M.2 PCI Express x4 Card
1 x internal M.2 Key M
English
Description
This PCI Express card by Delock expands the PC by one M.2 slot. An M.2 SSD
in format 22110, 2280, 2260 and 2242 can be connected. By the heat sink, which
can be positioned on different applicable positions, can be ensured a good heat
dissipation of the memory module.
Technical details
• Connectors:
internal:
1 x 67 pin M.2 key M slot
1 x PCI Express x4, V4.0
1 x 2 pin LED pin header male
• Interface: PCIe
• Supports M.2 modules in format 22110, 2280, 2260 and 2242 with key M or key
B+M based on PCIe
• Maximum height of the components on the module: 1.5 mm, application of
double-sided assembled modules supported
• Data transfer rate up to 64 Gbps
• Supports M.2 modules with up to 3.3 V / 5 A
• Supports NVM Express (NVMe)
