- Page 1 QUICK START GUIDE Get Smarter about Your Home Security FHD Battery Security Camera...
-
Page 2: Warranty Service
How to Activate the Free 1-year Warranty Extension? Send us the order number and SN number via email. Please email us within 30 days of receiving the camera. Email: Support@zumimall.com Product Service Email: Support@zumimall.com Distributor: Distributor@zumimall.com More About Us Web: www.zumimall.com Facebook: www.facebook.com/zumimalloffice... - Page 3 Brand Story ZUMIMALL, founded in 2008, focuses on the design and research of intelligent security technology. We insist on taking consumers as the core and strive to create smart home products that lead the global home fashion trend for consumers. Believe in craftsmanship to create top-quality goods, technology changes life.
-
Page 4: Table Of Contents
INDEX PAGE 1. What's in the Box - F5 ----------------------------------------- P1 1.1. What's in the Box - F5K ------------------------------------- P2 2. Product Diagram ------------------------------------------ P3 3. Download and Install App ------------------------------------P4 4. Account Registration --------------------------------------- P5 5. Add Camera to App --------------------------------------- P5 5.1 Preparations for Connection ------------------------------- P5... - Page 5 INDEX PAGE 12.2 Alarm Notification -------------------------------------- P15 12.3 Record/Playback/Delete -------------------------------- P15 13. Power Saving Settings -------------------------------------- P16 13.1 Alarm Interval ------------------------------------------P16 13.2 Recording Time ----------------------------------------P16 13.3 Alarm Plan -------------------------------------------- P17 14. Battery Management --------------------------------------P18 15. Multi-Device Management ---------------------------------- P19 15.1 Multi-Camera Management ------------------------------ P19 15.2 Multi-User Sharing -------------------------------------- P19...
-
Page 6: What's In The Box - F5
1. What’s in the Box - F5 QUICK START GUIDE Get Smarter about Your Home Security FHD Battery Security Camera Battery Camera Screws Set Outdoor Mount Charging Cable Magnetic Bracket Quick User Guide 3M Adhesive Tapes NOTE: Micro SD card and power adapter are not included. -
Page 7: What's In The Box - F5K
1.1. What’s in the Box - F5K QUICK START GUIDE Get Smarter about Your Home Security FHD Battery Security Camera Battery Camera Solar Panel Outdoor Mount Screws Set Magnetic Bracket Charging Cable 3M Adhesive Tapes Quick User Guide NOTE: Micro SD card and power adapter are not included. -
Page 8: Product Diagram
2. Product Diagram 11 12 ① LED Indicator ⑤ PIR Sensor ⑨ Power Button ② IR Lamp ⑥ Microphone ⑩ Charging Port ③ Camera Lens ⑦ Speaker ⑪ SD Card Slot ④ Spotlight ⑧ Silicone Rubber ⑫ Reset Hole Power Button Keep pressing for 5-10 seconds to power on/power off Reset Hole Poke the reset pin into the hole for 5-10 seconds to reset the device... -
Page 9: Download And Install App
NOTE: Please turn on both of the following permissions. ① Allow ZUMIMALL App to access mobile cellular data and wireless LAN, otherwise it will fail to connect the camera. ② Allow ZUMIMALL App to receive pushed messages, otherwise, the phone will not receive alarms when motion is detected. -
Page 10: Account Registration
4. Account Registration New user needs to sign up ZUMIMALL App with an email address. Click ' Sign up ' to create a New Account and follow the steps to complete registration. Step 3 Step 1 Step 2 5. Add Camera to App 5.1 Preparations for Connection... -
Page 11: Method 1: Bluetooth Setup(Recommended)
Method 1: Bluetooth Setup(RECOMMENDED) 1) On the Homepage, tap ' Add ' or ' + ' in the upper right corner, tap ' Add Device ' . 2) If the Bluetooth of the cellphone doesn't turn on, the app will show a pop-up, please allow it to turn on Bluetooth. - Page 12 4) Select the 2.4GHz Wi-Fi that you want the camera to connect to and enter password. When the Bluetooth is on, the app will automatically show you the 2.4GHz Wi-Fi that could be connected. 5GHz Wi-Fi will not be shown. Normally, the Wi-Fi name and password of your 2.4GHz and 5GHz Wi-Fi are the same or similar.
-
Page 13: Method 2: Qr Code Setup
Method 2: QR Code Setup Tap 'Add Device' Select Camera Turn on the Camera Input Wi-Fi Password Prepare the Scanning Scan QR Code... - Page 14 Installation complete at 100% Name the camera View Installation Tips 03-26-2024 10:16:44 AM 23KB/s Perform Network Diagnosis Using the camera...
-
Page 15: How To Reset The Camera
6. How to Reset the Camera ① Go to the device homepage, select the camera that needs to be reset, and keep pressing it to remove it from the app. ② Press the camera's reset button for 5-10s until hear the ' Boogu ' sound. ③... -
Page 16: Camera Installation
7. Camera Installation ① Select a proper position for your camera. Make sure the camera is not blocked and ensure it is in coverage of Wi-Fi. ② Secure the magnetic mount with the supplied 3M adhesive or screws. Attach the camera to the bracket and adjust it to the proper angle. NOTE：Choose a clean, smooth and dry surface for the mounting bracket, avoid uneven wood veneer and plastered walls. -
Page 17: Monitoring Area
9. Monitoring Area ① It is not suggested to install the camera vertically towards the moving objects, otherwise, it may not detect the motion events or cause delay. ② It is suggested to make the angle between PIR Sensor and detected objects more than 10 degrees. -
Page 18: Device Menu
10. Device Menu 064588341 064588341 064588341 03-26-2024 12:53:01 AM 03-26-2024 12:53:01 AM 03-26-2024 13:26:05 AM 03- 2 6- 2024 12:56:08 AM 064588341 Add Device and Scan Code Two-Way Talk More Functions Record to Phone Motion Detection On/Off Real Time Live View Button Lens Switch Light Camera Name... -
Page 19: 1 . Two-Way Audio
11. Two-Way Audio 064588341 ① Open the microphone permission of ZUMIMALL APP. 03-26-2024 12:53:01 AM ② Long press the intercom button to start speaking, and the sound will be emitted from the camera at this time. ③ Release the intercom button to listen to the speech, and the sound will be emitted from the mobile phone. -
Page 20: Alarm Notification
12.2 Alarm Notification This camera does not support 7*24 hours all day recording, it is an event recording camera. It is only triggered when body motion is detected. Here are system's reactions: ① Alarm notifications with sounds from App. ② Pictures/videos are automatically stored in Micro SD Card or Cloud. 12.3 Record/Playback/Delete ①... -
Page 21: Power Saving Settings
13. Power Saving Settings 13.1 Alarm Interval This is a function that avoids repeated alarms for the same event. You can choose an alarm interval of different lengths, if the interval is 5 minutes, then the camera is triggered at 08:00, you will receive an alarm message, and you will not receive a new alarm push in the next 5 minutes, even if motion detection continues to occur. -
Page 22: Alarm Plan
13.3 Alarm Plan You can set the weekly/daily alarm schedule as you need. If you set the camera's working hours from 0:00 to 1:00 .The camera will only be triggered and record alarm video during this period. NOTE：Alarm schedule can be set for up to 4 time periods. -
Page 23: Battery Management
14. Battery Management ① The camera has a built-in high-capacity battery, which can be used for 2-3 months, assuming the camera wakes up 15 times per day and play video for 10 minutes each day. NOTE: The battery's durability depends on how frequently the camera is activated. The more it is activated, the faster the battery drains. -
Page 24: Multi-Device Management
One camera can't be connected to multiple App accounts either. But camera can be shared form A to B. Share steps： ① B download ZUMIMALL App to his/her phone and create a new account in the App. ② Click ' Add ' in App on A's phone. - Page 25 064588341 On the camera's settings You have two ways to share: QR code The person being shared clicks Scan this QR code page, tap Share and enter your account number. on the QR code on the 'My' page Or enter the account number of the Customise the permissions of the View Shared Records Accepting sharing requests...
- Page 26 If you have other questions, please send us the SN number of your camera and describe the problem you have encountered, we will solve it as soon as possible. Email: Support@zumimall.com How to find SN number? 064588341 064588341 03-26-2024 12:53:01 AM...
