Harvey Fabric Bed - Single, Double and King Assembly Instructions Important before assembly: Read these instructions carefully before assembling or using the product. Please check the contents of the boxes before attempting to assemble this product. The instructions will have a checklist of parts and fittings.
Page 2
These tools are not necessary, but may help to assemble the product. Do NOT use any power tools as this may damage the frame. (Not metal) This product or some parts of this product will be heavy. Please use an assistant when lifting. Never drag or push the pieces across a hard or stone floor as this will cause damage to the joints.
14/15 Double/King Centre Support Rail Only for Double & King Metal 'L' Brackets Allen Key for Bolts a Big Head Bolts (M8x25mm) 0 10 1 Tools required No more tools needed. Harvey Non-Storage Bed - Assembly Guide - Page 3...
Bed assembly This step is for Single, Double or King size This step is for Single, Double or King size & 100% Harvey Non-Storage Bed - Assembly Guide - Page 4...
Page 5
This step is only for Double or King size This step is only for Double or King size A & B Harvey Non-Storage Bed - Assembly Guide - Page 5...
Page 6
Single Size Press down Double & King size Press Press down down Harvey Non-Storage Bed - Assembly Guide - Page 6...
Overall Dimensions (LWH cm) Single: 205.5 x 99.5 x 98 Double: 205.5 x 144.5 x 98 King: 215.5 x 159.5 x 98 Internal Dimensions (LW cm) Slat width Single: 193 x 92.5 Double: 193 x 137.5 King: 203 x 152.5 Distance between slats (cm) 31 15 Floor to top...
Please dispose of all packaging safely. General Care & Maintenance Wipe clean with a slightly damp cloth. Avoid the use of all household cleaners and abrasives. Periodically check all screw & fixings to ensure they are secure. When moving your product, carefully lift into place. Never drag or push the product across the floor as this will cause damage to the joints.
