MS390 Series Installation Guide
About this Guide
This guide provides instruction on how to install and configure your MS390 series switch. This guide also provides
mounting instructions and limited troubleshooting procedures. For more switch installation guides, refer to
the
switch installation guides section
Product Overview
Models
Model number
MS390-24-HW
MS390-24P-HW
MS390-24U-HW
MS390-24UX-HW
MS390-48-HW
MS390-48P-HW
on our documentation website.
Stackable Layer-3 24-port Gbe switch with hot-swappable 10G/40G modular
uplinks, hot-swappable power supplies and hot-swappable fans
Stackable Layer-3 24-port Gbe POE+ switch with hot-swappable 10G/40G modular
uplinks, hot-swappable power supplies and hot-swappable fans
Stackable Layer-3 24-port Gbe UPOE switch with hot-swappable 10G/40G modular
uplinks, hot-swappable power supplies and hot-swappable fans
Stackable Layer-3 24-port mGbe UPOE switch with hot-swappable 10G/40G modular
uplinks, hot-swappable power supplies and hot-swappable fans
Stackable Layer-3 48-port Gbe switch with hot-swappable 10G/40G modular uplinks,
hot-swappable power supplies and hot-swappable fans
Stackable Layer-3 48-port Gbe POE+ switch with hot-swappable 10G/40G modular
Description
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Meraki MS390 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Cisco Meraki MS390 Series

  • Page 1 MS390 Series Installation Guide About this Guide This guide provides instruction on how to install and configure your MS390 series switch. This guide also provides mounting instructions and limited troubleshooting procedures. For more switch installation guides, refer to switch installation guides section on our documentation website.
  • Page 2: Technical Specifications

    uplinks, hot-swappable power supplies and hot-swappable fans Stackable Layer-3 48-port Gbe UPOE switch with hot-swappable 10G/40G modular MS390-48U-HW uplinks, hot-swappable power supplies and hot-swappable fans Stackable Layer-3 36-port 2.5Gbe and 12-port mGbe UPOE switch with hot-swappable MS390-48UX-HW 10G/40G modular uplinks, hot-swappable power supplies and hot-swappable fans Stackable Layer-3 48-port 5Gbe UPOE switch with hot-swappable 10G/40G modular MS390-48UX2-HW uplinks, hot-swappable power supplies and hot-swappable fans...
  • Page 3: Front Panel Components

    MS390-48P-HW 48 x 1GbE RJ45 92.6 / 555 W 437W Yes, Dual MS390-48U-HW 48 x 1GbE RJ45 UPoE 145 / 844.9 W 822W Yes, Dual 36 x 100M/1G/2.5G MS390-48UX-HW UPoE 218.5 / 785.5 W 490W Yes, Dual 12 x 100M/1G/2.5G/ 5G/10G 48 x 100M/1G/2.5G/ MS390-48UX2-HW...
  • Page 4: Back Panel Components

    Switch does not have power Switch No client connected Ports Solid amber 10/100 Mbps (1 Gbps on SFP+) Solid green 1/2.5/5/10 Gbps (10 Gbps on SFP+) Back Panel Components Item Component LED Status Description Management Interface Green Connected, used for easy access to the local status page Stack Ports Stack Cables are connected here Redundant Fans...
  • Page 5 MS390-24P Series front panel MS390-24U Series front panel MS390-24UX Series front panel MS390-48 Series front panel MS390-48P Series front panel MS390-48U Series front panel MS390-48UX Series front panel MS390-48UX2 Series front panel MS390 Series Back Panel...
  • Page 6: Factory Reset Button

    Factory Reset Button If the button is pressed and held for at least 10 to 15 seconds and then released, the switch will reboot and be restored to its original factory settings by deleting all configuration information stored on the unit. Package contents In addition to the MS switch, the following are provided: •...
  • Page 7 Note: The MS390 does not include stacking cables. Stacking cables sold separately. Safety and Warnings These operations are to be taken with respect to all local laws. Please take the following into consideration for safe operation: • Power off the unit before you begin. Read the installation instructions before connecting the system to the power source.
  • Page 8: Assigning An Ip Address

    Stacking For stacking please refer to this section Stack Cabling Installation Assigning an IP Address All switches must be assigned routable IP addresses. These IP addresses can be dynamically assigned via DHCP or statically assigned. MS390 switches can support a total count of 1000 VLANs per stand-alone switch or switch stack. VLAN ID 1-1000 are configured by default, however, the active VLANs can be changed via the local status page or dashboard.
  • Page 9: Static Assignment

    Please make sure that the DHCP server used for providing a management IP address to the switch has an available address pool that falls within the active VLAN range. Static Assignment Static IPs can be assigned using the local status page on each switch. For more information on how to configure static IP from the local status page refer to this documentation.
  • Page 10: Installation Instructions

    Installation Instructions Note: Each switch comes with a graphical instruction pamphlet within the box. This pamphlet contains detailed step by step guides and images to assist in the physical install of the switch. 1. Attach the rack mount bracket to both sides of the switch as shown below: 2.
  • Page 11 3. Secure and screw in the rack mount bracket on to the rack. 4. Insert the Uplink module.
  • Page 12 (clockwise direction). Make sure the Cisco logo is on the top side of the connector. • Connect the other end of the cable to the port on the other switch and finger-tighten the screws. Avoid over tightening the screws.
  • Page 13: Basic Troubleshooting

    If you are still experiencing hardware issues, please contact Cisco Meraki support by logging in to dashboard and using the Help option near the top of the page, then opening and email case or calling using the contact information on that page.
  • Page 14: Warranty

    If your Cisco Meraki device fails and the problem cannot be resolved by troubleshooting, contact support to address the issue. Once support determines that the device is in a failed state, they can process an RMA and send out a replacement device free of charge.
  • Page 15 • The equipment is subject to installation and maintenance by specialists with the appropriate qualifications, sufficient specialized knowledge, and skills. • Rules and conditions for the sale of equipment are determined by the terms of contracts concluded by Cisco or authorized Cisco partners with equipment buyers.
