Summary of Contents for ML Accessories OP7N
- Page 1 INSTALLATION & MAINTENANCE MANUAL OP7N / OP9N / OP94 / OP9RCD...
-
Page 2: General Instructions
These instructions should be used to aid installation of the following product: OP7N / OP9N / OP94 / OP9RCD SAFETY • This product must be installed in accordance with the latest edition of the IEE Wiring Regulations (BS7671) and current Building Regulations. -
Page 3: Installation
These instructions should be used to aid installation of the following product: OP7N / OP9N / OP94 / OP9RCD SAFETY This product must be installed in accordance with the latest edition of the IEE Wiring Regulations • (BS7671) and current Building Regulations. If in any doubt, consult a qualified electrician INSTALLATION •... - Page 4 • Replace the gasket onto the backbox, then wire as shown in Fig. 3 for OP7N/OP9N/OP94 Replace the gasket onto the backbox, then wire as shown in Fig. 3 for OP7N/OP9N/OP94 Fig. 4 for •...
- Page 5 • slotted to allow some rotational adjustment Replace the gasket onto the backbox, then wire as shown in Fig. 3 for OP7N/OP9N/OP94 Fig. 4 for • Fig. 4 for OPRCD ensuring that correct polarity is observed: L - Live (brown), E - Earth...
- Page 6 • An earth connection must be made to the earth terminal of the socket. Use green/yellow sleeving on earth conductors that are not insulated. The earth terminal in the backbox is provided for convenience and does not need to be connected •...
- Page 7 RCD TEST PROCEDURE Press the green RESET button to switch on the supply. The red indicator should appear. To test that the RCD is operating correctly, press the yellow TEST button. The red indicator should turn green, this will disconnect the load. To restore power, press the green RESET button.
-
Page 8: Warranty
ML Accessories does not accept responsibility for any installation costs associated with the replacement product. Your statutory rights are not affected. ML... - Page 9 SUPPLIED BY: (UK) MANUFACTURER ML ACCESSORIES LTD, UNIT E CHILTERN PARK, BOSCOMBE ROAD, DUNSTABLE LU5 4LT, WWW.MLACCESSORIES.CO.UK (EU) AUTHORISED REPRESENTATIVE SLV LIGHTING GROUP, DAIMLERSTRASSE 21-23, 52531 ÜBACH-PALENBERG, GERMANY EMAIL: EPREL@GROUP.SLV.COM MADE IN CHINA 230V 50Hz JBOCT24_V1...
