QP10 Submittal Package
QP10 Unheated Series
Project Name
P.O.#
S.Q.
Company
Print Name
Signature
Date
(Electronic Signature Preferred)
NOTE: MARS AIR SYSTEMS, LLC reserves the right to change specifications and product design without notice. Such revisions do not entitle the buyer to corresponding changes, improvements, additions, or replacements
for previously purchased equipment.
14716 S. BROADWAY, GARDENA, CA 90248 ● Ph: (310)532-1555 Fax: (310)-532-3030 ●
QuietPro 10 Series
Commercial Air Curtain
Submittal Package
Submitted by:
Mars Air Systems, LLC
14716 S. Broadway
Gardena, CA 90248
MARS AIR SYSTEMS, LLC
GARDENA, CA
●
© Copyright Mars Air Systems, LLC 2014
Company Seal or Stamp
USA
●
www.marsair.com
Advertisement
Related Manuals for Mars Air Systems QP10 Unheated Series
Summary of Contents for Mars Air Systems QP10 Unheated Series
- Page 1 Company Seal or Stamp (Electronic Signature Preferred) NOTE: MARS AIR SYSTEMS, LLC reserves the right to change specifications and product design without notice. Such revisions do not entitle the buyer to corresponding changes, improvements, additions, or replacements for previously purchased equipment.
- Page 2 CSI Spec Reference Links NOTE: MARS AIR SYSTEMS, LLC reserves the right to change specifications and product design without notice. Such revisions do not entitle the buyer to corresponding changes, improvements, additions, or replacements for previously purchased equipment. MARS AIR SYSTEMS, LLC GARDENA, CA ●...
- Page 3 Note: above data is for 60 Hz at 1725 RPM. For 50 Hz, RPM is 1425 with a 17% reduction in performance. NOTE: Mars Air Systems, LLC reserves the right to change specifications and product design without notice. Such revisions do not entitle the buyer to corresponding changes, improvements, additions, or replacements for previously purchased equipment.
- Page 4 VOLTAGE CODE COLOR NOTE: Mars Air Systems, LLC reserves the right to change specifications and product design without notice. Such revisions do not entitle the buyer to corresponding changes, improvements, additions, or replacements for previously purchased equipment. MARS AIR SYSTEMS, LLC GARDENA, CA ●...
-
Page 6: Accessory Installation Supplement
Document No: ACC-IOM Date: 04/13/2013 ACCESSORY INSTALLATION SUPPLEMENT Door Limit and Magnetic Reed Switches 3. All wiring must be per local and NEC (National Electric Code) codes. 1. Mars door limit and magnetic reed switches are 4. Panels or controllers may be required. Refer to wiring available with NEMA 1, 4X and 7 ratings. - Page 7 Document No: ACC-IOM Date: 04/13/2013 Bracket Installation 1. Side Extension Plates: For doorways wider than the air curtain, use combination of Side Extension Plates and Adjustable Mounting Brackets. (FIG. 5) FIG. 7 (WMI/WMH Shown) FIG. 5 (LPV SHOWN) 2. Adjustable Mounting Brackets: For installation of air curtain over drum-style roll-up door, use Extended Wall Mounting Brackets.
-
Page 8: Installation, Operation And Maintenance
Document No: QP-IOM Date: 08/25/20 QuietPro 10 (QP10) COMMERCIAL SERIES Installation, Operation and Maintenance Manual Please read and save these instructions. Read carefully before attempting to assemble, install, operate, or maintain the product described. Protect yourself and others by observing all safety information. Failure to comply with these instructions could result in personal injury and/or property damage. - Page 9 Verify that all parts, components and accessories, and the correct quantities of each have been received. If any items are missing, report shortages to Mars Air Systems directly to arrange for obtaining the missing items. Again, verify quantities received against those on the Bill of Lading only, as multiple shipments may be involved.
- Page 10 2. The unit and any optional accessories must be wired with the proper voltage to the junction box per the wiring WARNING diagram. (FIG. 3, unheated products only) The following items must all be completed by a qualified 3. All 3 phase motors are bi-directional, which means they installer and checked off when completed can rotate in either direction.
- Page 11 6. The motor(s) require no additional lubrication. They are L. VERY IMPORTANT Using a clamp meter, measure permanently lubricated and feature double sealed ball the amperage to each motor and ensure that they bearings. do not exceed the amperage listed on the product 7.
- Page 12 TROUBLESHOOTING PROBLEM CAUSE SOLUTION NO AIR BLOWING - No power being supplied to the unit OUT OF DISCHARGE - Confirm power source / check if in on position from the electrical power source NOZZLE - Circuit breaker is tripped - Reset circuit breaker - Blown fuses on power supply - Replace fuses - Allow the motor to cool down;...
- Page 13 TROUBLESHOOTING MOTOR To determine if the motor is in good operating condition, compare measured motor resistance at the motor terminals to the values shown below. MARS MOTOR RESISTANCE READINGS Single Phase Motors MOTOR WIRES OR TERMINAL (T) OHM READINGS HIGH SPEED (1750) MEDIUM SPEED (1650) LOW SPEED (1450) Applicable Capacitor Motor...
- Page 14 WARRANTY Model Number: ______________________________ Serial Number: ______________________________ Mars’ warranty coverage, period, extent, and limitations apply to the product only. It does not apply Date Purchased: ____________________________ to labor. Mars warrants that the Mars product 1) is Dealer Purchased From: ______________________ free from defects in materials and workmanship, and 2) conforms to Mars’...
- Page 15 Mars QuietPro 10-CSI-Spec Revised 4/27/2023 MARS AIR SYSTEMS, LLC SECTION 23 34 33 AIR CURTAINS Important Note: This specification contains hidden text appearing in red. To show or remove hidden text in MSWord, click the “File” tab or “Office” icon on the top-left corner, select “Options,” select “Display,”...
- Page 16 Mars QuietPro 10-CSI-Spec Revised 4/27/2023 MARS AIR SYSTEMS, LLC Section 26 05 00 – Equipment Wiring: Connections to building power distribution. REFERENCES ASTM A240 / A240M -10 – Standard Specification for Chromium and Chromium. ASTM A591 / A591M -98 – Standard Specification for Steel Sheet, Electrolytic Zinc- Coated, for Light Coating Weight (Mass) Application (Withdrawn in 2005, replaced by A879/A879M).
-
Page 17: Troubleshooting Guide
Mars QuietPro 10-CSI-Spec Revised 4/27/2023 MARS AIR SYSTEMS, LLC Verification Samples: For each finish product specified, two samples, minimum size 6.25 inches (160 mm) square, representing actual product, color, and patterns. Manufacturer's Certificates: Certify products meet or exceed specified requirements. - Page 18 MARS AIR SYSTEMS, LLC PART 2 PRODUCTS MANUFACTURER Acceptable Manufacturer: Mars Air Systems, LLC; 14716 South Broadway St., Gardena, CA 90248. Tel: (310) 532-1555 or (800) 421-1266. Fax: (310) 324-3030. Email: info@marsair.com. Web: www.marsair.com. Delete one of the following two paragraphs: coordinate with requirements of Division 1 section on product options and substitutions.
- Page 19 Mars QuietPro 10-CSI-Spec Revised 4/27/2023 MARS AIR SYSTEMS, LLC Unheated: 20 inches deep by 12 inches high (including discharge nozzle) by width of unit. Electric Heated: 20 inches deep by 12 inches high (including discharge nozzle) by width of unit.
- Page 20 Mars QuietPro 10-CSI-Spec Revised 4/27/2023 MARS AIR SYSTEMS, LLC QP10120-3: 120 Inch (3050 mm) Wide Units: 2084 feet/min (10.6 m/s) three 1/2HP motor/fan assemblies. QP10144-3: 144 Inch (3660 mm) Wide Units: 1730 feet/min (8.8 m/s) three 1/2HP motor/fan assemblies. Air Speed at Floor: Minimum of 400 fpm (2 m/s) at 3 feet (914 mm) from the floor.
- Page 21 Mars QuietPro 10-CSI-Spec Revised 4/27/2023 MARS AIR SYSTEMS, LLC Coils: Certified in accordance with AHRI 410. Connections: Opposite end. Connections: Same end, right hand. Connections: Same end, left hand. Casing: One-piece unpainted galvanized steel, bolted to air curtain housing. Supply and return fittings on top of casing.
- Page 22 Mars QuietPro 10-CSI-Spec Revised 4/27/2023 MARS AIR SYSTEMS, LLC Electrical components UL/CUL listed. Optional Digital Programmable Controller: WiFi enabled controller for wireless interface with field supplied smartphone, tablet or computer No download or app required for wireless interface Wireless control range up to minimum of 50 feet from controller...
- Page 23 Mars QuietPro 10-CSI-Spec Revised 4/27/2023 MARS AIR SYSTEMS, LLC Optional remote mounted high resolution 7” Color LCD Display with resistive touchscreen technology Fully programmable controller Connect and control via any web browser Factory built wireless router with over 50 feet range Pre-set and fully customizable programs Time delay (Passive &...
- Page 24 Mars QuietPro 10-CSI-Spec Revised 4/27/2023 MARS AIR SYSTEMS, LLC PART 3 EXECUTION EXAMINATION Verify that required utilities are in correct location and are of correct capacities for specified products. Verify openings to receive air curtains are plumb, level, square, accurately aligned, correctly located, and in tolerance.
- Page 25 Mars QuietPro 10-CSI-Spec Revised 4/27/2023 MARS AIR SYSTEMS, LLC Repair minor damages to finish in accordance with manufacturer's instructions and as approved by Architect. Remove and replace damaged components that cannot be successfully repaired as determined by Architect. PROTECTION Protect materials and finish from damage until substantial completion.
- Page 26 QuietPro Series CSI spec (Word doc) NOTE: MARS AIR SYSTEMS, LLC reserves the right to change specifications and product design without notice. Such revisions do not entitle the buyer to corresponding changes, improvements, additions, or replacements for previously purchased equipment.
