- Page 1 EXOS-9 Quick Start Guide v:16.1...
- Page 2 We do this with a simple formula; creating amazing speakers that deliver the music you love, the way it was meant to be heard. We’re thrilled that you’ve chosen the Exos-9 to enhance your listening experience. Welcome to the Aiwa family.
-
Page 3: Battery
G E T T I N G S T A R T E D - B A T T E R Y Setting up your Exos-9 couldn’t be easier. First, install the battery pack. There is a small latch on the bottom of the unit that keeps the battery in place. -
Page 4: Pairing
The screen will illuminate. Now you’re ready to listen! The Exos-9 is always available to pair - in other words, there is no need for “pairing mode. ” Just turn it on and search for it on your smartphone or other Bluetooth-capable device, or simply tap your phone to the NFC touch-point on top of the speaker. - Page 5 Make sure Bluetooth is active on your device. If your device supports NFC pairing, touch it to the NFC icon in the circle on top of the device, just to the right of the button panel. Otherwise, search for nearby Bluetooth devices. The speaker will appear as “Aiwa Exos-9. ”...
- Page 6 G E T T I N G S T A R T E D - A U X - I N The Exos-9 will automatically switch to Auxiliary input when you connect a device using the included 3.5mm cable. However, this may be overridden if there is an active Bluetooth connection.
-
Page 7: Placement
Speakers with deep bass extension like the Exos-9 are affected by how close they are to the wall. Bass can be boosted if the back of the speaker is within a few feet of the wall, but if it’s too... -
Page 8: Auxiliary Input
A U X I L I A R Y I N P U T Almost anything headphones can plug into can play through the Exos-9. MP3 players, CD players, radios, computers, televisions, phones, etc. can be connected with the included 3.5mm audio cable. -
Page 9: Battery Life
B A T T E R Y L I F E The Exos-9 battery lasts for approximately 10 hours playing at moderate volume. Battery life varies with volume - as with all speakers, battery life decreases at a very high volumes. -
Page 10: Charging/Power
The screen shows the charge level. If you have a spare or extended battery, you can charge it when the Exos-9 is plugged in. You can swap a depleted battery with a previously charged one. After 15 minutes of inactivity, the speaker will enter sleep mode to save power. -
Page 11: Usb Ports
U S B P O R T S There are two USB ports on the Exos-9. The port labeled “USB Charge” can be used to charge your mobile device. The Exos-9 firmware can be updated using the micro-USB port labeled “Software Update. ” Check the Aiwa website (www.aiwa.us.com) for instructions and new firmware versions. -
Page 12: Equalizer
E Q U A L I Z E R The Exos-9 has a 5-band graphic equalizer so you can adjust the sound for your personal taste or room acoustics. To adjust the equalizer, use the left and right arrows to select an EQ band. -
Page 13: Controls
C O N T R O L S Play/Pause Link Controls playback of audio on Two Exos-9 speakers can be your connected Bluetooth device. wirelessly connected. Press LINK Does not affect playback through on both speakers within a few the auxiliary-in connection. -
Page 14: Wirelessly Sync Speakers
W I R E L E S S L Y S Y N C S P E A K E R S Simply press the LINK button on one Exos-9 and then press the LINK button on another Exos-9. As long as the two speakers are within about 20 feet of each other, you can listen to your favorite tunes in mirror or stereo mode. - Page 15 Changes or modifications not expressly approved by the party responsible for ent. compliance could void the user’s authority to operate the equipm Model identification information: Aiwa Exos-9 XXXX-XX Model number: XXXX (X=blank, 0-9) Power source country code: XX (X=blank, A-Z) For example, Aiwa Exos-9 9001-US © 2015 Aiwa...
-
Page 16: Safety Guidelines
S A F E T Y G U I D E L I N E S 1. Read all instructions 2. Do not use this apparatus near water. 3. Clean only with a dry cloth. 4. Do not use near any heat sources such as radiators, heat registers, stoves, or other apparatus that produce heat.
