PH10 Submittal Package
PH10 Unheated Series
Project Name
þÿ
P.O.#
þÿ
S.Q.
þÿ
Company
þÿ
Print Name
þÿ
Signature
þÿ
Date
þÿ
(Electronic Signature Preferred)
NOTE: Mars Air Systems, LLC reserves the right to change specifications and product design without notice. Such revisions do not entitle the buyer to corresponding changes, improvements, additions, or replacements for
previously purchased equipment.
14716 S. BROADWAY, GARDENA, CA 90248 ● Ph: (310)532-1555 Fax: (310)-532-3030 ●
Phantom 10 Series
Air Curtain
Submittal Package
Submitted by:
Mars Air Systems, LLC
14716 S. Broadway
Gardena, CA 90248
MARS AIR SYSTEMS, LLC
GARDENA, CA
●
© Copyright Mars Air Systems, LLC 2014
Company Seal or Stamp
USA
●
www.marsair.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Phantom 10 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Mars Air Systems Phantom 10 Series

Summary of Contents for Mars Air Systems Phantom 10 Series

  • Page 1 þÿ (Electronic Signature Preferred) NOTE: Mars Air Systems, LLC reserves the right to change specifications and product design without notice. Such revisions do not entitle the buyer to corresponding changes, improvements, additions, or replacements for previously purchased equipment. MARS AIR SYSTEMS, LLC GARDENA, CA ●...

  • Page 2: Troubleshooting Guide

    CSI Spec Reference Links NOTE: Mars Air Systems, LLC reserves the right to change specifications and product design without notice. Such revisions do not entitle the buyer to corresponding changes, improvements, additions, or replacements for previously purchased equipment. MARS AIR SYSTEMS, LLC GARDENA, CA ●...
  • Page 3 The AMCA Certified Ratings Seal applies to airflow rate, average outlet velocity, outlet velocity uniformity, velocity projection, and power rating at free delivery only. NOTE: Mars Air Systems, LLC reserves the right to change specifications and product design without notice. Such revisions do not entitle the buyer to corresponding changes, improvements, additions, or replacements for previously purchased equipment.
  • Page 4 NOTE: Models PH1060-2 and PH10120-4 are not AMCA-certified. NOTE: Mars Air Systems, LLC reserves the right to change specifications and product design without notice. Such revisions do not entitle the buyer to corresponding changes, improvements, additions, or replacements for previously purchased equipment.
  • Page 6 Document No: ACC-IOM Date: 04/13/2013 ACCESSORY INSTALLATION SUPPLEMENT Door Limit and Magnetic Reed Switches 3. All wiring must be per local and NEC (National Electric Code) codes. 1. Mars door limit and magnetic reed switches are 4. Panels or controllers may be required. Refer to wiring available with NEMA 1, 4X and 7 ratings.
  • Page 7 Document No: ACC-IOM Date: 04/13/2013 Bracket Installation 1. Side Extension Plates: For doorways wider than the air curtain, use combination of Side Extension Plates and Adjustable Mounting Brackets. (FIG. 5) FIG. 7 (WMI/WMH Shown) FIG. 5 (LPV SHOWN) 2. Adjustable Mounting Brackets: For installation of air curtain over drum-style roll-up door, use Extended Wall Mounting Brackets.
  • Page 8 Document No: ICM-IOM Date: 08/24/20 PHANTOM (PH10 and PH12) COMMERCIAL AND INDUSTRIAL SERIES Installation, Operation and Maintenance Manual Read these instructions carefully before assembling, installing, operating, or maintaining the product. Follow all safety guidelines to avoid injury or damage. Keep these instructions for future reference. Warning: To reduce the risk of fire, electric shock, or injury to persons, do not use replacement parts that have not been recommended by the manufacturer.

  • Page 9: Receiving And Inspection

    Verify that all parts, components and accessories, and FIG 1 the correct quantities of each have been received. If any items are missing, report shortages to Mars Air Systems directly to arrange for obtaining the missing items. Again, verify quantities received against those on the Bill of Lading only, as multiple shipments may be involved.
  • Page 10 WARNING The following items must all be completed by a qualified installer and checked off when completed A. Re-check that the product has been installed properly and is level and secure. B. Check all terminal screws are tight and field wiring is connected in accordance to National Electrical Code and wired per the enclosed wiring diagram.

  • Page 11: Maintenance

    3. To access the interior of the product, remove the air L. VERY IMPORTANT Using a clamp meter, measure intake grille(s) and/or air intake filter(s). This is the amperage to each motor and ensure that they do accomplished by removing the screws on the face of the not exceed the amperage listed on the product label.

  • Page 12: Troubleshooting

    TROUBLESHOOTING PROBLEM CAUSE SOLUTION NO AIR BLOWING - No power being supplied to the unit OUT OF DISCHARGE - Confirm power source / check if in on position from the electrical power source NOZZLE - Circuit breaker is tripped - Reset circuit breaker - Blown fuses on power supply - Replace fuses - Allow the motor to cool down;...

  • Page 13: Troubleshooting Motor

    TROUBLESHOOTING MOTOR To determine if the motor is in good operating condition, compare measured motor resistance at the motor terminals to the values shown below. MARS MOTOR RESISTANCE READINGS Single Phase Motors MOTOR WIRES OR TERMINAL (T) OHM READINGS HIGH SPEED (1750) MEDIUM SPEED (1650) LOW SPEED (1450) Applicable Capacitor Motor...

  • Page 14: Warranty

    WARRANTY Model Number: ______________________________ Serial Number: ______________________________ Mars’ warranty coverage, period, extent, and limitations apply to the product only. It does not apply Date Purchased: ____________________________ to labor. Mars warrants that the Mars product 1) is Dealer Purchased From: ______________________ free from defects in materials and workmanship, and 2) conforms to Mars’...
  • Page 15 Mars Phantom 10-CSI-Spec Revised 4/27/2023 MARS AIR SYSTEMS, LLC SECTION 23 34 33 AIR CURTAINS Important Note: This specification contains hidden text appearing in red. To show or remove hidden text in MSWord, click the “File” tab or “Office” icon on the top-left corner, select “Options,” select “Display,”...
  • Page 16 Mars Phantom 10-CSI-Spec Revised 4/27/2023 MARS AIR SYSTEMS, LLC Section 26 05 00 – Equipment Wiring: Connections to building power distribution. REFERENCES ASTM A240 / A240M -10 – Standard Specification for Chromium and Chromium. ASTM A591/A591M Standard Specification for Steel Sheet, Electrolytic Zinc-Coated, for Light Coating Weight Applications ASTM B209 –...

  • Page 17: Quality Assurance

    Mars Phantom 10-CSI-Spec Revised 4/27/2023 MARS AIR SYSTEMS, LLC LEED Submittals: Provide documentation of how the requirements of Credit will be met: List of proposed materials with recycled content. Indicate post-consumer recycled content and pre-consumer recycled content for each product having recycled content.
  • Page 18 PART 2 PRODUCTS MANUFACTURER Acceptable Manufacturer: Mars Air Systems, LLC; 14716 South Broadway St., Gardena, CA 90248. Tel: (310) 532-1555 or (800) 421-1266. Fax: (310) 324-3030. Email: info@marsair.com. Web: www.marsair.com. Delete one of the following two paragraphs: coordinate with requirements of Division 1 section on product options and substitutions.
  • Page 19 Mars Phantom 10-CSI-Spec Revised 4/27/2023 MARS AIR SYSTEMS, LLC Provide resilient isolation dampening mountings between motor frame and motor mounting pan. Factory balanced blower wheel assembly statically and dynamically. Housing: Self-contained one-piece type for units up to 72 inches in length with sufficient strength for mounting from pre-punched mounting holes at both ends to ceiling without intermediate support.
  • Page 20 Mars Phantom 10-CSI-Spec Revised 4/27/2023 MARS AIR SYSTEMS, LLC PH10 72-2: 72 Inch (1830 mm) Wide Units: 1947 feet/min (9.9 m/s) two 1/2HP motor/fan assemblies. PH10 84-2: 84 Inch (2133 mm) Wide Units: 1806 feet/min (9.2 m/s) two 1/2HP motor/fan assemblies.
  • Page 21 Mars Phantom 10-CSI-Spec Revised 4/27/2023 MARS AIR SYSTEMS, LLC Connections: Same end, left hand. Casing: One-piece unpainted galvanized steel, bolted to air curtain housing. Supply and return fittings on ends of casing. Thermostat: Wall-mounted, 110-Volt operation, with heater on/off selection.
  • Page 22 Mars Phantom 10-CSI-Spec Revised 4/27/2023 MARS AIR SYSTEMS, LLC Optional BACnet IP Optional adaptive fan speed control based on existing field conditions. Field mounted outdoor temperature sensors required. Motor Control Panels for Electric Heated Units: Motor Control Panel is included for all electric heated units.
  • Page 23 Mars Phantom 10-CSI-Spec Revised 4/27/2023 MARS AIR SYSTEMS, LLC Electrical components UL/CUL listed. Panels UL 508A listed. Optional Digital Programmable Controller: WiFi enabled controller for wireless interface with field supplied smartphone, tablet or computer No download or app required for wireless interface...

  • Page 24: Installation

    Mars Phantom 10-CSI-Spec Revised 4/27/2023 MARS AIR SYSTEMS, LLC Type: Magnetic reed switch and actuator for swing and sliding doors. Industrial floor mounted or surface mounted switches for roll up doors. Operation for Unheated Units: Automatic on/off control, on when door is opened, off when door is closed.
  • Page 25 Mars Phantom 10-CSI-Spec Revised 4/27/2023 MARS AIR SYSTEMS, LLC Adjust air foil vanes located within the discharge nozzle as required for prevailing conditions at each opening. Check heated air curtain performance on a calm day by measuring air temperature 6 inches off the floor.
  • Page 26 PH10 Series CSI spec (Word doc) NOTE: Mars Air Systems, LLC reserves the right to change specifications and product design without notice. Such revisions do not entitle the buyer to corresponding changes, improvements, additions, or replacements for previously purchased equipment.
