektronika shall not be liable for user’s failure to comply with these requirements.
- Page 3 Warning! High currents can run through the DC power terminals. These currents cause strong magnetic fields. Do not come near if you have an electro medical device such as a pacemaker. 1.15 Environmental Conditions • The Delta Elektronika power supplies safety approval applies to the following operating conditions: • Usage : Indoor use only.
- Page 4 Die Nichteinhaltung der Sicherheitsvorkehrungen oder Warnungen in diesem Dokument verstößt gegen die Sicherheitsstandards im Hinblick auf Bauart, Produktion und vorgesehene Nutzung dieses Geräts und kann die eingebauten Schutzvorrichtungen beschädigen. Delta Elektronika haftet nicht dafür, wenn der Nutzer diesen Anforderungen nicht nachkommt.
- Page 5 SM15K INTERFACES 2.10 Teileaustausch & Modifikationen Teileaustausch und Modifikationen sind ausschließlich autorisiertem Delta Elektronika-Service-Personal gestattet. Reparaturen am Gerät dürfen nur durch eine Delta Elektronika-Serviceeinrichtung durchgeführt werden. 2.11 Entfernung von (Sicherheits-) Abdeckungen Sicherheitsabdeckung(en) werden verwendet, um potenziell gefährliche Spannungen abzudecken. Beachten Sie Folgendes, wenn Sie die Sicherheitsabdeckung(en) entfernen: •...
- Page 6 à la norme CEI 60309. ‘Équipement connecté en permanence’ ou ‘Équipement enfichable de type B’. Fusibles Les fusibles ne peuvent être remplacés que par le personnel de service autorisé de Delta Elektronika afin d’éliminer définitivement le risque d’incendie. Alimentation d’entrée CA N’utilisez pas une alimentation CA qui dépasse la tension d’entrée CA et la puissance de fréquence de cet appareil.
- Page 7 Le remplacement et les modifications des pièces ne sont autorisés qu’au personnel de service autorisé de Delta Elektronika. Les réparations de l’appareil ne peuvent être effectuées que par un centre de service Delta Elektronika. 3.11 Retrait des couvercles (de sécurité) Les couvercles de sécurité...
-
Page 8: Hardware Installation
Stack the units with minimum spacing in between them. Distance between sets of output terminals is 3U = 133.35mm. • Assign a unit as Master. fig 4 - 1 Slot 3 and 4 are valid for INT MOD M/S-2. 8 / 24 DELTA ELEKTRONIKA B.V. rev. April 2025... - Page 9 4.4.3 DC POWER CONNECTIONS FOR M/S-SERIES • It is strongly advised to use one of the M/S SER kits from Delta Elektronika for best and safest results! These kits include special copper bars, bolts, nuts, specific washers, patch cables and extra safety covers.
- Page 10 4.4.6 CONNECT AC MAINS There are two 8-pole modular jack connectors • Connect the mains supply cables to the units. available on the INT MOD M/S-2. Make sure the cable is not yet connected to the mains supply! 10 / 24 DELTA ELEKTRONIKA B.V.
-
Page 11: Unit Configuration
• Check there is only one M/S-2 interface installed per unit. display. • Check that all interfaces are type INT MOD M/S-2, and there is no INT MOD M/S, see fig 4 - 9. • Check the firmware version as specified in paragraph 3 of this chapter. - Page 12 • The unit will automatically detect the new inserted interface. fig 5 - 3 Position of the interface icon in the unit display. • The interface icon will be shown in the display, see fig 5 - 3. 12 / 24 DELTA ELEKTRONIKA B.V. rev. April 2025...
- Page 13 • Check Interlock / enable connection on CON K. CALIBRATION fig 5 - 7 15 - 30 V Enable. • Calibration of the interface is not applicable. fig 5 - 8 Interlock contact (door switch). 13 / 24 DELTA ELEKTRONIKA B.V. rev. April 2025...
-
Page 14: Serial Interface
• Connect the mains supply again and check all the safety fig 6 - 3 covers are installed. Pin connections of the RS422 / RS485 connector. • Switch on the unit. • The LED should light up. UNIT CONFIGURATION 14 / 24 DELTA ELEKTRONIKA B.V. rev. April 2025... -
Page 15: Serial Programming
• Check that the power supply is in the required mode (CV or CC or CP). When programming a voltage, the unit must be in table 6 - 1 CV-mode, when programming a current, the unit must be in Available serial programming commands. 15 / 24 DELTA ELEKTRONIKA B.V. rev. April 2025... - Page 16 Termination : Disabled Differential communication : Half-duplex • Port settings on the PC. Baudrate : bps 9600 Data bits : 8 Parity bits : None Stop bits : 1 Flow control : None 16 / 24 DELTA ELEKTRONIKA B.V. rev. April 2025...
- Page 17 • The LED indicated in fig. 7 - 2 will light up. UNIT CONFIGURATION • The unit will automatically detect the new inserted interface. • The interface icon will be shown in the display, see fig 7 - 3. 17 / 24 DELTA ELEKTRONIKA B.V. rev. April 2025...
-
Page 18: Inputs And Outputs
Sequencer to make the power supply act like a Power PLC. • Refer to the Delta Elektronika programming manual for Ethernet & Sequencer for commands. • The manual is stored inside every SM15K unit and can be downloaded via the web interface. - Page 19 • Connect the mains supply again and check all the safety fig 8 - 3 covers are installed. • Switch on the unit. Position of the interface icon in the unit display. 19 / 24 DELTA ELEKTRONIKA B.V. rev. April 2025...
-
Page 20: Analog Programming
• The Limit Status or LIM-status is "1" in case the output voltage or current reaches the limit setting. Which limit circuit is active can be seen on the front panel indicators. 20 / 24 DELTA ELEKTRONIKA B.V. rev. April 2025... -
Page 21: Remote Shutdown
• The isolated analog interface is factory calibrated. • If desired, both the 5 V and 10 V range can be custom calibrated. See the ethernet programming manual for more details. 21 / 24 DELTA ELEKTRONIKA B.V. rev. April 2025... - Page 22 • Unscrew the 2 ‘Torx T10 screws’ and remove the slot cover of the power supply. • Insert the INT MOD ANY, with the AnyBus module installed. • Use the two ‘Torx T10 screws’ to secure the INT MOD ANY. 22 / 24 DELTA ELEKTRONIKA B.V. rev. April 2025...
-
Page 23: Connect Interface
62500 CVmon 0 … 65535 62500 CCprg 0 … 32500 31250 CCmon* -32768 … 32767 31250 *Note: CCmon should be treated as a 2-complement value. fig 9 -6 16-bit Format Scaling. 23 / 24 DELTA ELEKTRONIKA B.V. rev. April 2025... -
Page 24: Testing Communication
• Check the source of the power supply. • Check the web interface of the unit for errors. • Use Ethernet or web commands to check for errors. 9.11 CALIBRATION • Calibration of the interface is not applicable. 24 / 24 DELTA ELEKTRONIKA B.V. rev. April 2025...
