Summary of Contents for Ducati MULTISTRADA V2

  • Page 2 Owner’s manual ENGLISH...
  • Page 3 We recommend that you read the use and maintenance manual carefully, to quickly get familiar with your Ducati and make the most of all its features. In the manual, we provide lots of useful advice and information on your safety, on how to take care of your bike and on how to maintain its value through correct maintenance by specialist Service Centres.
  • Page 4 For this reason, the illustrations in this manual might differ from your motorcycle. Important Check the FAQs and tutorials dedicated to your bike on the Ducati website to keep up to date with all the latest news regarding its functions and features.
  • Page 5 Enjoy your ride!
  • Page 6: Table Of Contents

    Seat lock .............36 Maintaining the battery charge....42 Side stand ............44 Warranty information ......14 Installing the Ducati side panniers (if any). 46 General warranty conditions ......14 Using the side panniers (if any) ..... 61 USB connection ..........67 General Information......21 Adjusting windscreen height......
  • Page 7 Position of motorcycle controls .....74 Stopping the motorcycle.......103 Switchgears ............75 Parking..............104 Light control ............. 78 Refuelling............105 Keys..............83 Tool kit and accessories......... 107 Key-operated ignition switch and steering lock ............. 85 Instrument panel (Dashboard)..108 Restoring motorcycle operation via the Instrument panel ...........
  • Page 8 Settings - Devices - Bluetooth (if present) 250 Settings - Advanced - Riding Mode setup 197 Engine auto shutdown ......... 257 Settings - Advanced - Riding Mode Ducati Link app connection ......258 setup - Power mode........199 Warning displaying ........260 Settings - Advanced - Riding Mode Error warnings ..........
  • Page 9 Adjusting the rear-view mirrors....287 Fuel system............. 308 Tubeless tyres ..........288 Brakes .............. 308 Check engine oil level ........290 Transmission ..........309 Use of Ducati Corse Performance Oil by Frame..............310 Shell ..............291 Wheels ..............310 Cleaning the motorcycle ......292 Tyres..............310 Storing the motorcycle .........
  • Page 10: Roadside Assistance

    Corsica, roads open to ordinary traffic) Fyrom (the accident to the Ducati Customer. The service is former Yugoslav Republic of Macedonia), Germany, active 24 hours a day, 365 days a year, for 24 months...
  • Page 11 Centre in Italy: +39-02 66165610. Important All information is detailed and available on the Country Toll-free call Toll call / Call Ducati website of the respective country. from abroad Call Centre telephone numbers Andorra +34-91-594 93 +34-91-594 93 To request Assistance:...
  • Page 12 FYROM (02)-3181 192 +389-2-3181 192 Poland 061 83 19 885 +48 61 83 19 885 Germany 0800-27 22 774 +49-89-76 76 40 Portugal 800-20 66 68 +351-21-942 91 Gibraltar 91-594 93 40 +34-91-594 93 Czech Republic 261 10 43 48 +420-2-61 10 43 Greece (210)-9462 058 +30-210-9462...
  • Page 13 Ukraine 044-494 29 52 +380-44-494 29 Hungary (06-1)-345 17 47 +36-1-345 17 47 Country Toll call with call Toll call with call from the United from abroad Kingdom United King‐ 0330 053 0903 +44 330 053 0903...
  • Page 14: Software Update

    If the updates are not installed within a reasonable published on the Ducati website and the period of time, Ducati shall not be liable for any updates are made available, for two years from conformity or safety defects deriving from the the date of purchase of the motorbike or for the failure to install the update.
  • Page 15: Warranty Information

    Customer additional roadside assistance services in 1. Warranty content the Countries listed in the "Owner's manual", 1.1 Ducati Motor Holding S.p.A. - A Sole partner according to the specific terms and procedures company- a Company of the Audi Group, with reported therein, which are here fully referred to.
  • Page 16 2. Exclusions production process such as, by way of example, any 2.1 This warranty offered by Ducati is not applicable damage/defect deriving from: ● negligence in the execution of the Scheduled ● a) motorcycles used in sporting competitions of Maintenance Plan specified by Ducati in article 5 any kind;...
  • Page 17 A copy of this documentation should be kind from Ducati, nor to extend the warranty per the given to the Dealer/Authorised Service Centre present Warranty Conditions, without prejudice to...
  • Page 18 5. Scheduled maintenance plan and pre-delivery In any case, Ducati shall not be held liable for defects of the motorcycle attributable to the failure to notify 5.1 The pre-delivery operations are carried out by the Ducati of the change of ownership of the same.
  • Page 19 5.5 In order to certify that the operations specified for each service coupon have been duly performed, the Dealer and/or Authorised Ducati Service Centre shall place their stamp and write the necessary notes on the Service Booklet supplied with the motorcycle,...
  • Page 20 If you purchased your motorbike in Australia or New Zealand Attention A reference to ‘you’ is a reference to the Customer. If you purchased your motorbike in Australia: Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and compensation for any other reasonably fore‐...
  • Page 21 “Dealer Locator” (available at www.ducati.com) of any defects of the motorcycle within two (2) months of becoming aware of the defect. If you have any questions, you may contact Ducati ANZ Pty Ltd ACN 636 589 430 at Level 6, 895 South Dowling Street, Zetland NSW 2017 or by email at contac‐...
  • Page 22: General Information

    Important Black Box System Possibility of damaging the motorcycle and/or its components. Cruise Control Note Ducati Diagnostic System Additional information about the current Ducati Quick Shift operation. Ducati Traction Control The terms RIGHT and LEFT are referred to the Ducati Wheelie Control motorcycle viewed from the riding position.
  • Page 23: Intended Use

    Intended use Attention The maximum weight permitted for the side Attention panniers, top case and the tank bag must never This motorcycle was designed for both road use exceed 30 kg (66 lb), divided as follows: and for light off-road and dirt road use. Heavy duty 10 kg (22lb) max.
  • Page 24: Rider's Obligations

    Rider's obligations Attention All riders must hold a valid licence. Check your state laws. Obtain insurance coverage and keep your insurance document secure Attention with the other motorcycle documents. Riding without a licence is illegal and is To protect rider and passenger safety, some states prosecuted by law.
  • Page 25: Rider's Training

    Rider's training Accidents are frequently due to inexperience. Riding, manoeuvres and braking must be performed in a different way than on the other vehicles. Attention Untrained riders or a wrong use of the vehicle may lead to loss of control, serious injuries or even death.
  • Page 26: Apparel

    Apparel Important Riding gear is very important for safety. Unlike cars, Never wear loose clothing, items or accessories a motorcycle offers no impact protection in an that may become tangled in motorcycle parts. accident. Important Proper riding gear includes helmet, eye protection, For your safety, always wear suitable protective gloves, boots, back protector, long sleeve jacket and gear, regardless of season and weather.
  • Page 27: Safety ""Best Practices

    "Riding the motorcycle" during the running- Important in period. Failure to follow these instructions releases Ducati Rider must hold the handlebar with both hands Motor Holding S.p.A. from any liability whatsoever at ALL TIMES while riding.
  • Page 28 Important Attention Be sure you are clearly visible and do not ride Engine, exhaust pipes and silencers stay hot within the blind spot of vehicles ahead. long after the engine is switched off; pay particular attention not to touch the exhaust system with any Important body part and do not park the vehicle next to ALWAYS signal your intention to turn or pull to...
  • Page 29: Refuelling

    Refuelling Fuel label Fuel identification label Refuel outdoors with engine off. Do not smoke or use open flames while refuelling. Be careful not to spill fuel on engine or exhaust pipe. Never completely fill the tank when refuelling. Fuel should never be touching the rim of filler recess. When refuelling, avoid breathing the fuel vapours and prevent fuel from reaching your eyes, skin or clothes.
  • Page 30: Carrying The Maximum Load Allowed

    Carrying the maximum load allowed Important Your motorcycle is designed for long-distance riding, Never fix bulky or heavy objects to the carrying the maximum load allowed in full safety. handlebar or to the front mudguard as this would Even weight distribution is critical to preserving affect stability and cause danger.
  • Page 31: Dangerous Products - Warnings

    Attention If you install the side panniers (available on Spilling brake fluid onto plastic, rubber or request from Ducati Parts service), sort out luggage painted parts of the motorcycle may cause damages. and accessories according to their weight and Protect these parts with a clean shop cloth before arrange them in the side panniers to evenly proceeding to service the system.
  • Page 32 remove the radiator cap when the engine is hot. The coolant is under pressure and will cause severe burns. The cooling fan operates automatically: keep hands well clear and make sure your clothing does not snag on the fan. Battery Attention The battery gives off explosive gases;...
  • Page 33: Vehicle Identification Number

    Vehicle identification number Note These numbers identify the motorcycle model and should always be indicated when ordering spare parts. Fig 2 DUCATI PLANT OF MANU FACTURE TYPE OF MOTORCYCLE SEQUENTIAL MODEL NUMBER YEAR ZDM 2 A 0 2 A A # B 0 0 0 0 0 1 # Varies-can be Ø...
  • Page 34: Engine Identification Number

    Engine identification number Note These numbers identify the motorcycle model and should always be indicated when ordering spare parts. Fig 4...
  • Page 35: Main Components And Devices

    Main components and devices Position on the vehicle 1) Tank filler plug. 2) Seat lock. 3) Side stand. 4) Rear-view mirrors. 5) Front fork adjusters. 6) Rear shock absorber adjusters. 7) Catalytic converter. 8) Exhaust silencer. 9) USB socket. 10) Windscreen. 11) Coolant check.
  • Page 36: Tank Filler Plug

    Tank filler plug Opening Lift flap (1) and insert the key in the lock. Turn the key clockwise to release the lock. Lift the plug (2). Closing Turn the key in the plug clockwise to release the lock. Close the plug (2) with the key inserted and push it down into its seat until you hear its locking "click”.
  • Page 37: Seat Lock

    Seat lock Working lock (1) you can remove the passenger seat, to reach the tool box, and the rider seat, to reach the battery maintainer connector and other devices. Removing the passenger seat OPEN Insert the key into the catch (1) and turn it clockwise until the passenger seat latch disengages with an audible click.
  • Page 38: Removing The Rider Seat

    Removing the rider seat To remove the rider seat (4): slide the seat backwards and upwards at the same time to release it from the guides (5). Fig 10 Fig 11...
  • Page 39 With the seats removed, the connector (6) for the battery maintainer is accessible. To use it, slide it out from the clamp (X) and connect it to maintainer (7), as described in chapter “Maintaining the battery charge”. Fig 12...
  • Page 40 Position the rider seat (4) on the vehicle, making sure to correctly fit it into the lower part of guides (5). Attention Have rider seat and passenger seat in high or low mode correctly configured by a Ducati Dealer or authorised Service Centre. Fig 13 Fig 14...
  • Page 41 Position the rider seat (4) on the vehicle, making sure to correctly fit it into the upper part of guides (5). Attention Have rider seat and passenger seat in high or low mode correctly configured by a Ducati Dealer or authorised Service Centre. Fig 15 Fig 16...
  • Page 42 Refitting the passenger seat Check correct rider seat positioning according to low mode or high mode. If the rider seat has been fit in low mode, turn the brackets with rubbers blocks (D) of the passenger seat (2) upwards (Fig 17). If the rider seat has been fit in high mode, turn the brackets with rubbers blocks (D) of the passenger seat (2) downwards (Fig 17).
  • Page 43: Maintaining The Battery Charge

    When the motorcycle is left unused (approximately for more than 30 days). We recommend owners to Fig 20 use the Ducati battery charge maintainer (Battery...
  • Page 44 Note Using charge maintainers not approved by Ducati could damage the electric system; motorcycle warranty does not cover the battery if damaged due to failure to comply with the above indications, since it is considered as wrong maintenance.
  • Page 45: Side Stand

    Side stand Important Place the motorcycle on the side stand only when you are not going to use it for short periods of time. Before lowering the side stand, make sure that the bearing surface is hard and flat. Attention The position of the side stand is identified on the instrument panel by the warning light (A).
  • Page 46 To ensure trouble-free operation of the side stand If the instrument panel does not receive side stand joint, thoroughly clean it and then use SHELL status, the stand down/open “STAMP. LATER.” Alvania R3 grease to lubricate all friction points. indication will flash to indicate an undefined status. Attention Do not sit on the motorcycle when it is supported on the side stand.
  • Page 47: Installing The Ducati Side Panniers (If Any)

    Installing the Ducati side panniers (if any) Installing the plastic side bags (if any) Insert the key (1) in the lock and turn it clockwise. Open the handle (2) and lift the lever (3) towards the front side, until it is perpendicular to the bag.
  • Page 48 Position the side bag by inserting top hooks (4) in the corresponding housing (5). Note Position the front hook first and then the rear hook. Check the correct positioning of the bag (6) on the lower support (7). Fig 25 Fig 26...
  • Page 49 If there are any problems with the movement, contact a Ducati Dealer or Authorised Service Centre. Attention Pay attention to the safe positioning of your hands when checking the swinging movement.
  • Page 50 Installing the aluminium side panniers (if any) Attention To fit/remove the subframe kit for aluminium side panniers and to set it to “floating” or “fixed” mode, please contact your Ducati Dealer or authorised service centre. Attention To carry out all opening / closing or...
  • Page 51 “floating” mode, check the swinging movement of both, moving them to the right and left, on the rear side of the panniers. If there are any problems with the movement, contact a Ducati Dealer or Authorised Service Fig 31 Centre. Attention Pay attention to the safe positioning of your hands when checking the swinging movement.
  • Page 52 Attention Always ensure that the panniers are correctly fitted and fastened to the vehicle. Attention Ensure that the weight of the panniers is evenly distributed on both sides to avoid problems of vehicle imbalance. Attention Install both side panniers; for safety reasons, it is not permitted to install only one of them.
  • Page 53 Attention Failure to observe weight limits could result in poor handling and impair the performance of your motorcycle, and you may lose control of the motorcycle. Attention The maximum permissible weight for the side panniers, top case and the tank bag must never exceed 30 kg (66.13 lb), divided as follows: 10 kg (22 lb) max.
  • Page 54 Attention Failure to observe weight limits could result in poor handling and impair the performance of your motorcycle, and you may lose control of the motorcycle. Attention Clean the side panniers with a soft, clean cloth using lukewarm soapy water. Avoid the use of aggressive agents or rough tools.
  • Page 55 Removing the plastic side bags (if any) Insert the key (1) in the lock and turn it clockwise. Open handle (2). Lift the lever (3) towards the front side, until it is perpendicular to the bag. OPEN Fig 34 Fig 35...
  • Page 56 Repeat the same operation for removing the other side bag. Attention To fit/remove the subframe kit for aluminium side panniers and to set it to “floating” or “fixed” mode, please contact your Ducati Dealer or authorised service centre. Fig 36 Fig 37...
  • Page 57 Lift up the pannier to release both its hooks. Attention To fit/remove the subframe kit for aluminium side panniers and to set it to “floating” or “fixed” mode, please contact your Ducati Dealer or Fig 38 authorised service centre.
  • Page 58 The Multistrada's plastic or aluminium pannier system is equipped with a special floating system which allows the side panniers and Top Case to move during high speed riding, improving the stability of the vehicle. This system must not be blocked or compromised, for example by mounting accessories or panniers that prevent movement.
  • Page 59 Maxi‐ Type of panniers fit‐ Max speed Type of assembly Image allowed load Plastic fibre pannier 180 Km/h 10 Kg + (floating) (112 mph) 10 Kg 10 Kg + Plastic fibre panniers + 160 Km/h 10 Kg + Top Case (both floating) (100 mph) 5 Kg Plastic fibre Top Case...
  • Page 60 Maxi‐ Type of panniers fit‐ Max speed Type of assembly Image allowed load ALUMINIUM panniers 160 Km/h 10 Kg + (floating) (100 mph) 10 Kg ALUMINIUM panniers 10 Kg + 160 Km/h + Top Case (both float‐ 10 Kg + (100 mph) ing) 5 Kg...
  • Page 61 Maxi‐ Type of panniers fit‐ Max speed Type of assembly Image allowed load ALUMINIUM panniers 150 Km/h 10 Kg + (locked and FIXED) (93 mph) 10 Kg ALUMINIUM panniers 10 Kg + (locked and FIXED) + 150 Km/h 10 Kg + ALUMINIUM Top Case (93 mph) 5 Kg...
  • Page 62: Using The Side Panniers (If Any)

    Using the side panniers (if any) Using the plastic side bags (if any) Opening To open the side bag, turn the key (1) in the lock (2) clockwise and release the latch (3) by lifting at the rear. Closing To close the side bag, turn the key (1) in the lock (2) Fig 39 anti-clockwise and lock the latch (3) by lifting and closing it again, making sure the cover (4) is engaged...
  • Page 63 Using the aluminium side panniers (if any) Opening Open the side pannier as follows. Insert the key (1) in the pannier lock and turn it to the open position. Lift the lever (2) and then lift the cover (3). Fig 41 Fig 42...
  • Page 64 The cover (3) can be opened on both sides of the side pannier. After lifting the cover (3), press the lever (4) on the back of the side pannier, the cover (3) can be opened as shown in the figure. Fig 43 Fig 44...
  • Page 65 Closing Place the cover (3) on the side pannier and proceed as follows. Place the coupling element (4) on the relevant connection, as shown in the figure Fig 45 Fig 46...
  • Page 66 Close the cover (3) and push the lever (2) fully down, as shown in the figure. Turn the key (1) to the lock closing position. Remove the key (1). Fig 47 Fig 48...
  • Page 67 Attention To carry out all opening / closing or installation / removal operations on the panniers, operate only the appropriate levers and never use the key to transmit force. Attention The side panniers are only for light luggage: each pannier can hold a maximum weight of 10 kg (22 lb).
  • Page 68: Usb Connection

    USB connection The motorcycle is provided with a 5 V USB connection. It is possible to connect electric loads up to 1 A to the USB connection. The USB connection (2) is located on the left front dashboard and is protected by a lid (1). Opening the USB compartment: Place your thumb on the opening area and your opposite finger on the lid (1).
  • Page 69 Attention The water tightness of the USB socket compartment is ensured for cables up to 3.6 mm (0.14 in) in diameter. The use of cables with a larger diameter, such as those of 4.44 mm (0.17 in) supplied by some companies, prevents the compartment from being properly closed, causing water ingress.
  • Page 70: Adjusting Windscreen Height

    Adjusting windscreen height Adjust windscreen height using lever (1). Push up to lift the windscreen, or down to lower it. Attention Adjusting windscreen height while riding could cause an accident. Adjust the windscreen only with motorcycle at a standstill. Fig 52...
  • Page 71: Adjusting The Front Fork

    Adjusting the front fork The front fork used on this motorcycle has rebound (return), compression and spring preload adjustment. Adjustment is done by external screw adjusters: ● adjuster (1) to adjust the compression damping; ● adjuster (2) for rebound adjustment; ●...
  • Page 72 completely anticlockwise, to obtain fully uncompressed position. From this position, adjust the spring preload by turning the adjuster clockwise. Every turn corresponds to 1 mm (0.04 in) of spring preload. STANDARD settings are as follows: ● Compression on LH fork leg: -3 ± 1/4 turns from fully closed;...
  • Page 73: Adjusting The Rear Shock Absorber

    Adjusting the rear shock absorber The rear shock absorber has external controls that enable you to adjust the setting in order to suit the load on the motorcycle. The adjuster (1), located on the shock absorber upper connection, adjusts the damping during the compression phase.
  • Page 74 From this position, adjust the preload by turning the knob clockwise. STANDARD setting: ● Compression: -1.75 ± 1/4 turns from fully closed; ● Rebound: -0.75 ± 1/4 turns from fully closed; ● Preload: 0 clicks from fully unloaded; Attention The shock absorber is filled with gas under pressure and may cause severe damage if taken apart by unskilled persons.
  • Page 75: Controls

    Controls Position of motorcycle controls Attention This section shows the position and function of the controls used to ride the motorcycle. Be sure to read this information carefully before you use the controls. 1) Instrument panel. 2) Ignition switch. 3) Left-hand switch. 4) Clutch lever.
  • Page 76: Switchgears

    Switchgears Fig 58...
  • Page 77 Control button up Control button down Control button left Control button right ENTER function button Three-position turn indicator control: ● position (6a), left turn indicator ● centre position, OFF ● position (6b), right turn indicator Warning horn Hazard lights (red). Cruise control RES/+ Cruise control SET/- Cruise control ON/OFF...
  • Page 78 Light selector: ● high beam, pushed up ● low beam, at the centre ● high-beam flasher and “Start/Stop Lap” function, pushed down DRL (if present) Fog lights ON/OFF (long press, if any) Engine start Engine kill, pushed down (red) Heated grips (if present)
  • Page 79: Light Control

    Light control Low / High beam By means of button (A) it is possible to switch from low beam to high beam and vice versa: position (B) for high beam, position (C) for low beam. To flash, press the button in position (D). If engine is not started after turning the key to on, it is nevertheless possible to switch on the lights or flash.
  • Page 80 Using the DRL light in "Auto" mode in case of poor light conditions, especially in case of fog or clouds, could impair safety. In this case Ducati recommends to manually activate the low beam. DRL in "Manual" mode – only for version with DRL lights If the DRL is in this mode, as set through the "DRL"...
  • Page 81 Turn indicators Using the "Turn indicators" function in the "Settings - Vehicle” menu, you can set the control of the turn indicators to automatic or manual mode. To activate the left turn indicator, press button (F), in position (G); to activate the right turn indicator, press button in position (H).
  • Page 82: Hazard Lights

    Hazard lights To activate or deactivate the hazard lights, press button (I), only when the vehicle is in key-on condition. When turning the vehicle key OFF with hazard lights active, they will remain active for 2 hours. After 2 hours, the hazard lights switch OFF automatically in order to save battery charge.
  • Page 83 Note Fog lights (if any) Emergency braking To switch the fog lights on/off (if any): In the event of heavy braking from a speed of more ● if DRL lights are present, long press and hold than 55 km/h the tail light flashes rapidly in order to button (E);...
  • Page 84: Keys

    Keys The motorcycle comes with 2 keys. They contain the "Immobilizer system code". The keys are those for the standard use, i.e. to: ● start the engine; ● open the fuel tank plug; ● open the seat lock. Attention Separate the keys and use only one of the two to ride the bike.
  • Page 85: Duplicate Keys

    The Ducati authorised service centre will program all new and old keys. The Ducati authorised service centre may ask to the customer to prove to be the motorcycle owner. The codes of the keys missing during the programming procedure will be erased to ensure that any lost key can not start the engine.
  • Page 86: Key-Operated Ignition Switch And Steering Lock

    Key-operated ignition switch and steering lock It is located in front of the fuel tank and has three positions: : enables lights and engine operation; : disables lights and engine operation; : the steering is locked. Note To move the key to the last position, press it down before turning it.
  • Page 87: Restoring Motorcycle Operation Via The Pin Code

    If this procedure is necessary in order to start ● If there is a problem during the PIN check, the the motorcycle, contact an Authorised Ducati instrument panel displays “Time out” for 2 Service Centre as soon as possible to fix the problem.
  • Page 88: Clutch Lever

    Clutch lever Lever (1) disengages the clutch. It features a dial adjuster (2) for lever distance from the handgrip on handlebar. The lever distance can be adjusted through 10 clicks of the dial (2). Turn clockwise to increase lever distance from the handgrip. Turn the adjuster anticlockwise to decrease lever distance.
  • Page 89: Throttle Twistgrip

    Throttle twistgrip The handgrip on the right handlebar opens the throttles. When released, it will spring back to the initial position (idling speed). Fig 66...
  • Page 90: Front Brake Lever

    Front brake lever Pull in the lever (1) towards the handgrip to operate the front brake. The system is hydraulically operated and you just need to pull the lever gently. The brake lever (1) has a dial (2) for adjusting the distance between lever and handgrip on the handlebar.
  • Page 91: Rear Brake Pedal

    Rear brake pedal Press pedal down with your foot to operate the rear brake. The control system is of the hydraulic type. Fig 68...
  • Page 92: Gear Change Pedal

    Gear change pedal When released, the gear change pedal automatically returns to rest position N in the centre. This is indicated by the instrument panel light N coming on. The pedal can be moved: ● down = press down the pedal to engage the 1 gear and to shift down.
  • Page 93: Adjusting The Position Of The Gearchange Pedal And Rear Brake Pedal

    Have the gear change pedal (1) and rear brake pedal (2) adjusted at a Ducati Dealer or authorised Service Centre. Fig 70 Fig 71...
  • Page 94: Riding The Motorcycle

    Riding the motorcycle ● Do not ride at full throttle, especially when the engine is cold. ● Avoid starting at full throttle and rapid acceleration. ● Avoid abrupt and prolonged braking, act Motorcycle running-in period carefully on the brakes. During the running-in period, do not exceed the rpm ●...
  • Page 95: Pre-Ride Checks

    Pre-ride checks ● CONTROLS Work the brake, clutch, throttle and gear change Attention controls (levers, pedals and twistgrip) and check Failure to carry out these checks before riding, for proper operation. may lead to motorcycle damage and injury to rider ●...
  • Page 96: Abs Warning Light

    OFF to confirm the SPORT correct operation of the ABS system. km/h Gear Attention In case of malfunction, do not ride the Total 2326 km motorcycle and contact a Ducati Dealer or °C °C authorised Service Centre. Fig 72...
  • Page 97: Abs Device

    ABS device Check that the front (1) and rear (2) phonic wheels are clean. Attention Clogged reading slots would compromise system proper operation. It is recommended to disable ABS system in case of muddy road surface because under this condition the system might be subject to sudden failure.
  • Page 98: Engine Start/Stop

    Engine start/stop Attention Before starting the engine, become familiar with the controls you will need to use when riding. Attention Never start or run the engine indoors. Exhaust gases are poisonous and may lead to loss of consciousness or even death within a short time. Turn the key to position (B) and check that the green light (C) and the red light (D) are on.
  • Page 99 Attention The side stand must be fully up (in a horizontal position) as its safety sensor prevents engine starting when down. Note It is possible to start the engine with side stand down and the gearbox in neutral. When starting the motorcycle with a gear engaged, pull the clutch lever (in this case the side stand must be up).
  • Page 100 To stop the engine, move the red switch (1) downwards to the "RUN OFF" position. Turn the vehicle key off by turning the key to position (A). Attention When the engine is cold, start immediately after starting the engine to ensure a gradual and uniform warm-up of all the components of both the engine and the vehicle.
  • Page 101: Moving Off

    Moving off Attention Raise the side stand until it is horizontal, as Avoid harsh acceleration, as this may lead to confirmed by the switching off of the warning misfiring and transmission snatching. The clutch light on the instrument panel. lever should not be held in longer than necessary 2) Squeeze the control lever to disengage the after a gear is engaged, otherwise friction parts may clutch.
  • Page 102: Engine Shutdown In The Event Of A Motorbike Rollover

    Engine shutdown in the event of a motorbike rollover This system is designed to stop the engine in case of motorbike rollover being detected for a certain amount of time. The purpose of the system is to limit the likelihood of engine damage in the event of a rollover (e.g.
  • Page 103: Braking

    Braking This avoids wheel lockup and preserves traction. Pressure is raised back up immediately and the Slow down in time, shift down to use engine brake control unit keeps controlling the brake until the risk and then brake by operating both front and rear of a lockup disappears.
  • Page 104: Stopping The Motorcycle

    Stopping the motorcycle Reduce speed, shift down and release the throttle handgrip. Shift down to engage first gear and then neutral. Apply the brakes and bring the motorcycle to a complete stop. Stop the engine by pushing the red switch (1) down. Turn the vehicle key off by turning the key to position (A).
  • Page 105: Parking

    Parking Park the stopped motorcycle on the stand. To prevent theft, turn the handlebar fully left or right and turn the ignition key to position (A). If you park in a garage or other indoor area, make sure that there is proper ventilation and that the motorcycle is not near a source of heat.
  • Page 106: Refuelling

    Refuelling Never overfill the tank when refuelling. Fuel should never be touching the rim of filler recess. Warning The fuel pressure inside the tank may, in extreme cases, cause fuel to “spray” when opening the fuel cap. Always open the fuel cap slowly and carefully during the refill.
  • Page 107 Fuel label The label identifies the fuel recommended for this vehicle. 1) The E5 reference inside the label indicates the use of fuel with a maximum oxygen content of 2.7% by weight and a maximum ethanol content of 5% by volume, according to EN 228.
  • Page 108: Tool Kit And Accessories

    Tool kit and accessories The compartment under the passenger seat (1) houses an owner's manual and a tool kit (2), which includes the following: ● Tear-proof canvas envelope. ● Flat-blade/Phillips screwdriver PH2. ● 8/10 double-ended wrench. ● 3 mm (0.11 in) Allen wrench. ●...
  • Page 109: Instrument Panel (Dashboard)

    Instrument panel (Dashboard) Instrument panel The motorbike is equipped with an instrument panel featuring a TFT colour display. The instrument panel provides all the information needed for safe driving and allows you to customise the vehicle settings and parameters.
  • Page 110: Warning Lights

    Warning lights Menu Infomode SPORT Gear Gear km/h SIDE STAND Total 2326 km °C °C Fig 85 The example shows the Road Infomode screen page.
  • Page 111 no. Description Colour 1 Left turn indicator Green (display) 2 Right turn indicator Green (display) 3 Limiter 4 Limiter / Immobilizer 5 Neutral gear Green (display) 6 Side stand down Red (display) 7 ABS system malfunction Amber yellow (display) ● flashing: ABS in self-diagnosis and/or functioning with degraded per‐...
  • Page 112 The warning light turns on flashing to warn about a critical emission-re‐ lated error that could damage the catalytic converter. If possible, have the vehicle be taken to a Ducati authorised service centre and the malfunction eliminated and at any rate proceed slowly, avoid harsh acceleration and overtaking.
  • Page 113 If the display shows the message “TRANSPORT MODE”, immediately contact your Ducati Dealer that will delete this message and ensure the full operation of the motorcycle. Upon key-on, the instrument panel displays the Ducati Logo followed by an animation and carries out a sequential check of the LED warning lights.
  • Page 114 ● the warning light check routine and leave ON only the warning lights that are actually active at the moment.
  • Page 115: Infomode

    Infomode 3 main screen display modes (Infomode) are available: Road, Road Pro, Rally. At any time, you can change Infomode in Road, Road Pro and Rally order by holding down the button for a long time. It is also possible to change Infomode via the “Infomode change”...
  • Page 116 Road Infomode 09:09 Menu Infomode SPORT km/h Gear Total 2326 km °C °C Fig 86...
  • Page 117 The table below lists the items available in the Road Infomode. Description Speed It is displayed increased by 5% and together with the set unit of measurement (km/h or mph). Riding Mode in use Gear Rev counter Riding Info Refer to section “My Ride - Riding Info”. Air temperature (°C or °F) Note When the motorcycle is stopped, the engine heat could influence the displayed temperature.
  • Page 118 Description Engine Coolant temperature (°C or °F) The temperature display range goes from +40°C to +110°C (+104°F ÷ +230°F). When the temperature is lower than +40°C (+104°F), the “Low” message is displayed. When the temperature is higher than +110°C (+230°F), the flashing “High” red message is displayed. Attention In case of overheating, if possible, it is recommended to ride at reduced speed to allow the cooling system to lower the engine temperature.
  • Page 119 Road Infomode - navigation buttons The navigation buttons in the Road Infomode are managed as follows: ● short pressure on button to open the function menu; ● short pressure on buttons to scroll through the available trip info; ● long pressure on button to open the “My Ride - Riding Info”...
  • Page 120 Road Pro Infomode 09:09 °C Menu Infomode % Power DWC Of % Torque °C Fig 87...
  • Page 121 The table below lists the items available in the Road Pro Infomode. Description Speed It is displayed increased by 5% and together with the set unit of measurement (km/h or mph). Riding Mode in use Gear Rev counter Power and Torque This function allows the user to get a quick overview of relevant power and torque information.
  • Page 122 Description Engine Coolant temperature (°C or °F) The temperature display range goes from +40°C to +110°C (+104°F ÷ +230°F). When the temperature is lower than +40°C (+104°F), the “Low” message is displayed. When the temperature is higher than +110°C (+230°F), the flashing “High” red message is displayed. Attention In case of overheating, if possible, it is recommended to ride at reduced speed to allow the cooling system to lower the engine temperature.
  • Page 123 Road Pro Infomode - navigation buttons The navigation buttons in the Road Pro Infomode are managed as follows: ● short pressure on button to open the function menu; ● long pressure on button to go to the next Infomode.
  • Page 124 Rally Infomode 09:09 Menu Infomode Trip master 85.0 Star Move °C Fig 88...
  • Page 125 The table below lists the items available in the Rally Infomode. Description Speed It is displayed increased by 5% and together with the set unit of measurement (km/h or mph). Riding Mode in use Gear Rev counter Trip master Clock It is possible to set it through the “Date and time”...
  • Page 126 Description Fuel level Available in 2 modes: graduated bar or km or miles remaining. It is possible to set it through the “Fuel indicator” function in the “Settings - Display” menu. Note When the fuel is low, the relevant indicator is forced in the remaining km or mile mode. Parameter menu and quick level change.
  • Page 127 Rally Infomode - navigation buttons The navigation buttons in the Rally Infomode are managed as follows: ● long pressure on button to open the function menu; ● short pressure on buttons to select the Trip master controls; ● short pressure on button for interaction of the selected Trip master control;...
  • Page 128: Riding Mode

    Riding Mode 09:09 5 Riding Modes are available: Sport, Touring, Urban, Enduro, Wet. Menu Infomode The name of the active Riding Mode is displayed SPORT above the speed indication (A) (Road Infomode is shown in the example). km/h Gear Each Riding Mode is associated with a different colour for the relevant name.
  • Page 129 Changing the Riding Mode ● Press the MODE button (1). The display shows the page from which it is possible to scroll the available Riding Modes and view their parameters together with the relevant settings. ● Use buttons or briefly press MODE button (1) to scroll and select the desired Riding Mode.
  • Page 130 “Settings - Advanced” menu. As soon as the new Riding Mode is confirmed, the Ducati recommends performing the Riding Mode instrument panel checks the following conditions: change with the motorbike at a standstill. If the ●...
  • Page 131: Engine Rpm Indication

    Engine rpm indication 09:09 The number of engine rpm is displayed in the following ways: Menu Infomode ● using a rev counter with a grey wake (A) in Road SPORT and Road Pro Infomode; ● using a rev counter with a graduated scale and 12 12 Gear km/h...
  • Page 132 these conditions, the engine speed limitation intervenes with a slightly lower threshold than the nominal one. ● if the engine temperature is above 60 °C (140 °F), the rev counter wake will not turn amber yellow. The wake becomes flashing red when the rev limiter trips (Over-rev).
  • Page 133: Parameter Menu And Quick Level Change

    Parameter menu and quick level 09:09 change Menu Infomode This function is only available in the Rally Infomode and allows you to quickly change the parameter Trip master levels associated with the Riding Mode in use. 85.0 The right part of the screen shows the following parameters and their levels (A): ●...
  • Page 134: Changing The Level

    Changing the level 09:09 ● If the selection on the Trip Master is active, long Menu Infomode press the button ● The symbols (B) are displayed on the right-hand Trip master side of the DTC level. 85.0 ● Using the buttons , you can select the parameter you want to change (e.g.
  • Page 135: Temporary Abs System Deactivation

    Temporary ABS system deactivation 09:09 Attention Menu Infomode The ABS can be disabled. Trip master This function is available inside the Rally Infomode and can be used only with the Enduro Riding Mode: it allows deactivating and reactivating the ABS system.
  • Page 136 Attention The window (B) will remain active as long as the ABS system is disabled. Press the button reactivate the ABS system at level 1. Note If the speed is not 0, the “ABS Off with speed 0 only” warning is displayed for a few seconds.
  • Page 137: Trip Master

    Trip master 09:09 This function is available in the Rally Infomode and calculates the partial distance travelled by the bike. Menu Infomode The Trip master calculation can be set in incremental Trip master or differential mode and can also be temporarily stopped and reset to zero.
  • Page 138 When the Trip master is selected, the following controls are activated: Trip master ● “On” or “Off” to activate or deactivate the Trip master (B). When set to “Off”, the distance 85.0 meter is displayed in grey; when it is set to “On, it is displayed in black in light theme, white in the dark theme.
  • Page 139: Cruise Control

    Cruise Control Attention Cruise Control (CC) assists the rider in maintaining a The Cruise Control is not a safety system, but constant cruising speed. The system maintains the its function is improving the rider's riding comfort. It desired cruising speed by accelerating and acting on is designed to assist the rider, but does not replace the brakes, within the limits of the system.
  • Page 140 (see paragraphs "Changing the speed" and "Stopping the speed control"). Switching on and off The Ducati Cruise Control system controls the vehicle speed only between 50 Km/h (30 mph) and 200 Km/h (125 mph).
  • Page 141 The icon on the instrument panel informs the user of 09:09 system status and current setting. Switching on the CC Menu Infomode SPORT Press the ON/OFF button (C) to turn on the CC. Saving the speed and activating the control 12 12 Gear km/h...
  • Page 142 ● red: the system is in error. Speed control is not In this condition, the cruising speed in the Cruise active. Control icon turns grey. If the system operating conditions are verified, speed control can be Changing the cruising speed reactivated by pressing RES/+ (D) or SET/- (E).
  • Page 143 Attention The rider is always responsible for compliance with the speed limits and, more generally, the road traffic regulations in force in the country in which s/ he is riding, as well as for the way the motorcycle is ridden. Note It is not possible to downshift using the DQS when the Cruise Control is on.
  • Page 144 Note Perform this operation only when the motorcycle is at a standstill and in safe conditions; Total 2326 km 2. if the icon has remained red after the first operation, contact a Ducati authorised service °C °C centre. Fig 105...
  • Page 145: Function Menu

    Function menu 09:09 This menu (A) contains a series of functions that can be activated and are grouped in the following sub- Close menus: SPORT ● My Ride Set ings ● Smart features (grey if no Bluetooth device is 12 12 connected) ●...
  • Page 146 ● Riding Info (includes all trip information) ● Infomode change (allows selecting the Infomode) ● Lap (allows recording the lap times) ● Heated handgrips (allows setting the heating level of handgrips) The Smart features sub-menu contains the following functions related to infotainment and connected Bluetooth devices: ●...
  • Page 147: My Ride - Riding Info

    My Ride - Riding Info This menu contains all the meters relating to trip 09:09 information divided into two groups: “General info” Back Close and “Trip info”. SPORT Heated grips The unit of measurements of the trip info can be changed using the “Units”...
  • Page 148 General Information Name Description Measurement units / format Total Total odometer km, miles Range Residual range km, miles visible only if the fuel level display mode has been set to “Level” by using the “Fuel indicator” function in the “Settings - Display” menu. Consumption Instantaneous fuel consumption L/100, km/l, mpg UK, mpg...
  • Page 149 Trip info Name Description Measurement units / format Trip 1 Partial mileage 1 km, miles Ø consumption 1 Average consumption 1 L/100, km/l, mpg UK, mpg Ø speed 1 Average speed 1 km/h, mph Trip 1 time Travel time 1 hhh:mm Trip 2 Partial mileage 2...
  • Page 150 Resetting Trip 1 information 09:09 The “Trip 1”, "Ø consumption 1", "Ø speed 1" and "Trip Back Close 1 time" information can be reset when displayed SPORT within the “My Ride - Riding Info” menu by pressing Reset trip the button when selected: the display shows Set ings 12 12...
  • Page 151 Riding Info within the Road Infomode 09:09 Within the Road Infomode the same information is shown below the speed indication (C). Use buttons Menu Infomode to scroll through all available SPORT information. In the Road Infomode, the “My Ride - Riding Info” km/h Gear menu can be accessed directly by long pressing the...
  • Page 152 My ride - Infomode change This function allows changing the Infomode selecting it among three options: Road, Road Pro, Back Close Rally. You can also change Infomode by long pressing the button , refer to the chapter "Infomode". Riding info Infomode change To open this function: ●...
  • Page 153 My ride - Lap This function allows recording lap times and is only available in the Road and Road Pro Infomode. Close Back To open this function: Riding info ● Open the function menu. Infomode change ● Use buttons to select the “My Ride” item and press the button ●...
  • Page 154 The window (B) is displayed: ● If the function is disabled, the stopwatch and the indication of the available laps are displayed Close Back in grey (C) and the text “On” (D) is shown: press the button to enable the function. ●...
  • Page 155 Note to display the time of the current lap, updating the number of laps. When the 60th lap is reached, the If during lap recording the flash button (6) is message “Full” is displayed and it is not possible to pressed to start/stop the stopwatch, any further record new times: in this case, delete the saved laps button presses occurred within 5 seconds will not be...
  • Page 156: My Ride - Heated Grips (If Available)

    My ride - Heated grips (if available) This function is only available if heated handgrips have been installed and allows you to activate and Back Close set the heating of the handgrips. Infomode change To open this function: ● Open the function menu. ●...
  • Page 157 Note The actual turning on (heating) of the heated handgrips occurs only with engine started, and when a certain number of engine rpm have been reached and maintained: heating power is limited to 50% up to 2,000 rpm.
  • Page 158 The heated handgrips can be set using button (1). Press the button (1) to display the heated handgrips icon in large mode: each press of the button cycles through the high, medium, low and off levels indicated by the arrows on the symbol (C). To confirm the set level, simply do not press the button (1) for 3 seconds: the heated handgrips icon is then displayed in the small mode (C).
  • Page 159: Smart Features - Navigator (If Any)

    Contact Ducati Services for updated information on To access the “Turn by Turn” functions, it is necessary the territorial areas of map usability. Ducati has tested many of the most popular and ● have a compatible smartphone (not included) recent smartphones; however, the operating...
  • Page 160 ● The Ducati Link function must be activated on Connected the smartphone. Successful connection is indicated by the presence of the Ducati Link icon (A) within the “Device status” function in the “Smart features” menu. Fig 121 To start the function: ●...
  • Page 161 Note The item "Turn by turn" is displayed in grey if the smartphone has not been connected via Bluetooth and/or the connection with the Ducati Link app has not been started. A compact version of the navigator is also available, which is always visible with the menu closed or in other menu sections.
  • Page 162 Directions Press the button to confirm. Note Stop navigation Favourite addresses, entering a new destination and route settings are managed directly by the Ducati Link app. Fig 123 Refer to what is indicated in the Ducati Link app.
  • Page 163 Directions This function allows you to set the mode in which the directions are displayed. The submenu is displayed Back Close and includes the following available modes: ● • "Voice + Visual" (E), directions are displayed both via audio and graphically on the instrument panel (refer to the "Turn by turn screen"...
  • Page 164: Delete Route

    Delete route 09:09 This function allows you to stop the navigation in progress. “Delete route?” is displayed, press the button Stop confirm or press the button to cancel. navigation? If stop is confirmed, the navigation is interrupted and the instrument panel returns to the main screen Confirm set up before navigation was started.
  • Page 165: Smart Features - Phone (If Any)

    Smart features - Phone (if any) This function is available only if the Bluetooth control unit is installed and only in Road and Road Back Close Pro Infomodes in the “Smart features” menu: it allows viewing the list of the last 7 missed, made or received calls and can only be selected if a Navigator smartphone has been connected via Bluetooth.
  • Page 166 Note If the list includes no calls, “Empty” is displayed. Attention Ducati has tested many of the most popular and recent smartphones; however, the operating systems and technological choices made by smartphone manufacturers are not under Ducati's control. Therefore, it is not possible to guarantee operation on all phones on the market and their software and firmware.
  • Page 167: Incoming Call

    Call in progress When a call is in progress a window is shown with the Close name or number of the phone contact as well as the item “End call” (C). To end the call, press and hold button for a long time. Set ings During the call, it is possible to exit the call display to Mario...
  • Page 168: Missed Call

    Call back At the end of a call or after declining an incoming call, Close the window with the name or number of the phone contact and “Accept” and Decline” items (F) will be Call back displayed for a few seconds: press the button Mario Set ings start the call, press the button...
  • Page 169: Smart Features - Music (If Any)

    Attention ● Select the “Music” item (A) and press the button Ducati has tested many of the most popular and recent smartphones; however, the operating Note systems and technological choices made by Music is played on the smartphone connected smartphone manufacturers are not under Ducati's via Bluetooth.
  • Page 170: Volume Adjustment

    The player window (B) is displayed showing the music player controls and the title of the current track: if the title is not available, “Not available” is Menu displayed. By pressing the buttons it is possible to Not available scroll and select the following controls; to activate the selected control (except for the volume), press the button ●...
  • Page 171: Smart Features - Devices Status (If Any)

    Back Back Close Close smartphone network, connection to the Ducati Link app, etc. The devices paired but not currently connected to Iphone 15 Plus the instrument panel are greyed out. Connected...
  • Page 172: Settings

    Settings This menu allows enabling, disabling and setting 09:09 Gear some motorcycle functions. Close For safety reasons, you can enter this Menu only when the actual vehicle speed is lower than or equal Devices to 5 km/h (3 mph). If you are inside the Settings Vehicle Menu and the actual vehicle speed exceeds 5 km/h (3 Advanced...
  • Page 173 The following table shows the structure of the submenus and related functions contained in the Settings menu: submenu level 1 submenu level 2 submenu level 3 Tyre pressure (if available) Tyre calibration Coming home light Vehicle Turn indicators PIN Code Service and info Power Mode Advanced...
  • Page 174 submenu level 1 submenu level 2 submenu level 3 Backlight Themes Date and time Units Display Language Fuel indicator Trip master precision Riding info order Devices (if present) Bluetooth...
  • Page 175: Settings - Vehicle

    Settings - Vehicle This submenu contains all the following settings for 09:09 Gear the vehicle: ● Tyre pressure (if available) Close ● Tyre calibration Devices ● ● Coming home light Vehicle ● Turn indicators Advanced Display ● ● PIN Code °C ●...
  • Page 176: Settings - Vehicle - Tyre Pressure (If Available)

    Settings - Vehicle - Tyre pressure (if available) 09:09 Gear This function allows setting the reference pressure Vehicle Back Close for the front and rear tyre pressure sensors. Available Current only if tyre sensors are present. Service and info ● Enter the Settings menu.
  • Page 177 ● The items “Front tyre” and “Rear tyre” are 09:09 displayed. Gear ● Use buttons to select the desired Vehicle Tyre pressure Close Back item and press the button Service and info When “Front tyre” or “Rear tyre” is selected, the current pressure value is displayed with two arrows Tyre pressure Front tyre...
  • Page 178 Settings - Vehicle - Tyre calibration This function allows the user to run the procedure for 09:09 Gear calibrating and teaching in the tyre rolling Vehicle circumference or to restore their original values. Back Close It also allows you to correctly learn the final drive Next ratio (front sprocket/rear sprocket) in the event of Tyre pressure...
  • Page 179 ● The “Start calibration” and “Default” items are 09:09 displayed (only visible if a calibration has already Gear been performed). Vehicle Tyre calibration Back Close ● Use buttons to select the desired item and press the button to confirm and go back to the previous screen.
  • Page 180 Tyre calibration - Start calibration 09:09 When entering the function, by pressing the button Exit with “Start calibration” selected, the instrument panel shows the screen to proceed with calibration. Ready This screen shows the message “Ready” and the Keep speed indication to maintain a constant speed within 49 km/h (30 mph) and 51 km/h (32 mph), with second 49 - 51 km/h...
  • Page 181 In the event of front sprocket and/or rear sprocket replacement, after performing the “Tyre Calibration” procedure, it is necessary to go to an authorised Ducati dealer who will perform a “drive adaptive system reset” with the diagnosis instrument. This allows you to avoid false plausibility diagnoses related to the final drive ratio modification.
  • Page 182 Attention Final Rear sprocket drive ra‐ Changing the final drive ratio may result in the OBD diagnosis being validated and the MIL warning light on the instrument panel turning on. Front 15 2.67 2.73 2.87 2.93 In these cases it may also happen that the ECU sproc 2.56 2.63...
  • Page 183 Settings - Vehicle - DRL This function allows setting the status of the DRL in 09:09 Gear automatic or manual mode. Available only if daytime Vehicle Back Close running lights (DRL) are present. Current ● Enter the Settings menu. Tyre pressure ●...
  • Page 184: Settings - Vehicle- Coming Home Light

    Settings - Vehicle- Coming home light 09:09 Gear This function allows activating or deactivating the Vehicle Back Close Coming Home Light function: if active, each time the Current motorbike is switched off (key-off) the headlights Tyre Calibration are activated for a few seconds. Coming home light ●...
  • Page 185 When the function is set to “Off” the DRL light is activated for some seconds at key-off. Note If the parking light is activated after the key- off, the low beam and DRL light are deactivated. Note In case of battery disconnection, the function is automatically set to “Off”.
  • Page 186: Settings - Vehicle- Turn Indicators

    Settings - Vehicle- Turn indicators This function allows user to set the turn indicators to 09:09 Gear automatic mode or manual mode. Vehicle Back Close The turn indicator automatic switch-off strategy is Current implemented based on calculation of leaning angle, vehicle speed and run distance.
  • Page 187: Settings - Vehicle - Lap

    Settings - Vehicle - Lap This function allows enabling or disabling the Lap 09:09 Gear function in the “My Ride” menu and viewing and Vehicle Back Close deleting the recorded Lap data. Current ● Enter the Settings menu. Coming home light ●...
  • Page 188 Lap data 09:09 Gear By selecting and confirming the “Lap data” item, the ... Lap Lap data Back Close display shows the list with “Best laps” and available laps (up to 60). Lap 13 Use buttons to scroll through the Time Speed Max Lap 14...
  • Page 189: Erase Data

    Erase data 09:09 Gear By selecting and confirming the “Erase data” item, ... Lap Erase data the display shows the “Accept” and “Decline” items: Close press the button to erase all data of the recorded laps or press the button to cancel and return to Erase data? Lap date...
  • Page 190: Settings - Vehicle - Pin Code

    Ducati authorised dealer to will include “New PIN” item to activate it. reset it. The Ducati authorised dealer may ask you to If the PIN Code has already been activated, this demonstrate that you are the owner of the menu will include the “Modify PIN”...
  • Page 191 New PIN 09:09 Gear ● Enter the Settings menu..Pin code New pin Close Back ● Use buttons to select the “Vehicle” item and press the button Turn indicators ● Select the “PIN code” item and press ● Select the “New PIN” item and press the button PIN code New PIN 0 0 0 0...
  • Page 192: Modify Pin

    Modify PIN 09:09 Gear ● Enter the Settings menu. Vehicle Close Back ● Use buttons to select the “Vehicle” item and press the button Next Turn indicators ● Select the “PIN code” item and press ● Select the “Modify PIN” item and press the PIN code Modify PIN button...
  • Page 193 ● The arrows above and below the digit indicate that the value can be changed from 0 to 9 using buttons ● Press the button to edit to the other digits. ● Once the desired code is complete, press the button ●...
  • Page 194: Settings - Vehicle - Service And Info

    Settings - Vehicle - Service and info This function allows viewing the deadlines for the 09:09 Gear next service coupons, battery voltage and the Vehicle engine rpm digital indication. Back Close Total 260.000 km ● Enter the Settings menu. XXXXXXXXXXXXXXXXX ●...
  • Page 195: Service Warnings

    Service warnings 09:09 This indication shows the user that the motorcycle is Close due for service and must be taken to a Ducati Authorised Service Centre. SPORT The service thresholds are provided in the chapter 12 12 "Scheduled maintenance chart: operations to be - 1000 km performed by the dealer".
  • Page 196 The history of routine maintenance is saved on Ducati's servers in order to certify that it has been carried out (it is a digital maintenance booklet). The bike owner is able to see the performed services both in the MyGarage reserved area (on Ducati.com...
  • Page 197: Settings - Advanced

    Settings - Advanced This submenu contains all the following advanced 09:09 Gear settings for the motorbike: ● Riding Mode Setup Close To access this submenu: Vehicle ● Enter the Settings menu. Advanced ● Use buttons to select the Display “Advanced” item and press the button Devices Use buttons to navigate within the...
  • Page 198: Settings - Advanced - Riding Mode Setup

    Settings - Advanced - Riding Mode setup 09:09 Gear This function allows customising each Riding Mode. Advanced Back Close ● Enter the Settings menu. Current Power High ● Use buttons to select the “Advanced” item and press the button Riding Mode setup SPORT ●...
  • Page 199 Note The customisable parameters are the following: ● Power mode With the motorbike at a standstill, the Riding ● Mode setting menu can be accessed directly from ● the Riding Mode change screen. ● ● ● ● Default (visible only if one or more parameters have been modified) Use buttons to scroll through the...
  • Page 200: Settings - Advanced - Riding Mode Setup - Power Mode

    Settings - Advanced - Riding Mode setup - Power mode 09:09 Gear This function allows customising the Power mode Spor setup Back Close level. Current ● Enter the Settings menu. Default ● Use buttons to select the Power mode “Advanced” item and press the button ●...
  • Page 201 Settings - Advanced - Riding Mode setup - ABS 09:09 Gear This function allows setting the ABS intervention Spor setup Back Close level. Current ● Enter the Settings menu. Power mode ● Use buttons to select the “Advanced” item and press the button ●...
  • Page 202 motorcycle: the possibility of falling or having an ● the “cornering” function, which optimises the accident during this difficult moment is statistically ABS operation even when the vehicle is leaning higher than any other moment. When one or both over. The system manages the front and rear wheels lock, the stabilising action of traction fails, brake systems according to the leaning angle of resulting in loss of control of the vehicle.
  • Page 203 Ducati motorbikes are developed and calibrated When riding in the rain or on slippery surfaces, using the OE tyres recommended by Ducati; in braking will become less effective. Always use the particular, the vehicle's OE tyres are listed in the brakes very gently and carefully when riding under “Technical specifications”...
  • Page 204 ABS intervention level table The ABS system fitted to this bike is a safety system preventing wheel lock-up while braking, adopting different strategies depending on the selected level. The ABS features 3 levels, one associated to one or more Riding Modes. The following table indicates the most suitable level of ABS intervention for the various riding types as well as the default settings in the Riding Mode that can be selected by the rider: RIDING MODE...
  • Page 205 RIDING MODE CHARACTERISTIC DEFAULT SPORT This level is designed for road use, with It is the default level for the good grip conditions. ABS in this level “SPORT” Riding Mode. controls both wheels and the cornering and anti-lift-up functions are active. This calibration gives priority to the braking power while ensuring a good compromise between performance...
  • Page 206 Attention and skidding as much as possible, within the physical limits allowed by the vehicle and by the road The ABS OFF level can only be activated by conditions. means of the “Temporary ABS system deactivation” function available only in the Rally Infomode and can Selecting level 2, the ABS will privilege more the only be activated with Enduro Riding Mode.
  • Page 207 Off, so both the wheelie control and the vehicle dynamics stabilisation control are deactivated. The Ducati Traction Control system (DTC) supervises the rear wheel slipping control and settings vary through eight different levels that are calibrated to offer a different tolerance level to rear wheel slipping.
  • Page 208 This function allows setting the intervention level of the DTC or deactivating it. 09:09 ● Enter the Settings menu. Gear ● Use buttons to select the Spor setup Back Close “Advanced” item and press the button Current Power mode ● Select the “Riding Mode setup”...
  • Page 209 ● Sport, Touring and Urban Riding Modes: DTC standards and the requirements of the road traffic levels from 3 to 8 and “Off”. code. ● Enduro Riding Mode: DTC levels 1, 2 and “Off”. ● Wet Riding Mode: DTC levels 7, 8 and “Off”. Use buttons to scroll and select the desired level.
  • Page 210 Anti-Lock Braking System (DTC) The following table indicates the most suitable level of DTC intervention for the various riding modes, as well as the default settings in the “Riding Mode” that can be selected by the rider: RIDING MODE OPERATION CHARACTERISTIC DEFAULT LEVEL The DTC is disabled.
  • Page 211 RIDING MODE OPERATION CHARACTERISTIC DEFAULT LEVEL SPORT This level is designed for road use, with It is the default level for the good grip conditions. Sport Riding Mode. TOURING This level is designed for use in any rid‐ It is the default level for the ing conditions, on the road with good Touring Riding Mode.
  • Page 212 OE tyres and/or at similar speeds or at very different speeds) with the ones recommended by Ducati. In particular, The riding mode (whether the rider has a OE tyres for this motorcycle are indicated in the "smooth"...
  • Page 213 further, rather than with a "rough“ style” where the If changes occur in the grip conditions and/or circuit motorcycle is straightened up as quickly as possible characteristics and/or your riding style, and the level when exiting a turn. setting is no longer suitable, switch to the next level up or down and proceed to determine the best Tips for use on the track setting (e.g.
  • Page 214 In case of deactivated. intervention of the DWC system for wheelie control The Ducati Wheelie Control system (DWC) or for the stabilisation of the vehicle dynamics, the supervises control of wheelie movement and warning light on the dashboard is lit.
  • Page 215 This function allows setting the intervention level of the DWC or deactivating it. 09:09 ● Enter the Settings menu. Gear ● Use buttons to select the Spor setup Back Close “Advanced” item and press the button Current ● Select the “Riding Mode setup” item and press the button ●...
  • Page 216 Attention DWC is a rider aid that can be used on both the track and the road. The system is designed to make riding easier and to enhance safety, but in no way relieves the rider of the obligation to drive responsibly and to maintain a high standard of riding in order to avoid accidents, whether caused by his own errors or those of other road users, through...
  • Page 217 Anti-Lock Braking System (DWC) The following table indicates the most suitable level of DWC intervention for the various riding modes, as well as the default settings in the “Riding Mode” that can be selected by the rider: DEFAULT LEVEL The DWC is disabled. It is the default level for the Enduro Riding Mode.
  • Page 218 DEFAULT LEVEL HIGH SAFE & STABLE Level for all kinds of riders. The system It is the default level for the reduces the motorcycle's proneness to Urban and Wet Riding Modes. do wheelies to a minimum level and sensitively intervenes in case of wheel‐...
  • Page 219 OE The rider's experience tyres and/or with the ones recommended by Ducati. The choice of level setting depends greatly on the In particular, OE tyres for this motorcycle are riders' experience and ability to control wheelies on indicated in the “Technical specifications”...
  • Page 220 (e.g. if with level 3 the DWC intervention seems excessive, switch to level 2; alternatively, if on level 3 you cannot perceive any DWC intervention, switch to level 4). Recovery in case of error If a DWC fault occurs while the DTC system is switched on, a specific function is activated to inform the user of the fault in good time.
  • Page 221: Settings - Advanced - Riding Mode Setup - Ebc

    Settings - Advanced - Riding Mode Attention setup - EBC EBC is a rider aid that can be used both on the track and the road. The system is designed to make The Engine Braking Control (EBC) system controls riding easier, but in no way relieves the rider of the engine braking when riding with throttle control obligation to ride responsibly and to maintain a high completely closed (both when downshifting and in a...
  • Page 222 This function allows setting the EBC intervention level. 09:09 ● Enter the Settings menu. Gear ● Use buttons to select the Spor setup Back Close “Advanced” item and press the button Current ● Select the “Riding Mode setup” item and press the button ●...
  • Page 223 The following table indicates the most suitable level of EBC intervention for the various riding types as well as the default settings in the Riding Modes that can be selected by the rider: CHARACTERISTIC DEFAULT LEVEL In this level the engine delivers the maximum engine brake. It is the default level for the SPORT and TOURING Riding Modes...
  • Page 224 OE tyres and/or The choice of the correct level mainly depends on with the ones recommended by Ducati and with the the following parameters: OE final drive ratio. In particular, OE tyres for this 1) The grip (type of tyre, amount of tyre wear, motorcycle are indicated in the “Technical...
  • Page 225: Settings - Advanced - Riding Mode Setup - Dqs

    Settings - Advanced - Riding Mode setup - DQS 09:09 Gear This function allows activating or deactivating the Spor setup Back Close DQS system. Current ● Enter the Settings menu. ● Use buttons to select the “Advanced” item and press the button ●...
  • Page 226 The system works in a different way ● If the Ducati Quick Shift strategy does not work when upshifting and downshifting. it is always possible to complete the gear shifting using the clutch lever. Here below are some tips that will ensure you ●...
  • Page 227: Settings - Advanced - Riding Mode Setup - Default

    This function allows restoring the values of the Advanced Riding Mode setup Back Close parameters linked to the Riding Modes set by Ducati and is visible only if the parameters have been ENDURO setup WET setup previously modified. All default...
  • Page 228 Resetting of parameter values for a single 09:09 Gear Riding Mode: Spor setup Close Back ● Enter the Settings menu. ● Use buttons to select the “Advanced” item and press the button. ● Select the “Riding Mode setup” item and press Default ●...
  • Page 229 The following table shows the default values set by Ducati for all the parameters of all Riding Modes: SPORT TOURING URBAN ENDURO Power Mode High Medium Offroad Up/Down Up/Down Up/Down Up/Down Up/Down...
  • Page 230: Settings - Display

    Settings - Display This submenu contains all the following settings for 09:09 Gear the display and the displayed information: ● Backlight Close ● Themes Vehicle ● Date and time Advanced ● Units Display ● Language Devices ● Fuel indicator ● Trip master precision °C ●...
  • Page 231: Settings - Display - Brightness

    Settings - Display - Brightness This function allows dashboard backlighting setting. 09:09 Gear ● Enter the Settings menu. Display Back Close ● Use buttons to select the “Display” Current item and press the button. Riding info order ● Select the “Brightness” item and press the Brightness button Themes...
  • Page 232: Settings - Display - Themes

    Settings - Display - Themes This function allows the light or dark theme of the 09:09 Gear display to be set. Display Back Close ● Enter the Settings menu. Current ● Use buttons to select the “Display” item and press the button.
  • Page 233: Settings - Display - Date And Time

    Settings - Display - Date and time This function allows setting date and time as well as 09:09 Gear the relevant formats. Display Back Close ● Enter the Settings menu. Current ● Use buttons to select the “Display” Brightness item and press the button.
  • Page 234 Set date 09:09 Gear This function allows setting the date, in the example ... Date and time Set date shown here the date format is year/month/day. Back Close ● Enter the Settings menu. Current: 2024 / 12 / 21 ● Use buttons to select the “Display”...
  • Page 235: Date Format

    Date format 09:09 Gear This function allows setting the date format. Display Date and time Close Back ● Enter the Settings menu. ● Use buttons to select the “Display” Brightness item and press the button. Themes Set date ● Select the “Date and time” item and press Date and time Date format ●...
  • Page 236 Set time 09:09 Gear This function allows setting the time, in the example Display Date and time Close Back shown here the time format is 12 hours (AM/PM). ● Enter the Settings menu. Brightness Set date ● Use buttons to select the “Display” Themes Date format item and press the...
  • Page 237: Settings - Display - Units

    Settings - Display - Units This function allows setting the units of 09:09 Gear measurement used by the instrument panel. Display Back Close ● Enter the Settings menu. Current ● Use buttons to select the “Display” Themes item and press the button.
  • Page 238 Speed 09:09 Gear To set the speed measurement unit: ... Units Speed ● Enter the Settings menu. Back Close ● Use buttons to select the “Display” Current item and press the button. Default ● Select the “Units” option and press Speed km/h ●...
  • Page 239 Temperature 09:09 Gear To set the temperature measurement unit: Display Units Back Close ● Enter the Settings menu. ● Use buttons to select the “Display” Current Themes item and press the button. Date and time Speed ● Select the “Units” option and press Units Temperature °C...
  • Page 240 Consumption 09:09 Gear To set the consumption measurement unit: Display Units Back Close ● Enter the Settings menu. ● Use buttons to select the “Display” Current Themes Speed item and press the button. Date and time Temperature ● Select the “Units” option and press Units Consumpt...
  • Page 241 Pressure (if available) 09:09 Gear To set the pressure measurement unit: Display Units Close Back ● Enter the Settings menu. ● Use buttons to select the “Display” Current Themes Temperature item and press the button. Date and time Consumption ● Select the “Units”...
  • Page 242 Restoring the unit of measurement 09:09 Gear You can restore all or a single unit of measurement..Units Default Close To restore all measurement units: ● Enter the Settings menu. Consumption Restore Restore ● Use buttons to select the “Display” Pressure to default? to default?
  • Page 243 To restore a single unit of measurement: 09:09 ● Enter the Settings menu. Gear ● Use buttons to select the “Display” ... Units Speed Back Close item and press the button. ● Select the “Units” option and press Default Restore ●...
  • Page 244: Settings - Display - Language

    Settings - Display - Language This function allows setting the instrument panel 09:09 Gear language. Display Back Close ● Enter the Settings menu. Current ● Use buttons to select the “Display” Date and time item and press the button. Units Language English ●...
  • Page 245: Setting - Display - Fuel Indicator

    Setting - Display - Fuel indicator This function allows changing the display mode of 09:09 Gear the fuel level, by choosing among graduated bar or Display Back Close remaining km or miles. Current ● Enter the Settings menu. Units ● Use buttons to select the “Display”...
  • Page 246: Settings - Display- Trip Master Precision

    Settings - Display- Trip master precision 09:09 Gear This function allows setting the accuracy level of the Display Back Close Trip Master function. Current ● Enter the Settings menu. Language Fuel indicator ● Use buttons to select the “Display” Trip master precis. 0.1 km item and press the button Riding info order...
  • Page 247: Settings - Display - Riding Info Order

    Settings - Display - Riding info order This function allows changing the order of the 09:09 Gear general info and the order of the trip info within the Display Back Close “Riding Info” menu in the “My Ride” function. Current General Current Trip ●...
  • Page 248 Modify order 09:09 Gear The following description is valid for both “General General info order info order” and “Trip info order”; in the example Back Close shown, the position of the “Total” item contained in Current General the “General info order” submenu is changed: Rear tyre 1 Total ●...
  • Page 249 ● The selected item and 2 arrows (C) above and 09:09 below the position number (in the example “1”) Gear are displayed to indicate that its value can be ... General info order Total Close Back changed using buttons Current General ●...
  • Page 250: Settings - Devices (If Present)

    Settings - Devices (if present) This submenu is only available if the Bluetooth 09:09 Gear control unit has been installed and contains all the following settings for Bluetooth device Close management: Advanced ● Bluetooth Display Devices To access this submenu: ●...
  • Page 251: Settings - Devices - Bluetooth (If Present)

    Settings - Devices - Bluetooth (if present) 09:09 Gear This function is available only if the Bluetooth Devices Back Close control unit is installed and allows the user to Next manage any paired Bluetooth devices and add more. ● Enter the Settings menu. Bluetooth Add device ●...
  • Page 252: Adding A New Bluetooth Device

    Adding a new Bluetooth device 09:09 Gear ● Enter the Settings menu. Devices Bluetooth Back Close ● Use buttons to select the “Devices” item and press the button Next Forget all devices ● Select the “Bluetooth” item and press the button Add device Phone...
  • Page 253 ● Once confirmed, if the pairing of the device has been successful, the message “Paired” is displayed for a few seconds and then the instrument panel returns to the previous screen. Otherwise, “Pairing error” is displayed.
  • Page 254 If you are pairing an headset device, during pairing 09:09 you are asked to assign the device the role of “Rider” Gear or “Passenger”: ... Headset Headset Mario Back Close ● Press the button to assign the rider role. ● Press the button to assign the passenger Assign role:...
  • Page 255 These changes are outside the control of ● MAP profile: for a correct display of SMS and Ducati and may result in Smartphone and Bluetooth MMS notifications; Headset devices functionality becoming impaired ● PBAP profile: for a correct display of the (sharing Music, multimedia player, etc.) and may...
  • Page 256: Deleting A Bluetooth Device

    Deleting a Bluetooth device 09:09 Gear ● Enter the Settings menu..Bluetooth Iphone XYZ X... Back Close ● Use buttons to select the “Devices” item and press the button ● Select the “Bluetooth” item and press the Add device button Iphone XYZ X...
  • Page 257 Deleting all Bluetooth devices 09:09 Gear ● Enter the Settings menu. Devices Bluetooth Close ● Use buttons to select the “Devices” item and press the button Next IPhone XYZ X... ● Select the “Bluetooth” item and press the Samsung FTRS XXXXXX button Forget all devices Forget all paired devices...
  • Page 258: Engine Auto Shutdown

    Engine auto shutdown 09:09 This function warns the rider when the engine is automatically switched off by the control unit. Close When the motorbike is stationary, depending on the SPORT engine temperature, a timer is activated after which the engine is switched off. In this case, the warning Engine auto “Engine auto shutdown Press start”...
  • Page 259: Ducati Link App Connection

    Ducati Link app connection If a smartphone with the Ducati Link app active is connected, the relevant icon (A) is displayed on the instrument panel within the “Devices status” Back Back Close Close function included in the “Smart features” menu.
  • Page 260 instrument panel returns to the screen displayed prior to function activation. In case of errors during the configuration saving, the message “Error” is displayed for a few seconds, then the instrument panel returns to the screen displayed before the function activation.
  • Page 261: Warning Displaying

    Warning displaying 09:09 The instrument panel manages a number of warnings and alarms, aimed at giving useful Close information to the rider during use. SPORT Upon key-on, if there are any active warnings, the instrument panel will display the messages for all the present warnings or alarms: in a large size (A) for the first seconds and then in a smaller size (B).
  • Page 262 Yellow, it indicates that you must ride carefully on Fig 230 the asphalt as the current DTC setting was devised Ducati recommends to ride carefully and use this for off-road use. type of setting only for off-road use. Ducati recommends to ride carefully and use this type of setting only for off-road use.
  • Page 263 No key (G) Yellow indicates that the inserted key was not No key acknowledged. Set date (H) Set Date Date The yellow colour indicates that the date must be entered using the "Date and time" function in the "Settings - Display” menu. Ice (I) Yellow, it means that there might be ice on the road, Set pressure...
  • Page 264 Front pressure (K) and Rear pressure (L) high – accessories High front pressure The yellow colour indicates that the corresponding tyre pressure is high. They are only displayed if the High tyre pressure sensors are present on the motorcycle. rear pressure Front pressure (M) and Rear pressure (N) low –...
  • Page 265 Rear TPMS available for the corresponding tyre(s). Ducati recommends that the sensor be checked as High High soon as possible because it is necessary to replace it.
  • Page 266 Low fuel (S) Yellow, it indicates that the fuel level is low. There is no small version of the warning. Note When the fuel is low, the relevant indicator is forced in the remaining km or mile mode. Low fuel Fig 234...
  • Page 267: Error Warnings

    5 seconds. Fig 235 ABS error! 09:09 Activation of this error indicates that it is necessary to go to a Ducati Authorised Service Centre as the Menu Infomode ABS error! vehicle ABS is in error. SPORT...
  • Page 268 Traction control error! 09:09 Activation of this error indicates that it is necessary Close to go to a Ducati Authorised Service Centre as the vehicle Traction Control is in error. SPORT ● (A) large size. Traction ● (B) small size.
  • Page 269: Main Use And Maintenance Operations

    Main use and maintenance operations "Checking coolant level and topping up, if necessary" Press at the indicated point to release the cover (1). Lift the cover (1) to check coolant level in the expansion tank on the right side of the vehicle. Check the level according to the intervals indicated Fig 239 in the tables in "Scheduled maintenance chart".
  • Page 270 Attention This operation must be performed with cold engine. Failure to observe the above recommendation may lead to coolant or hot vapour leakage with possible consequent severe burns.
  • Page 271: Checking Brake And Clutch Fluid Level

    Brake and clutch fluid must be topped up and changed at the intervals specified in the scheduled maintenance table contained in the Warranty Booklet; please contact a Ducati Dealer or Authorised Service Centre. Fig 241 Fig 242...
  • Page 272: Brake System

    Do not exceed the pedal and brake pads are still in good condition, specified level (3 mm (0.12 in) above the minimum contact your Ducati Dealer or authorised Service level). Centre to have the system inspected and any air drained out of the circuit.
  • Page 273: Checking Brake Pads For Wear

    Friction material wear beyond this limit would lead to metal support contact with the brake disc thus compromising braking efficiency, disc integrity and rider safety. Important Fig 243 Have the brake pads replaced at a Ducati Dealer or authorised Service Centre. Fig 244...
  • Page 274: Charging The Battery

    Charging the battery Removing the battery Remove the tank front cover (1). Undo screws (2) and remove battery cover (3). Fig 245 Fig 246...
  • Page 275 Loosen the screws (4), remove the black negative cable (5) from the negative terminal (-) and the red positive cable (6) from the positive terminal (+), always starting with the negative one (-). Remove the battery (7) sliding it upwards. Fig 247...
  • Page 276: Refitting The Battery

    Refitting the battery Grease the screws (4). Refit the battery (7) on the mount, connect the red positive cable (6) to the positive terminal (+) and the black negative cable (5) to the negative terminal (-) of the battery, always starting from the positive one (+).
  • Page 277 Position battery cover (3) and tighten screws (2). Refit the tank front cover (1). Fig 249 Fig 250...
  • Page 278 (-). to a completely flat battery, it is not permitted to Ducati disclaims any liability deriving from the use of start the bike by connecting an external starter or non-original Ducati chargers or maintainers.
  • Page 279: Checking Drive Chain Tension

    Checking drive chain tension Important Have chain tension adjusted by a Ducati Dealer or authorised Service Centre. Make the rear wheel turn until you find the position where chain is tightest. Set the motorcycle on the side stand. With just a finger, push down the chain at the point of measurement and release.
  • Page 280 Attention Correct tightening of the rear wheel shaft (1) and of the adjustment screws (2) is critical to rider and passenger safety. Important Improper chain tension will lead to early wear of transmission parts. Important To ensure the best performance and long life of the chain, please follow the information related to chain cleaning, lubrication, inspection and Fig 252...
  • Page 281: Lubricating The Drive Chain

    Lubricating the drive chain Important Have drive chain cleaned by a Ducati Dealer or authorised Service Centre. Attention Carry out these inspection operations with the engine off, the vehicle at a standstill, on a flat ground and on the stand.
  • Page 282 Check the chain tension (4) as indicated in the sub- section “Checking the drive chain tension”. Avoid the use of steam, fuel, solvents, hard Have the chain tension adjusted by a Ducati Dealer brushes or other methods that could damage the O- or authorised Service Centre.
  • Page 283 Lubrication Important Have drive chain cleaned by a Ducati Dealer or authorised Service Centre. Attention Use SHELL Advance Chain to lubricate the chain; the use of non-specific lubricants could damage the O-rings and therefore the entire drive system. It is recommendable to lubricate (5) the chain...
  • Page 284 Apply the lubricant jet (1) inside the chain between the inner and outer links, in point (2) immediately before the engagement point on the sprocket. Due to the centrifugal force, the lubricant, made fluid by the solvents contained in the spray, will expand in the working area between the pin and the bush, ensuring perfect lubrication.
  • Page 285 After lubrication, wait 10-15 minutes to allow the lubricant to act on the internal and external surfaces of the chain and then remove the excess lubricant with a clean cloth. Important Do not use the motorcycle immediately after lubricating the chain as the lubricant, still fluid, would be centrifuged outwards causing possible soiling of the rear tyre or the rider's footpeg.
  • Page 286: Aligning The Headlight

    Aligning the headlight Note Headlight features two adjusters, one for the RH beam and one for the LH beam. Check correct headlight aiming. Position the motorcycle 10 m (32.8 ft) from a wall or a screen, the motorcycle must be perfectly upright with the Tyres inflated to the correct pressure and with a rider seated, perfectly perpendicular to the longitudinal axis.
  • Page 287 To align the headlight beam, turn the screws (1) and (2) located at the front of the vehicle, on both sides. Stand facing the instrument panel and locate the two screws to adjust them. Screw (1), positioned on the left side, acts on the left headlight: ●...
  • Page 288: Adjusting The Rear-View Mirrors

    It is possible to make a further adjustment by turning the screw (2), for which it is necessary to contact a Ducati Dealer or Authorised Service Centre. After this last operation, it is necessary to adjust the rear-view mirror by turning the dome (1).
  • Page 289: Tubeless Tyres

    0.2 ÷ 0.3 Note bar (2.9÷4.35 PSI). Have the tyres replaced at a Ducati Dealer or Tyre repair or change authorised Service Centre. Correct removal and installation of the wheels is essential. Some parts of...
  • Page 290: Minimum Tread Depth

    Minimum tread depth Measure tread depth (S, Fig 261) at the point where tread is most worn down: it should not be less than 2 mm (0,078 in), and in any case not less than the legal limit. Important Visually inspect the tyres at regular intervals for detecting cracks and cuts, especially on the side walls, bulges or large spots that are indicative of internal damage.
  • Page 291: Check Engine Oil Level

    Oil level should be between the marks on the sight glass. If the level is low, top up with engine oil. Ducati prescribes the only use of SAE 15W-50/JASO MA2 oil and recommends the use of Shell Advance DUCATI 15W-50 Fully Synthetic Oil.
  • Page 292: Use Of Ducati Corse Performance Oil By Shell

    Use of Ducati Corse Performance Oil by Shell Attention The use of Ducati Corse Performance Oil by Shell is not allowed on this model as it would damage the engine. The Ducati Corse Performance Shell Advance oil is made exclusively for Desmosedici Stradale engines equipped with dry clutch.
  • Page 293: Cleaning The Motorcycle

    Cleaning the motorcycle Important To preserve the finish of metal parts and paintwork, Do not wash your motorcycle right after use. wash and clean your motorcycle at regular intervals, When the motorcycle is still hot, water drops will anyway according to road conditions. Use specific evaporate faster and spot hot surfaces.
  • Page 294 Attention Pay special attention when cleaning the wheel rims since they have parts in machined aluminium; clean The headlight might fog up due to washing, and dry them every time you use the vehicle. rain or moisture. Switch headlight on for a short time to help and dry up any condensate.
  • Page 295: Storing The Motorcycle

    Periodically carry out the required checks and renew During service operations such as repairs, parts as necessary, using Ducati original spare parts, maintenance activities, operations under warranty, in compliance with the regulations in the country and quality assurance, service network personnel concerned.
  • Page 296 Within the scope of these services, personal data are processed in compliance with current legislation on data protection, based on a legitimate interest of Ducati to ensure increasingly efficient assistance, and finally to comply with legal obligations (e.g. information obligations on repairs and maintenance).
  • Page 297: Vehicle Transport

    Vehicle transport Before transporting the motorcycle using another vehicle, follow the safety instructions below. Remove all loose objects and accessories from the vehicle; 2) Align the front wheel straight in the riding direction and lock it properly to prevent any movement;...
  • Page 298: Scheduled Maintenance Chart

    Scheduled maintenance chart Scheduled maintenance chart: operations to be carried out by the dealer Important Using the motorcycle under extreme conditions, such as very damp and muddy roads or dusty and dry environment, could cause above-average wear of components like the drive system, the brakes or the air filter.
  • Page 299 Service Check (every 12 months) Valve check (every 30,000km/18,000mi) Oil Service (every 15,000 km/9,000 mi or 24 months) Oil Service 1000 Check secondary air reeds • Change spark plugs • Replace the water pump seal and bushing • Change coolant (if present) •...
  • Page 300 Service Check (every 12 months) Valve check (every 30,000km/18,000mi) Oil Service (every 15,000 km/9,000 mi or 24 months) Oil Service 1000 Check the tightening of swinging arm and rear shock absorber fasteners • • Check front and rear wheel hub bearings •...
  • Page 301 Service Check (every 12 months) Valve check (every 30,000km/18,000mi) Oil Service (every 15,000 km/9,000 mi or 24 months) Oil Service 1000 Check the operation of all electric safety devices (clutch and side stand sensor, front and • • • rear brake switches, engine kill switch, gear/neutral sensor) Check lighting devices, turn indicators, horn and controls operation •...
  • Page 302: Scheduled Maintenance Chart: Operations To Be Carried Out By The Customer

    Scheduled maintenance chart: operations to be carried out by the Customer Important Using the motorcycle under extreme conditions, such as very damp and muddy roads or dusty and dry environment, could cause above-average wear of components like the drive system, the brakes or the air filter.
  • Page 303: Technical Data

    Technical data Weights Total weight (kerb weight without fuel): 202 kg (445.33 lb). Maximum permissible weight (in running order carrying full load): 457 kg (1007.51 lb). Attention Failure to observe weight limits could result in Fig 264 poor handling and impair the performance of your motorcycle, and you may lose control of the motorcycle.
  • Page 304: Dimensions

    Dimensions 958 mm (37.71 in) 987 mm (38.85 in) 1570 mm (61.81 in) 2243 mm (88.30 in) Fig 265 * Sump guard in engineering plastic / in aluminium: 203 mm (7.99 in) / 199 mm (7.83 in). ** Low seat (optional): 830 mm (32.67 in).
  • Page 305: Fuel, Lubricants And Other Fluids

    (0.88 gal) leaded premium fuel with a minimum of (4.17 gal) octane rating of RON 95 Oil sump and filter Ducati recommends you use SHELL Ad‐ 3.8 litres vance 4T Ultra 15W-50 oil (JASO: MA2, (0.83 gal) API: SN) SHELL Advance DUCATI 15W-50 Fully...
  • Page 306 TOP-UPS TYPE Front fork RH and LH leg oil quan‐ tity: 540 ±10g (1.19±0.02 lb) - 645 cu. cm (39.36 cu. LH leg oil level: 105 mm (4.13 in) RH leg oil level: 115 mm (4.52 in) (measured without pre‐ load tube and with rod fully home on bump rubber)
  • Page 307 These references identify the fuel recommended for this vehicle, as specified by the European Regulation EN228. Attention The use of Ducati Corse Performance Oil by Shell is not allowed on this model as it would damage the engine. The Ducati Corse Performance Shell Advance oil is made exclusively for Desmosedici Stradale engines...
  • Page 308: Engine

    Engine Max. rotation speed: 11325 rpm. Ducati V2, Twin cylinder, L-type, timing system with Important 4 valves per cylinder, liquid cooling. Do not exceed the specified rpm limits in any Bore: 96 mm (3.77 in) running conditions. Stroke: 61.5 mm (2.42 in) Attention Total displacement: 890 cu.
  • Page 309: Performance Data

    Using fuel Failure to follow these instructions releases with ethanol content over 10% will make the Ducati Motor Holding S.p.A. from any liability warranty null and void. whatsoever for any engine damage or shorter engine Brakes life.
  • Page 310: Transmission

    Brake master cylinder type: radial. shaft via spur gears, 1.844:1 ratio. Cylinder Ø: 18 mm (0.71 in). Front chain sprocket/clutch gearwheel ratio: 32/59. 6-gear gearbox with Ducati Quick Shift (DQS) up/ REAR down EVO. With fixed drilled steel disc. Gearbox output sprocket/rear chain sprocket ratio: Disc diameter: 265 mm (10.43 in).
  • Page 311: Frame

    Attention Front If the rear sprocket needs replacing, contact a “Tubeless", radial tyre. Ducati Dealer or authorised Service Centre. Size: 120/70 ZR19 M/C 60W. If improperly replaced, this component could Make and type: Pirelli Scorpion Trail II. seriously endanger your safety, as well as the Alternatively Pirelli Scorpion Rally STR (M+S).
  • Page 312: Suspension

    Rear pressure (Pirelli Scorpion Trail II): 2.5 bar (rider Suspension travel: 59 mm (2.32 in). only) - 2.9 bar (rider with passenger and/or bags + Wheel travel: 170 mm (6.69 in). Top Case). Exhaust system Pirelli Scorpion Rally STR (tubeless): Single silencer and tailpipe in stainless steel, with 3 lambda sensors and 1 catalytic converter.
  • Page 313: Electric System

    Electric system Rear ones (USA), LED units: No. 3 OSRAM KY DMLN31.FY LEDs. Basic electric items are: Tail light Instrument panel LED parking light: No. 2 DOMINANT SVA-SHG 5" colour TFT display. LEDs. Battery: YUASA YT7B-BS DC DRY sealed-type, 12V - LED stop light: No.
  • Page 314 To reach the fuse boxes, remove the battery compartment cover as described in chapter “Charging the battery”. To expose the fuses used in box (A), remove the box protection lid. Mounting position and ampere capacity are marked on it. Three spare fuses (10 A, 15 A and 25 A) are positioned at the side.
  • Page 315 The 30 A fuse (11) and a spare fuse (12) are located on the solenoid starter. Remove the fuse cap to reach it (B). To reach the 30 A main fuse (13), remove the cap (C) after removing the battery protective cover as described in chapter “Charging the battery”.
  • Page 316 A blown fuse can be identified by breakage of the inner filament (E). Important Switch the ignition key to OFF before replacing the fuse to avoid possible short-circuits. Attention Never use a fuse with a rating other than specified. Failure to observe this rule may damage the electric system or even cause fire.
  • Page 317: Open Source Software

    Open source software Information about open source software Some vehicle components use open source software. The source code used and information on open source is available online at the following link: https://www.ducati.com/ww/en/home/open- source-software...
  • Page 318: Declarations Of Conformity

    Declarations of Declarations of conformity conformity EU Directive 2014/53/EU Frequency bands and maximum transmission power Data relevant to frequency bands and maximum transmission power of radio equipment are given in table Addresses of radio component manufacturers All radio components must carry the manufacturer's address according to the provisions of directive 2014/53/EU.
  • Page 319 Table 1 Radio equipment in‐ Model Name Frequency band Max. transmission power stalled in the vehicle < 42 dBμA/m (10m) with an‐ Egicon RTADE002 tenna: Inductance range: with Loop antenna: 1.025 ÷ 1.065 mH (@100 kHz) Dashboard 134.2 KHz (119 ÷ 135 KHz) Resistance: 14.65 ±...
  • Page 320 The name of the supplier of each device is given in Table 2 Dashboard (RTADE002) H-30825 BRASIL Este produto está homologado pela Anatel, de acordo com os procedimentos regulamentados pela Resolução nº 242/2000 e atende aos requisitos técnicos aplicados. Este equipamento não tem direito à proteção contra interferência prejudicial e não pode causar interferência em sistemas devidamente autorizados.
  • Page 321 CANADA This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device.
  • Page 322 Dashboard RTADE002 IC: 23285-RTADE002 Canadian Representative: DUCATI CANADA 777 Bayly Ave. Ajax ON Canada L1S7G7 Tel No.: +1 705 786 7768 CHINA 使用微功率短距离无线电发射设备应当符合国家无线电管理有关规定。 (Translation: The use of micropower short range radio transmission equipment shall be in accordance with the relevant provisions of the National Radio Management.)
  • Page 323 Votre véhicule est équipé d'une série d'appareillages radio. Les constructeurs de ces appareillages radio déclarent que ces derniers sont conformes à la directive 2014/53/UE lorsque la loi le requiert. Le texte complet de la déclaration de conformité UE est disponible à l'adresse suivante : certifications.ducati.com [Bulgaria] Твоят...
  • Page 324 Votre véhicule est équipé d'une série d'appareillages radio. Les constructeurs de ces appareillages radio déclarent que ces derniers sont conformes à la directive 2014/53/UE lorsque la loi le requiert. Le texte complet de la déclaration de conformité UE est disponible à l'adresse suivante : certifications.ducati.com [Germany] Ihr Fahrzeug ist mit einer Reihe von Funkgeräten ausgestattet.
  • Page 325 Your vehicle is equipped with a range of radio equipment. The manufacturers of this radio equipment declare that these equipment complies with Directive 2014/53/EU where required by law. The complete text of the EU declaration of conformity is available at the following web address: certifications.ducati.com [Italy] Il tuo veicolo è...
  • Page 326 Votre véhicule est équipé d'une série d'appareillages radio. Les constructeurs de ces appareillages radio déclarent que ces derniers sont conformes à la directive 2014/53/UE lorsque la loi le requiert. Le texte complet de la déclaration de conformité UE est disponible à l'adresse suivante : certifications.ducati.com [Malta] Il-vettura tiegħek hija mgħammra b’firxa ta’...
  • Page 327 Su vehículo está equipado con una serie de equipos de radio. Los fabricantes de dichos equipos de radio declaran su conformidad con la directiva 2014/53/UE, como requiere la ley. El texto completo de la declaración de conformidad UE está disponible en el siguiente sitio: certifications.ducati.com [Sweden] Ditt fordon är utrustat med radioutrustning.
  • Page 328 Your vehicle is equipped with a range of radio equipment. The manufacturers of this radio equipment declare that these equipment complies with Directive 2014/53/EU where required by law. The complete text of the EU declaration of conformity is available at the following web address: certifications.ducati.com JAPAN 当該機器には電波法に基づく、技術基準適合証明等を受けた特定無線設備を装着している。...
  • Page 329 MEXICO La operación de este equipo está sujeta a las siguientes dos condiciones: (1) es posible que este equipo o dispositivo no cause interferencia perjudicial y (2) este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la que pueda causar su operación no deseada.
  • Page 330 THAILAND เครื ่ อ งโทรคมนาคมและอุ ป กรณ์ น ี ้ มี ค วามสอดคล้ อ งตามข้ อ กํ า หนดของ กทช. Dashboard RTADE002...
  • Page 331 Frequency bands and maximum transmission power Data relevant to frequency bands and maximum transmission power of radio equipment are given in the table below. Radio equipment in‐ Frequency band Max. tx power stalled in the vehicle Dashboard RTADE002 134.2 KHz (119 ÷ 135 KHz) <...
  • Page 332 In the UK, the relevant regulation is as follows: S.I. no. 2017/1206 “The Radio Equipment Regulations 2017”, as amended by S.I. 2019 no. 696, SCHEDULE 29. The full text of the UK Declaration of Conformity is available at the following Internet address: certifications.ducati.com...
  • Page 333 ПОСТАНОВА ВІД 24 ТРАВНЯ 2017 Р. № 355 Київ; Додаток 6: Cправжнім Robert Bosch GmbH заявляє, що тип радіообладнання (6.5inchCluster/ MRRevo14F/ MRR1Rear) відповідає Технічному регламенту радіообладнання; повний текст декларації про відповідність доступний на веб-сайті за такою адресою: certifications.ducati.com. Dashboard RTADE002...
  • Page 334 UNITED STATES This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation."...
  • Page 335 Dashboard RTADE002 FCC ID: 2ANYI-RTADE002...
