Ion Technologies SH30
High Head Effluent Pump
Introduction
Thank you for purchasing an Ion Technologies
high head effluent pump. Take the time to read the
instructions carefully before using this appliance. We
strongly recommend that you keep this instruction
manual in a safe place for future reference.
Check the nameplate for your pump's specification,
refer to the table list.
Be careful not to exceed the given specifications in
the use of your pump.
Each pump is individually factory tested to ensure
proper
performance.
instructions will eliminate potential operating problems
assuring years of trouble-free service.
Most accidents can be avoided by using common
sense.
Model
HP
SH30
3/10
www.ionproducts.net
Closely
following
these
0'
5'
47
41
OPERATION MANUAL
Dated: 07/31/2017
Document Name: SH30_OM
IMPORTANT: Ion Technologies is not responsible
for losses, injury or death resulting from failure to
observe these safety precautions, misuse, abuse
or misapplication of pumps or equipment.
Marks & Meanings
CAUTION: Keep the pump equipment out of
the reach of children! Warns that the failure to
follow the directions given could cause serious risk to
individuals or objects.
WARNING: This sign warns the operator that
the failure to follow an instruction may damage
the pump and/or the system.
Safety Warnings
CAUTION: Read these safety warnings first
before installing, servicing, or operating any
pump.
Before Installation
This manual contains important information for the safe
use of this product. Read this manual completely and
follow the instructions carefully. Reasonable care and
safe methods relating to the installation and operation
of this product should be practiced. Check local codes
and requirements before installation.
WARNING: Risk of Electrical Shock or
Electrocution. May result in serious injury or
death or fire hazard. Installer must disconnect all
electrical sources prior to installation, handling or
servicing. Only qualified personnel may install this
system. NFPA 70/National Electric Code (NEC) or
GPM @ Total Feet of Head
10'
15'
20'
35
30
24
Page 1 of 12
Maxium
Head
25'
30'
16
8
36'
Advertisement
Table of Contents
Related Manuals for Ion Technologies SH30
Summary of Contents for Ion Technologies SH30
- Page 1 Introduction Safety Warnings Thank you for purchasing an Ion Technologies CAUTION: Read these safety warnings first high head effluent pump. Take the time to read the before installing, servicing, or operating any instructions carefully before using this appliance.
- Page 2 Ion Technologies SH30 OPERATION MANUAL Dated: 07/31/2017 High Head Effluent Pump Document Name: SH30_OM Page 2 of 12 local codes must be followed. System must be properly CAUTION: All returned products must be grounded according to NEC. Do not lift pump by power cleaned, sanitized, or decontaminated prior cord.
- Page 3 Ion Technologies SH30 OPERATION MANUAL Dated: 07/31/2017 High Head Effluent Pump Document Name: SH30_OM Page 3 of 12 Performance WARNING: Make sure lifting handles are securely fastened each time before lifting. CAUTION: Do not lift, carry or hang pump by the electrical cables. Damage to the electrical cables can cause shock, burns or death.
-
Page 4: Specifications
Ion Technologies SH30 OPERATION MANUAL Dated: 07/31/2017 High Head Effluent Pump Document Name: SH30_OM Page 4 of 12 Important 1 Phase Models Model Number: MFG Date: Prior to installation, record Model Amps: Volts: Number, MFG Date, Amps, Phase: Voltage, Phase and HP, from pump nameplate for future reference. -
Page 5: Pump Installation
Ion Technologies SH30 OPERATION MANUAL Dated: 07/31/2017 High Head Effluent Pump Document Name: SH30_OM Page 5 of 12 Pump Installation CAUTION: Operating pump builds up heat and pressure; allow time for pump to cool to room temperature. These important instructions must be followed for satisfactory performance of your pump. -
Page 6: Pre-Operation
Ion Technologies SH30 OPERATION MANUAL Dated: 07/31/2017 High Head Effluent Pump Document Name: SH30_OM Page 6 of 12 pipe has a 1/8” diameter hole approx. 5” from end CAUTION: Electrical Connections nearest volute and oriented towards the pump body. Turn circuit breaker off before plugging or unplugging the switch and/or pump. -
Page 7: Troubleshooting
Ion Technologies SH30 OPERATION MANUAL Dated: 07/31/2017 High Head Effluent Pump Document Name: SH30_OM Page 7 of 12 The thermal sensor will trip when the windings 5. Vertical pumping distance is too high. Reduce become too hot and will automatically reset when the distance or change the discharge fittings of the pump motor cools to a safe temperature. - Page 8 Ion Technologies SH30 OPERATION MANUAL Dated: 07/31/2017 High Head Effluent Pump Document Name: SH30_OM Page 8 of 12 3. Pump impeller may be partially clogged causing motor to run slow, resulting in motor overload. Clear impeller. 4. Defective motor stator; return to authorized service center.
- Page 9 Ion Technologies SH30 OPERATION MANUAL Dated: 07/31/2017 High Head Effluent Pump Document Name: SH30_OM Page 9 of 12 Notes www.ionproducts.net...
- Page 10 Ion Technologies SH30 OPERATION MANUAL Dated: 07/31/2017 High Head Effluent Pump Document Name: SH30_OM Page 10 of 12 Notes www.ionproducts.net...
- Page 11 Ion Technologies SH30 OPERATION MANUAL Dated: 07/31/2017 High Head Effluent Pump Document Name: SH30_OM Page 11 of 12 Notes www.ionproducts.net...
- Page 12 Ion Technologies SH30 OPERATION MANUAL Dated: 07/31/2017 High Head Effluent Pump Document Name: SH30_OM Page 12 of 12 3 Year Residential Warranty Coverage and Term. Metropolitan Industries, Inc. (“Metropolitan”) warrants to the original purchaser (the “Buyer”) of each Ion® product (the “product”), that any part thereof which proves to be defective in material or workmanship within three (3) years from date of manufacture, will be replaced at no charge with a new or remanufactured part, F.O.B.
