1. In terminal write the following command:
$sudo lsusb
Sometimes you need to input the password for sudo, such as
[sudo] password for ***:
Please input it, then it should have similar information as follows:
Bus 002 Device 002: ID 201e:2009
Here the 201e:2009 is very important; it corresponds to the VID&PID of the data card.
2. Now it should load the proper module to let the kernel know the device. Do as follows:
$sudo modprobe usbserial vendor=0x201e product=0x2009
After that, using the command "dmesg" to check again, it will see the following information:
usbcore: registered new interface driver usbserial
drivers/usb/serial/isb-serial.c: USB Serial support registered for generic
usbserial_generic 2-2:1.0 generic converter detected
usb 2-2: generic converter now attached to ttyUSB0
usbserial_generic 2-2:1.1 generic converter detected
usb 2-2: generic converter now attached to ttyUSB1
usbserial_generic 2-2:1.2 generic converter detected
usb 2-2: generic converter now attached to ttyUSB2
usbcore: registered new interface driver usbserial_generic
drivers/usb/serial/usb-serial: USB Serial Driver core
It's ok for loading the device, the next steps should introduce how to dial the data service. We
use the wvdial command as example.
3. Edit the wvdial configure file by typing the following command:
$sudo gedit /etc/wvdial.conf
On entering the above line a new window will pop up , Fill in the details as given below and
click save and close that window.
Edit the wvdial.conf file as follows:
[Dialer Defaults]
Init = ATZ
Init = ATQ0 V1 E1 S0=0 &C1 &D2 +FCLASS=0
Modem Type = USB Modem
Baud = 115200
Modem = /dev/ttyUSB0
10
