SERVICE MANUAL
ACTIVE SPEAKER
This Service Manual is the "Revision Publishing" and replaces "Simple Manual"
SC-A48 AU<B>(S/M Code No.09-994-328-6T2).
S/M Code No. 09-994-328-6R2
SC-A48
SC-C48
ALH(B)
AU(W)
