- Page 1 OMNI-Monitor Series OMNI-310M, OMNI-312M, OMNI-315M, OMNI-317M, OMNI-319M, OMNI-215M, OMNI-221M Industrial Touch Display User’s Manual 3 Last Updated: February 13, 2025...
-
Page 2: Copyright Notice
Copyright Notice This document is copyrighted, 2025. All rights are reserved. The original manufacturer reserves the right to make improvements to the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of the original manufacturer. - Page 3 Acknowledgement All other products’ name or trademarks are properties of their respective owners. ® is trademark of Advanced Micro Devices. ⚫ Microsoft Windows is a registered trademark of Microsoft Corp. ® ⚫ ITE is a trademark of Integrated Technology Express, Inc. ⚫...
- Page 4 Packing List Before setting up your product, please make sure the following items have been shipped: Item Quantity OMNI Monitor ⚫ VGA Cable ⚫ USB Cable for Touch ⚫ Touch Driver CD ⚫ Phoenix Power Connector ⚫ If any of these items are missing or damaged, please contact your distributor or sales representative immediately.
- Page 5 About this Document This User’s Manual contains all the essential information, such as detailed descriptions and explanations on the product’s hardware and software features (if any), its specifications, dimensions, jumper/connector settings/definitions, and driver installation instructions (if any), to facilitate users in setting up their product. Users may refer to the product page on AAEON.com for the latest version of this document.
- Page 6 Safety Precautions Please read the following safety instructions carefully. It is advised that you keep this manual for future references All cautions and warnings on the device should be noted. Make sure the power source matches the power rating of the device. Position the power cord so that people cannot step on it.
-
Page 7: To Prevent Damage
If any of the following situations arises, please the contact our service personnel: Damaged power cord or plug Liquid intrusion to the device iii. Exposure to moisture Device is not working as expected or in a manner as described in this manual The device is dropped or damaged Any obvious signs of damage displayed on the device... - Page 8 FCC Statement This device complies with Part 15 FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received including interference that may cause undesired operation. Caution: There is a danger of explosion if the battery is incorrectly replaced.
- Page 9 China RoHS Requirements (CN) 产品中有毒有害物质或元素名称及含量 AAEON System QO4-381 Rev.A2 有毒有害物质或元素 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) 印刷电路板 × ○ ○ ○ ○ ○ 及其电子组件 外部信号 × ○ ○ ○ ○ ○ 连接器及线材 外壳 ○...
- Page 10 China RoHS Requirement (EN) Name and content of hazardous substances in product AAEON System QO4-381 Rev.A2 Hazardous Substances Part Name 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) PCB Assemblies × ○ ○ ○ ○ ○ Connector and ×...
-
Page 11: Table Of Contents
Table of Contents Chapter 1 - Product Specifications ..................1 Specifications ......................2 1.1.1 OMNI-310M ....................4 1.1.2 OMNI-312M ....................5 1.1.3 OMNI-315M ....................6 1.1.4 OMNI-317M ....................7 1.1.5 OMNI-319M ....................8 1.1.6 OMNI-215M ....................9 1.1.7 OMNI-221M ....................10 Chapter 2 –... - Page 12 2.5.2 VESA Mounting ..................26 Chapter 3 - Onscreen Display Control ................27 Functional Buttons ....................28 OSD Menu - PICTURE ..................29 OSD Menu - DISPLAY ..................30 OSD Menu - COLOR ..................... 31 OSD Menu - ADVANCE ..................32 OSD Menu - INPUT ....................
-
Page 13: Chapter 1 - Product Specifications
Chapter 1 Chapter 1 - Product Specifications... -
Page 14: Specifications
Specifications These specifications apply to all models of the OMNI-Monitor Series. Specifications for individual models are listed separately. System VGA/HDMI Input Signal 5 keys OSD keypad (Up, Down, Menu, Auto, On Screen Display Control Power) DB9 VGA x 1, HDMI x 1 USB x 1 (For Enable T/S Function) I/O Port Line in x 1 (For optional internal Speaker) Power... - Page 15 Power Supply DC 12~30V Power Input with 3 Pin Terminal DC Input Block Touchscreen Projective Capacitive Multi Touch or 5 Wire Type Resistive Touch Screen (By Model) P-CAP (90% ± 3%) Light Transmission 5-wire Resistive (80% ± 3%) — Life Time Chapter 1 –...
-
Page 16: Omni-310M
1.1.1 OMNI-310M 10.4" TFT-LCD Display Type 800 x 600 Max. Resolution 16.2M Max. Colors 230 cd/m2 Luminance 160°(H), 130°(V) Viewing Angle Back Light 30,000 Back Light MTBF (Hours) Mechanical IP65 aluminum front bezel & SGCC chassis Construction Panel Mount / VESA 100x100 / Stand Mounting 11.0"... -
Page 17: Omni-312M
1.1.2 OMNI-312M 12.1" TFT-LCD Display Type 1024 x 768 Max. Resolution 16.2M Max. Colors 500 cd/m2 Luminance 160°(H), 160°(V) Viewing Angle Back Light 50,000 Back Light MTBF (Hours) Mechanical IP65 aluminum front bezel & SGCC chassis Construction Panel Mount / VESA 100x100 / Stand Mounting 12.9"... -
Page 18: Omni-315M
1.1.3 OMNI-315M 15" TFT-LCD Display Type 1024 x 768 Max. Resolution 16.2M (8bit/color) Max. Colors 300 cd/m2 Luminance 176° (H), 176° (V) Viewing Angle Back Light 70,000 Back Light MTBF (Hours) Mechanical IP65 aluminum front bezel & SGCC chassis Construction Panel Mount / VESA 100x100 / Stand Mounting 14.5"... -
Page 19: Omni-317M
1.1.4 OMNI-317M 17" TFT-LCD Display Type 1280 x 1024 Max. Resolution 16.2M Max. Colors 350 cd/m2 Luminance 170°(H), 160°(V) Viewing Angle Back Light 50,000 Back Light MTBF (Hours) Mechanical IP65 aluminum front bezel & SGCC chassis Construction Panel Mount / VESA 100x100 / Stand Mounting 16.1"... -
Page 20: Omni-319M
1.1.5 OMNI-319M 19" TFT-LCD Display Type 1280 x 1024 Max. Resolution 16.7M Max. Colors 350 cd/m2 Luminance 170°(H), 160°(V) Viewing Angle Back Light 50,000 Back Light MTBF (Hours) Mechanical IP65 aluminum front bezel & SGCC chassis Construction Panel Mount / VESA 100x100 / Stand Mounting 18.1"... -
Page 21: Omni-215M
1.1.6 OMNI-215M 15.6" TFT-LCD Display Type 1366 x 768 Max. Resolution 16.7M Max. Colors 400 cd/m2 Luminance 170°(H), 160°(V) Viewing Angle Back Light 50,000 Back Light MTBF (Hours) Mechanical IP65 aluminum front bezel & SGCC chassis Construction Panel Mount / VESA 100x100 / Stand Mounting 16.5"... -
Page 22: Omni-221M
1.1.7 OMNI-221M 21.5" TFT-LCD Display Type 1920 x 1080 Max. Resolution 16.7M Max. Colors 250 cd/m2 Luminance 178°(H), 178°(V) Viewing Angle Back Light 50,000 Back Light MTBF (Hours) Mechanical IP65 aluminum front bezel & SGCC chassis Construction Panel Mount / VESA 100x100 / Stand Mounting 21.6"... -
Page 23: Chapter 2 - Hardware Information
Chapter 2 Chapter 2 – Hardware Information... -
Page 24: Dimensions
Dimensions 2.1.1 OMNI-310M Chapter 2 – Hardware Information... -
Page 25: Omni-312M
2.1.2 OMNI-312M Chapter 2 – Hardware Information... -
Page 26: Omni-315M
2.1.3 OMNI-315M Chapter 2 – Hardware Information... -
Page 27: Omni-317M
2.1.4 OMNI-317M 73.4 182.6 OMNI- 317M 410.0 387.9 338.9 100.0 Chapter 2 – Hardware Information... -
Page 28: Omni-319M
2.1.5 OMNI-319M Chapter 2 – Hardware Information... -
Page 29: Omni-215M
2.1.6 OMNI-215M Chapter 2 – Hardware Information... -
Page 30: Omni-221M
2.1.7 OMNI-221M Chapter 2 – Hardware Information... -
Page 31: I/O Ports
2.2 I/O Ports I/O Description Remark USB A Type for Touch Screen VGA input HDMI input Audio in (Line in) Optional Function DC in (Terminal Bock 3pin) Default Connector DC in (Jack) Optional Connector Chapter 2 – Hardware Information... -
Page 32: Pin Definitions
Pin Definitions This section details all the pins definition of all the connectors associating with the OMNI-Monitor Series to aid your setup. 2.3.1 VGA Port Connector Signal Signal Green Blue R-GND G-GND B-GND PC 5V SDA DDC SYNC.H SYNC.V SCL DDC Chapter 2 –... -
Page 33: Hdmi Port Connector
2.3.2 HDMI Port Connector Signal Signal TMDS2+ TMDS2- TMDS1+ TMDS1- TMDS0+ TMDS0- TMDSC+ TMDSC- HDMI_SCL HDMI_SDA HD_5V H_HPD Chapter 2 – Hardware Information... -
Page 34: Waterproof Sponge
Waterproof Sponge Inside sponge: Tear off the protection paper on the self-adhesive side of the inside sponge. Stick the sponge on the recessed area of the Aluminum bezel or customer’s own bezel. Back side of the Front Bezel Chapter 2 – Hardware Information... -
Page 35: Mounting
Mounting This section details the steps you need to follow when fitting the various mounting brackets onto the OMNI-Monitor Series. 2.5.1 Panel Mounting To mount this panel onto a wall, refer to the diagram below. Step 1-Glue the waterproof rubber along the back side of the panel Chapter 2 –... - Page 36 Step 2-Pull out the panel mount brackets along the edge of frame Step 3- Use screws to secure the panel onto the wall with the wallmount brackets Chapter 2 – Hardware Information...
-
Page 37: Stand Mounting
2.5.2 Stand Mounting Use AAEON's optional Monitor Stand (Part Number: AP-OT9789LA1000) Attach the stand to the monitor via the VESA holes (100x100mm) on the back of OMNI-Monitor. AP-OT9789LA1000 Chapter 2 – Hardware Information... -
Page 38: Vesa Mounting
2.5.2 VESA Mounting Mounting the OMNI-Monitor with UL Listed Wallmount Bracket only. The Monitor can be mounted on a monitor arm or wallmount plate. Caution: When mounting the monitor, take care to tighten the retention screws or bolts until fully secured, but do not over tighten. Overtightening the retention screws or bolts may cause them to become stripped, rendering them useless. -
Page 39: Chapter 3 - Onscreen Display Control
Chapter 3 Chapter 3 - Onscreen Display Control... -
Page 40: Functional Buttons
Functional Buttons Button Function (Outside Menu) Function (Inside Menu) Turn the Monitor on or off Turn the Monitor on or off Return to last menu Auto adjustment (VGA only) Activate the OSD menu Confirm the selected option. Increase backlight brightness Move up (Default: 50, range: 0 ~ 100) Increase the gauge value of the... -
Page 41: Osd Menu - Picture
OSD Menu - PICTURE Item Function Brightness Adjust the brightness (0-100) Contrast Adjust the contrast (0-100) Sharpness Adjust the image sharpness (0-4) Exit Exit the menu Chapter 3 – Onscreen Display Control... -
Page 42: Osd Menu - Display
OSD Menu - DISPLAY Item Function Auto Adjust Perform the auto adjust (VGA Mode only) H Position Adjust the image to the left or right on the screen (0-100) V Position Adjust the image to the up or down on the screen (0-100) Pixel Clock Adjust the value of horizontal image (0-100) Adjust the phase control (Phase adjustment may be required to... -
Page 43: Osd Menu - Color
OSD Menu - COLOR Item Function Gamma Adjust the value of gamma (off/1.8/2.2/2.4) Adjust the color temperature Color Temp (5800K/6500K/7500K9300K/sRGB/User) Auto Color Perform auto color function Exit Exit the menu Chapter 3 – Onscreen Display Control... -
Page 44: Osd Menu - Advance
OSD Menu - ADVANCE Item Functionas Aspect Ratio Change the aspect ratio mode (4:3/16:9/5:4/Full/Original) Exit Exit the menu Chapter 3 – Onscreen Display Control... -
Page 45: Osd Menu - Input
OSD Menu - INPUT Item Function Auto Select Auto detect the valid input image signal source Set to VGA input mode HDMI Set to HDMI input mode Exit Exit the menu Chapter 3 – Onscreen Display Control... -
Page 46: Osd Menu - Audio (Working With Optional Internal Speaker)
OSD Menu - AUDIO (working with optional internal speaker) Itam Function Volume Adjust the level of audio volume (0-100) Mute Set the speaker work or mute (off/on) Exit Exit the menu Chapter 3 – Onscreen Display Control... -
Page 47: Osd Menu - Other
OSD Menu - OTHER Item Function Reset Reset all settings to the default Adjust how long the OSD shown on the screen while active Menu Time (1-30 sec) OSD H Position Adjust the OSD to the left or right on the screen (0-100) OSD V Position Adjust the OSD to the up or down on the screen (0-100) Transparency... -
Page 48: Osd Menu - Exit
OSD Menu - EXIT Item Function Showing the information of current input image signal Exit Perform to quit the OSD Chapter 3 – Onscreen Display Control... -
Page 49: Chapter 4 - Touchscreen And Driver Installation
Chapter 4 Chapter 4 – Touchscreen and Driver Installation... -
Page 50: Introduction
Introduction The OMNI-Monitor Series touch monitor uses 5-wire resistive technology or Projected Capacitive technology to provide more accurate sensing capacity than other technologies. The touch screen is specially designed for tough industrial environments and has been approved by CE/FCC Class A standards. Touch Screen 5-Wire Resistive •... -
Page 51: Touchscreen Driver Installation (5-Wire Resistive)
Touchscreen Driver Installation (5-Wire Resistive) Introduction Please install the touch driver on your PC device after connecting the USB cable from the monitor to the PC device. Note: There is no need to install a driver for Projected Capacitive touch; it’ s only necessary for 5-Wire Resistive touch. -
Page 52: Installing Driver For Windows® And Linux
Installing Driver for Windows® and Linux The touch screen has drivers for Windows and Linux. You should read the ® instructions in this chapter carefully before installation. Note 1: The following windows illustrations are examples only. You must follow the flow chart instructions and pay attention to the instructions which appear on your screen. - Page 53 Click the “Next” button on the screen Click on the “I Agree” button and restart your system Chapter 4 – Touchscreen and Driver Installation...
- Page 54 Confirm the path for driver install and click "Install" button. Click "Yes" button. Chapter 4 – Touchscreen and Driver Installation...
- Page 55 Installation finished. Touch Calibration After the touch driver installed, you should run calibration immediately to make sure the touch accuracy. Find the icon and execute it. Chapter 4 – Touchscreen and Driver Installation...
- Page 56 Click the "Configure" button. Standard Calibration Chapter 4 – Touchscreen and Driver Installation...
- Page 57 Follow the instruction on the screen to calibrate the touch. Draw Test 1. Go to "Tools" tab and click "Draw" button Chapter 4 – Touchscreen and Driver Installation...
- Page 58 For Linux Ubuntu, please find the compressed file "pmLinux-Ubuntu_12.04-18.04_32_64bit_Driver_V4.5.6.tar.bz2" in the Touch Driver CD. Find the "README" file inside the compressed file and follow the instruction to install the touch driver 1). Login as user in Ubuntu login prompt 2). Open terminal [Dash Home] -> Applications -> Accessories -> Terminal 3).
-
Page 59: Appendix A - Support Timing List
Appendix A Appendix A - Support Timing List... -
Page 60: Support Timing List Table
Support Timing List Table Item Description 3105 3125 3155 3175 3195 2155 2215 640 x 480 640 x 480 640 x 480 640 x 480 640 x 480 720 x 400 800 x 600 800 x 600 800 x 600 800 x 600 1024 x 768 1024 x 768... - Page 61 1600 x 1200 1680 x 1050 1920 x 1080 Appendix A – Support Timing List...
