AIWA BST-330 Wireless Portable Speaker Manual

Important Safety Instructions

  1. Please do not place device near any form of heat sources.
  2. Please use the accessories specified by the manufacturer.
  3. Please refer all servicing / repairs to a qualified personnelshould there by any form of damage to the device.
  4. Keep this user manual for future referencing/ troubleshooting.
  5. Please heed ALL safety cautions.

Safety Cautions

  1. Always keep device AWAY from fire and heat sources.
  2. Do NOT attempt to disassemble or alter the device.
  3. Do NOT expose device to excessive heat (Direct sunlight etc.).
  4. Do NOT immerse device into any form of liquids.

Unboxing

BST-330 BT speaker
BST-330 BT speaker x1

Type C charging cable
Type C charging cable x1

Instruction
Instruction x1

Please refrain from using any damaged components.
Contact your local authorized AIWA distributor/customer service should you need any assistance.

Product Specifications

Model Number: BST-330
BT version: V5.0
BT Distance: ≥10M (open distance)
Play Mode: BT/ AUX / Micro SD card (TF card)
Battery: 1500mAh / 3.7V
Rated power: 10W
Charging Input: DC 5V 1A (Max)
Working Time: 4-13 hours (depends on different volume)
Charging Time: 2.5 hours (battery empty status)
Distortion Rate: THD<10%
Horn: 50mm x1
Product Size: 110x74x74mm

The above playback & charging times are estimated values tested in a practical environment and may vary upon individual usage habits.

Product Overview

Product Overview 1
Product Overview 2

  1. Light key
  2. Volume"-" / Previous song
  3. Volume"+" / Next song
  4. On/off/Audio/Play/Pause
  5. Micro SD card(TF card)
  6. Aux port
  7. Charging indicator
  8. Charging port
  9. Reset key
  10. Mic

Connecting the Product

Connecting the Product Step 1

Connecting the Product Step 2

Connecting the Product Step 3

Connecting the Product Step 4

""Long press: Turn on the speaker and enter bluetooth mode. The speaker will voice "Welcome to aiwa" & "Bluetooth Mode".

Lighting will flash rapidly, use the bluetooth device to search for "AIWA BST-330" and click to connect.
Upon bluetooth connection, the speaker will voice " Bluetooth connected".

Short press x 2: Switch audio mode
Short press x 3: Start/Close siri
Long press: Power off the speaker, speaker will voice" Bye bye"

Short press together: Disconnect Bluetooth device, then the speaker will voice "Blueotooth disconnected".
And short press together again, speaker will connect to bluetooth device automatically.

Music control -/+

Short press x1: Volume"-"/"+"
Long press: Previous/Next song

NOTE:
When speaker is at Maximum or Minimum volume, the speaker will voice " Maximun volume" or "Minimum volume".

Short press x 1:Play/Pause

Answer the phone

Short press x1: Answer
Long press: Hang up

Switch audio playback modes

Short press X 2: Switch audio playback mode.
The last connected source of audio will be the playback source. Voice prompts from the speaker will be present while you switch between modes.

Light Mode

Short press x1: Lighting effect switch
Short press x2: Lighting on/off

Product charge

Red light on: The battery is charging
Red light off: Fully charged
Low battery: The speaker will prompt " Low battery".

To preserve battery lifespan, fully charge at least once every 45 days.

Intelligent power saving function

The speaker will power down automatically after 5 minutes of inactivity.

NOTE:
Please long press button again to power on the speaker.

Charging and battery information

  1. This product has a built-in non-removable and rechargeable battery. Please use the equipped Type-C cable to charge the battery.
  2. The charging current voltage is 5V/1A (Max).
  3. Please choose the charger that passes the regular manufacturer's safety certification.
  4. Repeated charging on the speaker will cause batteryperformance degradation overtime, which is a normal phenomenon for all rechargeable batteries.

AIWA Electronics International Co., Ltd.
Explore more at www.int-aiwa.com
